Ssangyong Korando 2010 Technical Manual – E-EGR System

You have a Korando 2010 that’s throwing a P0401 or maybe the EGR valve is sticking. You start poking around, pull the cooler, and you need to know the torque on those bolts. Generic aftermarket guides tell you “hand tight plus a quarter turn.” That’s how you crack a U-shaped cooler and waste a Saturday. This Ssangyong Korando 2010 Technical Manual is the actual OEM document from Ssangyong,xa020 pages dedicated to the E-EGR system. No guessing, no third-party rewrites.

E-EGR System Specification – Page 3

Page 3 gives you the hard numbers. The E-EGR valve is driven by a DC motor with a response time of 50 ms. Gas flow rate: 120 kg/h. E-EGR cooler has a cooling capacity of 8.3 kW or more. Cooling fin is wavy type, cooler U-shaped. Bypass solenoid is vacuum-actuated. Those specs matter when you’re testing the valve or replacing the cooler. If you don’t have the factory numbers, you’re flying blind.

What Does This Technical Manual Cover?

This is not a full service manual. It covers the E-EGR system exclusively: general information, specification, overview, operating process, configuration, and removal & installation for the EGR cooler assembly, E-EGR pipe, and cooler. If you need engine block disassembly or transmission work, grab the full SsangYong Korando 2010 Service Manual instead. But for the EGR circuit, this 20-page book is all you need. There’s also a SsangYong Korando 2010 Audio System Technical Manual if you’re dealing with a different headache. For comparison, the Ssangyong Kyron 2005 Technical Manual – 1105 Pages Factory Specs shows what a full manual looks like.

20 Pages of Factory Procedures

20 pages sounds thin until you realize it’s laser-focused. The index starts with general info and a one-page spec table. Then you get an overview of the E-EGR valve function, the operating process (how the system responds to engine load), and a dedicated section on the 1793-12 EGR cooler assembly. The removal and installation section covers component removal, the E-EGR pipe (1793-05), and the cooler (1793-12). Page 17 walks you through taking the E-EGR cooler off without breaking the mounting boss. Torque values are listed in Nm – you can convert to lb-ft, but use the factory numbers.

E-EGR Cooler Assembly: Configuration and Function

Section 1793-12 breaks down the cooler assembly. You get the wavy fin design and the U-shaped flow path. The bypass valve uses a vacuum solenoid – the manual explains how it operates. Before you start unbolting anything, read that section. I’ve seen guys remove the cooler without depressurizing the system and crack the housing. The manual gives you the steps in order. No need to reinvent the procedure.

Get the Right Torque Data

Page 3 has the specification table that includes operating parameters, but the removal pages have fastener torque values. I can’t tell you the exact numbers because I don’t have them memorized – that’s why you buy the manual. What I can tell you is that overtightening the E-EGR pipe flange bolts warps the flange, and undertightening the cooler bolts causes an exhaust leak. The factory spec is the only authority.

Need background on automotive emissions systems? Check the Automotive Industry Overview for a general reference. Or search Automotive Industry Overview for broader context. But for this specific job, stick with the OEM doc.

Who Needs This Manual?

DIYers owning a 2010 Korando who want to replace the E-EGR cooler or diagnose a stuck valve. Beginners who need to understand the system before touching anything. Professional mechanics who want the real specs without scrolling through forum threads. Safety warning: let the engine cool, disconnect the battery, and use jack stands if you’re working under the vehicle. The manual doesn’t repeat that on every page, but I am.

Can I use this manual to fix my check engine light P0401?

Yes, if the fault is in the E-EGR system. This manual covers diagnostics and replacement.

Does this manual include wiring diagrams?

It does not include full wiring schematics for the entire vehicle. However, it covers the E-EGR valve electrical feedback (potentiometer function) and the solenoid vacuum control. For complete vehicle wiring, you’ll want the full Ssangyong Korando 2010 Service Manual. The spec table on page 3 gives you the motor response time and flow rate, which helps when testing the valve electrically.

How many pages is the manual?

20 pages. Focused entirely on the E-EGR system – specification, operation, and removal.

Is this the original factory manual?

Yes, it’s the OEM Ssangyong document from 2010, printed in October 2010 with application basis and affected VIN data included.

If you’re working on a Korando 2010 E-EGR system, stop relying on forum advice. Access the Factory Manual from AutoRepairManuals – 20 pages of verified specs straight from Ssangyong. That’s the only way to get the job done without comebacks.
