Dynapac CC5200 2015 Parts Catalog – OEM Factory Specs for Vibratory Roller

If you’ve ever ordered a part for a vibratory roller and got the wrong size scraper blade or a pump that doesn’t match your serial number, you know the headache. That’s what happens when you rely on aftermarket catalogs or memory. The Dynapac CC5200 2015 Parts Catalog is the factory-issued document that eliminates that risk. 592 pages of OEM part numbers, exploded diagrams, and serial-number-specific splits. This isn’t a shop manual – it’s a parts catalog. You still need the service manual for torque specs and procedures. But if you want to order the correct eccentric shaft kit or sprinkler pump module without pulling your hair out, this is the book.

Service Kits and Repair Kits – 7 Pre-Assembled Sets

The manual opens with service kits for the Cummins QSB 4.5 Tier 4i engine and the roller itself. Part numbers like 4812159352 (50-hour Plus kit) and 4812159355 (1000-hour Cummins QSB 4.5 kit) are listed with full contents. You also get repair kits: scraper kit (4700950151), eccentric shaft kit (4700945903), drum rotation kit (4700938891), shock absorber kit for drum (4700945904), and a sprinkler kit (4812155698). Each kit breaks down into individual components in later sections. If you’re rebuilding the drum vibration system, start with page 22 for the eccentric shaft kit and trace every seal, bearing, and spacer.

Frame Breakdown – Front Frame, Rear Frame, Sprinkler System

This is where the catalog earns its keep. The front frame section covers the steering cylinder (part 4700391023), tank structure module, articulated joint (4812117737), and hitch module. Rear frame includes engine structure module, oil cooler, fan module, noise suppression plates. Crucially, the sprinkler system is split by serial number – To SN 0A013069 and From SN 0A013070. That’s a detail most aftermarket catalogs skip. You get separate water hose routing diagrams and pump modules for each range. If your roller is around that breakpoint, check your serial number before ordering.

Sprinkler System: Water Hoses and Pump Modules by Serial Number

The sprinkler section (page 82+) covers the main pump, backup pump, and optional cocoa mat pumps. For machines built up to SN 0A013069, you reference sprinkler pump module on page 84; from that serial onward, it’s page 88. The backup pump also splits: two separate pages for each range. This level of granularity is what prevents downtime. One extra note: the manual includes a separate section for an extra sprinkler tank if your roller is equipped with the larger water capacity option. Filling pipe, water hoses, tank – all drawn and numbered.

End Frame Assemblies – Front and Rear with Scraper Modules

Front end frame includes fork assemblies for vibration and propulsion sides, scraper modules with and without nozzles (page 118+), cocoa mat module, and process mirrors. Rear end frame includes a similar layout plus a steering cylinder (4700391024) for offset models. Scraper bracket (4700394340) is common to both ends. If you’re replacing a scraper, decide whether you need the module with nozzles or without – the part numbers differ. The cocoa mat module is also detailed, including bracket assemblies. Every page shows the exact bolt and washer count.

Why OEM Parts Catalogs Beat Aftermarket Copies

I’ve seen aftermarket parts diagrams where the engine mounts are drawn wrong or the sprinkler pump location is flipped. You can’t trust third-party reprints when a $2,000 drum shock absorber kit is on the line. This is a direct scan from Dynapac – the Swedish manufacturer that built the roller. The part numbers, illustrations, and serial number splits are identical to what the dealer uses. No reprints, no generic drawings. If you need a replacement for the fan module or a grab handle, you get the factory number.

Also worth noting: the document is dated 2015 (part number 4812159878_A) and specifically covers CC5200 machines with Cummins QSB 4.5 IIIB/T4i engine. If your machine is a Tier 4 Final model, you’ll need a different catalog. Check the serial number range: 10000347x 0A012727 and up.

Audience Fit – Who Needs This Catalog

This is for the home garage guy who maintains his own roller, the small rental fleet manager, or the field mechanic who gets handed a parts list and an exploded view. You don’t need to be a master tech – you need to be able to read a part number and match it to your machine. If you’ve ever stood in a parts counter with a greasy scraper blade and tried to describe it, you’ll appreciate having the drawing and number ready. Use it alongside a service manual for full coverage.

Source Validity – Factory Document, Not a Reprint

AutoRepairManuals carries the largest collection of OEM shop manuals in North America. This catalog is a verified factory scan, not a photocopy of a photocopy. The PDF is searchable, so you can type “4812159353” and jump straight to the 500-hour service kit page. No guesswork. If you want to see other factory catalogs from the same manufacturer, check the Dynapac CC5200 2014 Parts Catalog or the Dynapac PL2000LS Parts Catalog (258 Pages) – OEM Factory Spec for cold planers. For tracked machines, the Dynapac PL2000LS Parts Catalog – Factory OEM Specs for Cold Planer is also available.

For broader context on construction equipment documentation standards, see this Automotive Industry Overview.

FAQ – Dynapac CC5200 2015 Parts Catalog

Does this catalog include torque specifications for bolts?

No. This is a parts catalog, not a service manual. Torque specs are found in the OEM workshop manual. Use this catalog to order the correct parts, then refer to the service manual for assembly torque values.

How do I find the correct part for my CC5200 with serial number around 0A013069?

Look for the serial number splits in the sprinkler system and other sections. The catalog marks components as “To SN 0A013069” and “From SN 0A013070.” Check your machine’s serial plate – typically on the rear frame near the engine. If your number is, say, 0A013072, you need the “From” parts. If it’s 0A013065, use the “To” pages. This applies to sprinkler pumps, backup pumps, and some wiring components.

Can I use this catalog for a Dynapac CC5200 with a Tier 4 Final engine?

No. This catalog specifically covers the IIIB/T4i (Cummins QSB 4.5) emission level. Tier 4 Final machines use different engines, pumps, and aftertreatment systems. Look for a later edition or a separate catalog for Tier 4 Final models.

Is the catalog available in a printed format?

The access is a digital PDF. You can print specific pages as needed. The file is 592 pages, so printing the whole thing is heavy. Most users keep it on a tablet in the shop for quick reference.

Access the Factory Manual and stop wasting time cross-referencing part numbers from blurry online listings. This is the same document the dealer uses. Get it, print the pages you need, and keep your CC5200 running with OEM parts.
