Dynapac CC5200 2014 Parts Catalog

I’ve been wrenching on heavy equipment long enough to know that ordering the wrong part costs you a day and a half – sometimes more if it’s a special-order item. With the Dynapac CC5200 2014 Parts Catalog, you get the exact part numbers direct from the factory. This is the same 562-page document the dealer uses, not some aftermarket reprint that missed updates. If you need a steering cylinder (4700391023), a scraper kit (4700950151), or any service interval kit for the Cummins QSB 4.5 T3, it’s in here with the official reference. Don’t waste time cross-referencing third-party charts.

Part Number Accuracy for the CC5200

The catalog breaks down every assembly – front frame, rear frame, sprinkler system, end frames, and more. Each part carries a unique OEM number. For example, the eccentric shaft kit is 4700945903. The drum rotation kit is 4700938891. When you order using these numbers, you get the right piece. No returns. No downtime. The catalog also covers serial number breaks – like the steering hitch to 0C004314 (4812113153) and from 0C004315 (4812117737). You need to match your machine’s serial number. Page 53 and 55 show those hitch assemblies.

What Service Kits Are Listed?

Service kits for the Cummins QSB 4.5 T3 engine are listed with full part numbers and intervals: 50-hour (4700945805), 250/750-hour (4812274593), 500-hour (4700945806), and 1000-hour (4700945807). There are also “PLUS” kits for markets outside China. If you’re doing a major service, the 1000-hour start-up kit is included. Also scraper kits, shock absorber kits for the drum, and the sprinkler kit (4812155698). This level of detail keeps a roller running on schedule. For other models, the Dynapac PL2000LS Parts Catalog (258 Pages) – OEM Factory Spec covers the cold planer.

562 Pages: What You Get

That’s 562 pages of OEM documentation. Each section covers a specific module: mechanical (front/rear frame, steering, engine structure), sprinkler system, extra sprinkler tanks, end frames front and rear, and cocoa mat modules. Every part is illustrated in exploded view. You see the relationship between components. For a shop that maintains a fleet of rollers, this catalog pays for itself the first time you avoid ordering the wrong pump. The official Dynapac lineage ensures the data is current.

Verify Part Numbers Against Your Machine’s Serial Number

The catalog is keyed to serial number 10000322x0C002052 and above. If your CC5200 falls in that range, these part numbers are correct. Don’t assume a part from an earlier model year will fit. The steering cylinder (4700391023) is listed on page 39. The grab handle modules and covers are shown. Always confirm your serial number before ordering. This catalog gives you that reference. For a Dynapac CC5200 2015 Parts Catalog you’d need a different serial range; this 2014 edition covers your machine.

3 Reasons to Use the Factory Parts Catalog

First, genuine part numbers eliminate the “I think this fits” gamble. Second, the exploded diagrams show exactly how components assemble – useful when rebuilding a drum rotation kit. Third, the service interval kits are pre-assembled, saving you from piecing together individual seals and filters. Aftermarket catalogs often skip revisions or use superseded numbers. This one is the real deal. The Dynapac PL2000LS Parts Catalog – Factory OEM Specs for Cold Planer is another example of factory-correct documentation.

For an industry context, the Automotive Industry Overview provides background on heavy equipment standards.

Source Validity: OEM vs. Aftermarket

The OCR excerpt from the manual states: “Use only authorized parts. Any damage or malfunction caused by the use of unauthorized parts is not covered by Warranty or Product Liability.” That’s the manufacturer’s own language. This catalog is the authorized source. Aftermarket parts lists might be close, but they often miss engineering changes. The Dynapac CC5200 2014 Parts Catalog is dated 2014-12 and carries Dynapac’s official part numbers. That warning appears on page 2 of the catalog.

Does this catalog include torque specifications for assembly?

No. This is a parts catalog, not a service manual. It lists part numbers and quantities. For torque values, you need the service manual.

Can I use this catalog to order parts from my local dealer?

Yes. The part numbers are factory-issued. Your dealer will recognize them. However, always verify with your machine’s serial number because some sub-assemblies changed during production. For instance, the sprinkler pump has variations from 0C003678 onward. The catalog breaks those out on pages 107-109. If you skip that step, you might end up with the wrong pump and lose a shift waiting for the correct one. Using the catalog correctly means checking the serial number range every time.

Stop hunting for part numbers online and hoping they match. Get the genuine file and access the factory manual for your CC5200.
