OM Pimespo XE22ac, XE25ac, XE25Lac, XE30ac 2006 Workshop Manual

If you are swapping a drive motor on an OM Pimespo electric forklift without the factory binder, you are burning billable hours and risking a callback. I have seen guys torque a motor mount to a guess, then wonder why the bolts loosen in a month. The OM Pimespo XE22ac, XE25ac, XE25Lac, XE30ac 2006 Workshop Manual ends that. Everything you need to keep these Series 4024 trucks running is inside these 286 pages – OEM torque specs, diagnostic software procedures, and maintenance intervals that come straight from the plant in Italy. Not a reprint, not a summary.

Two hundred eighty-six pages.

OM Pimespo XE22ac, XE25ac, XE25Lac, XE30ac 2006 Workshop Manual: Factory Data You Can Trust

This is the genuine workshop literature, edition 07/2006. The Table of Contents starts with General Information – section 00 – covering overall dimensions, technical data, tire inflation pressures, and battery dimensions for each model. You get the lift capacities for the 2200 kg, 2500 kg short pitch, 2500 kg long pitch, and 3000 kg configurations. If you need to know the exact counterweight disconnection procedure, it is in section 31. Every page is laid out for a tech who has done this before – no fluff, just steps and numbers.

286 Pages of Factory Service Data

The main sections break down by system: 00 General Information, 01 Technical Assistance (maintenance schedules and supply tables), 02 Diagnostics, 11 Drive Motor, 22 Transmission, 31 Truck, 34 Driver’s Seat, and 42 Steering System. The diagnostic chapter alone is worth the access. It covers the WINPCCONSOLE software – connection between the diagnostics PC and the forklift, the PARAMETER menu, the TESTER menu, alarm codes for the DUAL AC Master module, AC3 module, and Smart Display. No aftermarket generic overlay, just the factory data you need to clear a fault and move on.

WINPCCONSOLE Diagnostic Software: Dealer-Level Tools

The diagnostics chapter – Section 02 – dives into the WINPCCONSOLE software. It covers the connection between the diagnostic PC and the forklift, the PARAMETER menu, the TESTER menu, and the Smart Display. You get parameters for the DUAL AC Master module, AC3 module, speed reductions, and alarm codes. This is the actual factory diagnostic procedure, not a third-party summary. If you have a fault code, you look it up here instead of guessing. The alarm section breaks down every module: DUAL AC, AC3, and Smart Display. Without this data, you are chasing electrical ghosts. With it, you are following a map. The manual also includes the analogue signal acquisition procedure, so you can verify sensor readings against factory numbers. That is the difference between a repair that holds up and a comeback job. If you work on other OM Pimespo models, you might also need OM Pimespo XD40/45/50 Series 4156 Workshop Literature for the larger trucks.

Drive Motor and Front Axle Specifications

Section 11 covers the asynchronous drive motors. You get technical data, check procedures, motor temperature sensor specs, and decomposition steps. Section 22 covers the front axle and reducer – removal, disassembly, reassembly, oil change intervals, and reduction gear layout. I have seen a tech try to pull a front axle without the manual, and he spent two hours figuring out the bolt pattern. The manual shows the layout and torque sequence. Also, the reduction gear oil level check is right there. For a deeper understanding of gear types, read up on Manual Transmission fundamentals. But for the actual factory steps on this Series 4024, you need this book.

What About the Steering System?

Section 42 covers the steering hydraulic circuit, tube connection diagram, steering distributor removal and reassembly, steering column joint replacement, and steering axle bearing replacement. If you have a hard-steering complaint on an XE25Lac, the steering axle technical data and lubrication specs are in that chapter. You also get the steering column removal steps. No need to guess the orientation of the joint – the manual shows it.

General Information: Start Here

The General Information section (00) includes safety devices, transporting, towing, and loading/unloading the forklift. The safety precautions are not fluff – they cover preliminary operations, accident avoidance, and safety regulations relative to operating materials. You also get the abbreviation key, lamp specifications, and internal accessibility for each model. If you need the battery dimensions and weights for swapping a pack, page numbers in that section tell you exactly which battery fits which model. Do not skip the safety symbols section – I have seen guys get injured because they ignored the lockout procedure. For the earlier Series 4016/4017 trucks, check OM PIMESPO Shop Manual Series 4016 4017 – Section: Chapter 00 Contents to see how the layout differs. And for the XD XG series, OM Pimespo Shop Manual Series 4141-4257 XD XG covers those models.

Understanding OEM documentation is a core skill in this industry. The Automotive Industry Overview on Wikipedia gives context, but the real work happens when you have a manual like this open on the bench.

Is this manual officially from OM Pimespo?

Yes, it is the OEM workshop literature, edition 07/2006.

What diagnostic software does the manual cover?

The manual covers the WINPCCONSOLE diagnostic software, including connection between the diagnostics PC and the forklift. It provides full descriptions of the PARAMETER menu, the TESTER menu, and the Smart Display. You get alarm codes for the DUAL AC Master module, AC3 module, and Smart Display. The parameters section lists each module’s parameters and speed reductions. This is the same data the dealer uses—none of the guesswork from third-party reprints or outdated summaries.

Access the Factory Manual from AutoRepairManuals and get the real data – 286 pages of factory specifications for the XE22ac, XE25ac, XE25Lac, and XE30ac. Your workbench will thank you.
