Neuson 1402 RD Primus Force 2005 Parts Catalog – Factory OEM Spare Parts

I don’t care if you’ve turned wrenches for twenty years or you’re swapping your first undercarriage component. If you’re touching a Neuson 1402 RD Primus Force crawler excavator without the factory Parts Catalog in your hand, you’re wasting time and money. I’ve seen too many guys order the wrong selection valve because they guessed from a blurry online diagram. This 2005 catalog is the real deal—OEM print, not a scanned copy from some parts house that can’t read German.

This 90-page manual sits on my bench right now. It’s what I pull when a 1402 RD Primus Force rolls in with a leaking swing drive or a busted track adjuster. You get the same part numbers Neuson’s own warehouse uses. None of this “cross-reference your serial number to a superseded part” guesswork that aftermarket catalogs force on you. The format is dead simple: Part A (General Information) and Part B (Parts Number Reference List).

Part A: General Information – The Rules of Ordering

Page 4 spells out exactly how to read the catalog. Positions, article numbers, annotations, quantities. They show you a real example from the manual: a selection valve with part number 1408410 that interchanges with AA00733V under certain serial number ranges. That’s the kind of detail you need when the dealer says “that’s been updated three times.” The catalog uses symbols like A↔N (old and new interchangeable), A→N (replacement only one way), and A#N (not interchangeable). Miss that note and you’ll bolt on a part that doesn’t fit.

Part B: Parts Number Reference List – Find What You Need

This is the meat. The TEILESUCHLISTE / PARTS NUMBER REFERENCE LIST covers every major system on the 1402 RD Primus Force. You get exploded-view diagrams with position callouts, then a table with the part number, quantity, description, and any interchange notes. Need the serial number breakpoint for the updated final drive seal? It’s right there in the “A:” or “E:” column. No calling three dealers to figure out if your machine falls into the new part range.

Why the 2005 Edition Matters

This edition (7.2 / May 2005) covers machines from serial number 0001428/1998 up through that date. If you own a 1402 RD Primus Force that’s newer than 1998, this catalog applies. It also includes all the service news updates (KDN references) that happened during those years. For example, KDN 17/00 tells you about a change in the hydraulic control valve—stuff you’d never catch unless you bought every revision.

Audience Fit: Who Needs This Catalog

Shop owners who don’t have time to chase part numbers for a customer’s 1402 RD. DIY owners who want to order the exact track roller without paying dealer markup. Fleet managers who need to stock common wear parts across multiple machines. If you’re touching any system—undercarriage, hydraulic, engine, cab—this catalog gets you the right Neuson part number fast. I use it to cross-check when a junior tech pulls a number off the internet; nine times out of ten, the internet is wrong.

Source Validity: OEM vs Aftermarket

This is a direct PDF of the factory binder. The file name even shows the original document ID: Neuson_1402_RD_Primus_Force_1998_Parts_Catalog_de-en-fr-40714012993.pdf. That’s three languages (German, English, French) from Neuson Baumaschinen GmbH. No third-party redrawing, no “compatible with” notes. The torque specs? Not in a parts catalog—this is about parts identification only. But for parts, this is the bible. Aftermarket catalogs often leave out the interchange codes and serial number breaks, which is why I’ll only trust the factory print.

FAQ

Does this catalog include part numbers for the entire hydraulic system?

Yes. It covers pumps, valves, cylinders, hoses, fittings, and even the selection valve at position 1 on page 4. Every hydraulic component has a factory part number with quantity and interchange notes.

How do I know if a part has been superseded?

Check the annotation column. If you see “A→N”, the old part replaces to the new one but not backward. “A↔N” means they swap both ways. The catalog also lists a “E:” (valid from serial number) and “A:” (valid until) range to pinpoint the change point.

Can I use this catalog for a 1402 RD Primus Force built before 1998?

No. The catalog starts at serial number 0001428/1998. Machines older than that need the previous edition. Check the PIN on your machine before you order.

Does the catalog give torque specs or repair procedures?

No. This is a parts catalog, not a service manual. It lists part numbers, quantities, and interchange codes only. For torque values and disassembly steps, you need the separate service manual for this model.

Related Manuals: Neuson 1402 RD Primus Force 2005 Parts Catalog – Factory OEM Spare Parts | Wacker Neuson 8002 RD 2009 Parts Catalog – Factory Spare Parts | Wacker Neuson LOCUST 752 2007 Parts Catalog

External reference: Automotive Industry Overview — Automotive Industry Overview

Access the Factory Manual if you want the same parts data Neuson’s own parts counter uses. Anything less and you’re guessing. I don’t guess.
