Mitsubishi Motors COLT, LANCER 1993 Wiring Diagram – Factory OEM Manual

If you’ve ever stared at a tangled mess of wires under the dash of a mid-90s Mitsubishi and wondered which one goes to the tail lights or the fuel pump relay, you’re not alone. I’ve seen guys chase a short for three hours because they trusted a generic aftermarket wiring diagram that had the pinouts reversed. That’s why I keep the official Mitsubishi Motors COLT, LANCER 1993 Wiring Diagram on my bench. This is the same document Mitsubishi issued to its dealer network in December 1993 – 197 pages of factory wiring layouts, connector locations, and circuit diagrams. No guesswork, no translation errors from a third-party republisher. You get the real thing.

How to Read the Factory Wiring Diagrams

Open to Group 1 – “COMO INTERPRETAR LOS DIAGRAMAS DE CABLEADO”. Mitsubishi didn’t just throw a bunch of colored lines on a page. They explain the symbols, wire color codes, and how to interpret the configuration diagrams. Page 4 shows you exactly how the connector numbering works: the letter tells you where the connector lives (engine compartment, instrument panel, door, etc.) and the number is a sequential ID. If you’ve ever misread a connector position and fried a module, this section alone is worth the price of the access.

Connector and Harness Layouts

Group 2 – “DIAGRAMAS DE CONFIGURACION DE LOS MAZOS DE CONDUCTORES” – gives you the physical routing of every harness. I tell my guys: before you start probing with a multimeter, look at these layouts. They show where the main body harness splits, where the engine harness passes through the firewall, and where each connector lives. Mitsubishi even marks ground points with a dedicated symbol. You’ll see the same numbers you see in the circuit diagrams, so you can cross-reference instantly. Saves time and keeps you from ripping out a dash panel that didn’t need to come out.

Individual Component Locations – Group 3

Group 3 charts the exact mounting positions of sensors, relays, fusible links, and control units. For a DIYer working on a 1993 COLT or LANCER, this is where you find out that the engine control relay is buried behind the left kick panel, not under the hood. I’ve watched a weekend mechanic pull his hair out because he couldn’t find the air flow meter connector. The manual puts it on a map. No more hunting.

Circuit Diagrams – Group 4

Group 4 is the main event: “DIAGRAMAS DE CIRCUITOS”. These are the full schematics for every electrical system – starting, charging, lighting, wipers, A/C, audio, and the engine management harness. Need to trace the alternator sense wire? It’s in that section. Want to confirm the correct wire color for the crank sensor? The manual lists the color codes right next to the symbol. Because it’s a factory document, the wire colors match the actual harness. Aftermarket diagrams often use generic colors or skip the stripe patterns. That’s how you end up connecting a white wire with a green stripe to a solid white wire and frying a fuse. Not here.

Why Factory Specs Matter for Your COLT or LANCER

This manual is an original Mitsubishi Motors publication – Publication Number PHMS9340 – printed in December 1993. It is not a scan of a scan. It’s not a translation from an aftermarket source. The wiring diagrams, pin numbers, and component positions were checked against production vehicles. I’ve used these diagrams to diagnose a no-start on a 1993 LANCER GTI and found that the previous owner had swapped the injector harness connectors because an aftermarket diagram had the injector bank orientation wrong. This manual caught it in five minutes. If you’re serious about electrical diagnostics, you need the genuine article. Check out the Mitsubishi Lancer Evolution VIII 2003 Electrical Manual for newer platform diagrams, but for the 1993 COLT and LANCER, this is the only one I trust.

Who Should Own This Manual

If you’re a home garage enthusiast working on a 1993 COLT or LANCER, or a shop that still sees these cars roll in for electrical repairs, this manual belongs on your shelf. The 197 pages cover everything from the basic lighting circuits to the engine control wiring. Beginners will appreciate the explanation of how to read the diagrams (Group 1). Professionals will use the connector and ground locations to get in and out faster. DIYers who are tired of paying dealership diagnostic fees for a simple short circuit – this is your toolkit. For related factory documents, see the Mitsubishi Motors 3000GT 1992 Technical Manual – 216-Page Factory Specs or the Mitsubishi Motors 4G63, 4G64 1998 Technical Manual – 122-Page Factory Specs if you’re also working on engine mechanicals.

FAQ – Common Questions About This Wiring Diagram

Is this manual in English?

No, the original factory manual is in Spanish. The wiring diagrams and connector numbers are universal – they use the same symbols and color codes Mitsubishi used worldwide. If you’ve ever worked from a Mitsubishi wiring diagram in another language, the layout will be familiar.

Does it include the air conditioning circuit?

Yes. The circuit diagrams in Group 4 include A/C compressor, condenser fan, and blower motor wiring.

Are torque specs included for electrical connections?

This is a wiring diagram manual, not a service manual. It does not list torque values for bolts or sensors. For that, you need the factory service manual listed in the preface (e.g., PYMS9122).

How many pages are there?

197 pages, covering Groups 1-4 as described. The PDF is a direct scan of the original binder – no missing pages.

I’ve been turning wrenches for 28 years, and I can tell you that the difference between a correct diagnosis and a three-day headache is often the quality of the wiring diagram you’re using. This Mitsubishi Motors factory manual gives you the same information that the dealership technician had in 1993. It’s saved me more hours than I can count. If you want to stop chasing wiring ghosts and start finding the real problem, Access the Factory Manual now. For more on interpreting automotive electrical systems, read this Automotive Wiring overview. And if you’re interested in the automotive industry’s shift towards standardized electrical systems, see the Automotive Industry Overview for context.
