Dynapac CC4200C 2016 Parts Catalog – OEM Factory Parts List

Dynapac CC4200C 2016 Parts Catalog – if you’re turning wrenches on one of these rollers, you need the factory book. Not a reprint. Not a third-party summary. I’ve seen too many guys order the wrong eccentric shaft kit because they trusted a generic list. That costs billable hours and leaves a machine down. This catalog runs 588 pages and gives you the exact part numbers, exploded views, and kit breakdowns the factory uses. Use it once, and you’ll stop guessing.

Service Kits and Repair Kits – Specified by Hour Interval

The manual breaks down service kits by runtime: 50-hour Plus, 500-hour for the Cummins QSB 4.5 T3, and 1000-hour. Each kit has its own Dynapac part number – 4812159352, 4700945806, 4812160269 – so you order exactly what the machine needs. Repair kits for the eccentric shaft, drum rotation, shock absorbers, and sprinkler system are listed with separate numbers. Don’t trust aftermarket cross-references; the CC4200C uses specific bearing and seal specs that change with serial number breaks (To A016642 vs From A016643). This catalog catches those differences.

Frame and Structure – Front and Rear Sections with Serial Number Splits

Front frame pages cover steering cylinder (4700391023), tank structure modules, and the articulated joint. Rear frame includes engine structure, noise suppression plates, and covers. The Parts Catalog shows the hitch module in two variants depending on your machine’s serial number. If you need the steering hitch (4812119139) for a newer unit, you flip to page 43. No ambiguity. I’ve had techs ask me, “Which cover do I need for the right side?” – the answer is 4812121583, and you find it in the rear frame section with the correct fastener callouts.

One thing that bugs me: aftermarket catalogs often lump “frame parts” together. This factory book splits front and rear end frames, lists scraper brackets (4700394340) with and without nozzles, and includes cocoa mat modules. You get the exact assembly variant – scraper assy, scraper assy with nozzles – not a generic “fits all” part.

Hydraulic System Details – Front Drum and Rear Wheel Circuits

The hydraulic system section covers the front drum circuit and rear wheel circuit separately. Dynapac provides exploded views of hydraulic valves (4700391017), the offset/combi valve module, and the hose routing on the frame. I appreciate that they include the pump and motor breakdowns for the vibration circuit – you get the hydraulic motor part number 4700395915 and the Sauer vibrating unit. If you’re rebuilding a drum drive, the gear and motor assemblies (4812269526, 4812120567) are shown with exploded views and torque values for the end plates. Those torque values? Not in a generic guide. Only the factory book.

Related resources worth having on the shelf: check the Dynapac CC4200C 2016 Parts Catalog for your own machine. If you work on cold planers, the Dynapac PL2000LS Parts Catalog (258 Pages) – OEM Factory Spec and the Dynapac PL2000LS Parts Catalog – Factory OEM Specs for Cold Planer will save you headaches.

Engine and Cooling – Cummins QSB 4.5 T3 Specifics

The engine section covers the room, module, and the Cummins QSB4.5 T3 (93kW). You get the air cleaner module, muffler, exhaust pipes, fuel hoses, and charge air cooler. There’s a split for water coolers: To A014202 and From A014203. That matters because the hose routing changed. I’ve seen aftermarket diagrams swap them, causing leaks. The expansion tank assembly and coolant hoses are diagrammed clearly. With 588 pages, the catalog doesn’t skimp on engine accessory details – even the expansion tank bracket is listed.

Why Factory OEM Documentation Matters

I’ve been a tech for 28 years. Aftermarket parts catalogs are hit-and-miss. They reuse old drawings, miss serial number breaks, or substitute “equivalent” parts that don’t fit. This 2016 factory catalog is the exact PDF Dynapac released for the CC4200C with Cummins QSB 4.5 IIIA/T3. It contains warranty notes: “Use only authorized parts. Any damage or malfunction caused by the use of unauthorized parts is not covered by Warranty or Product Liability.” That’s not lawyer talk – that’s a real risk if you use a cheap aftermarket bearing. The catalog also includes the general information page that reminds you to consult safety instructions. Don’t skip that.

For a broader look at construction equipment documentation standards, see the Automotive Industry Overview – but honestly, you won’t find anything better than a factory parts list for one specific model.

3 Reasons You’ll Use This Catalog Every Week

• Part numbers are grouped by system (frame, drum, engine, hydraulics) with exact locations on exploded diagrams – no “see similar” nonsense.
• Service kits list every gasket, O-ring, and filter needed for a specific hour interval; you order one number instead of ten.
• Repair kit contents are shown with quantities and descriptions – the eccentric shaft kit (4700945903) includes bearings and seals, not guesses.

I’ve built a career on using the right spec. This catalog is the spec.

Frequently Asked Questions

Does this manual include torque specifications for assembly?

No. This is a parts catalog, not a service manual. It lists part numbers and exploded views. For torque specs, get the factory service manual for the CC4200C.

How many pages and what year is this catalog?

588 pages. Published in 2016. Covers CC4200C rollers with Cummins QSB 4.5 T3 engine from serial number 10000321xxA013070 onward.

Stop losing time on wrong parts. Access the Factory Manual now and keep your CC4200C running with OEM-specified components.
