Jaguar AJ V8 2004 Technical Manual – What a Pro Uses

You’ve got a 2004 Jaguar AJ V8 on the lift. Maybe it’s an XJ, maybe an XK, maybe an S-Type. The owner’s waiting. You need oil capacity, torque for the valve cover, or the firing order. If you grab a generic aftermarket spec sheet, you’re gambling. I’ve seen techs strip a head bolt because they trusted a third‑party number. This Jaguar AJ V8 2004 Technical Manual is the factory booklet Jaguar handed to its dealer techs. 146 pages, published July 2004, part number JJM 10 34 99 501. It’s the only source I’d let touch a Jaguar engine.

Vehicle Identification Numbers – Why You Need Them

Before you order a single part, pull the VIN. This manual lays out exactly where to find the VIN on each model—XJ up to 2003.5MY on the left‑hand “A” pillar, after that same spot but different label. XK on the left “B” pillar. S‑Type on the left “A” pillar. X‑Type early on left “A”, later on left “B”. Why does that matter? Because the engine identification codes change by VIN range. You might have a 4.2L supercharged or a 4.0L naturally aspirated. The wrong oil filter or crank bolt torque can cost you an engine. Page 1 of the manual shows the VIN location table. Don’t skip this step.

Jaguar AJ V8 2004 Technical Manual: What You Actually Get

This isn’t a repair manual—it’s the factory vehicle specifications booklet. Covers engine data for V8 gasoline engines in XJ, XK, and S‑Type from 1998 through 2004. You get cylinder numbering, firing order, valve clearances, spark plug specs, oil capacities, coolant, power steering fluid, air conditioning refrigerant charge, rear axle ratios, transmission lubricants. Each section is organized by model year and engine displacement. For example, the 4.2L supercharged engine first appeared in 2003.5MY XJ. If you need to confirm the oil capacity for that engine, go to page 25. If you’re setting valve clearances, page 20 has the cold clearances for each AJ V8 variant. The data comes straight from Jaguar Technical Communications. No guesswork.

Torque Specs and Fluid Capacities – Factory Data Only

Torque values appear throughout the engine data tables. I’m not going to list them here because you need to see the table for your specific engine code. The manual lists engine identification codes (A through F) based on VIN and emission system. You match your VIN to the code, then that code points to the correct spec table. For instance, the V8 gasoline engine ID code table on page 4 shows serial numbers up to 2001MY and after. Use the wrong code and your torque for the main bearing cap could be off by 20 ft‑lbs. I’ve seen it happen. Stick to this booklet. It also gives you transmission and final drive ID codes, differential ratios, and lubricant specs. If you’re swapping a rear end, page 38 tells you which ratio came in which model year. That’s data you won’t find in a Chilton’s.

Does This Manual Cover the 4.2L Supercharged?

Check the model year tables. The 4.2L supercharged (SC) engine appears in XJ from 2003.5MY onward, and in XK from 2003MY onward. The manual lists the introduction date for each engine. It also covers the 4.0L naturally aspirated and supercharged, the 3.2L, 3.5L, and the 4.2L naturally aspirated. If you’re working on a 2004 XK with the 4.2L SC, the spark plug gap, oil viscosity, and cooling system cap pressure are all in here. Page 21 for spark plugs—they specify the exact NGK or Champion part number. Don’t trust an aftermarket cross‑reference without verifying against this manual. I’ve had parts counter guys hand me the wrong plug because their screen showed a generic equivalent. This booklet ends that.

3 Reasons Aftermarket Manuals Miss the Mark

Aftermarket manuals reprint data from earlier years, merge superseded specs, and leave out model‑year splits. I’ve caught them listing the same oil capacity for a 1998 4.0L and a 2004 4.2L, which is wrong. This factory manual was updated in July 2004 to include the 2003.5 and 2004 model year changes. It also tells you to hand‑enter Technical Service Bulletin updates. That’s the level of detail a pro needs. If you’re a DIY guy at home, you’ll still appreciate having the exact same data a Jaguar dealer tech uses. Saves you from buying parts twice.

Related Manuals You Might Need

If you’re working on a full vehicle, you might also want the Jaguar XSARA, XANTIA, SYNERGIE, EVASION, BERLINGO 2004 Technical Manual – Key Fo (though that’s a different brand, it’s in our catalog), or the Jaguar XK8 1996 Technical Manual – Factory Specs & Procedures for earlier models. For diagnostic tool training, check Jaguar Land Rover Land Rover 2009 Training Manual – SDD IDS Diagnostics. And for broader automotive context, see Automotive Industry Overview or Manual Transmission on Wikipedia.

Does this manual include wiring diagrams?

No. This is a vehicle specifications booklet, not a service manual. It covers fluid capacities, torque specs, VIN codes, and engine data only.

What torque value should I use for the main bearing cap on a 2004 AJ V8?

You must cross-reference your VIN to the engine identification code on page 4, then go to the engine data section for that code. The manual does not list a single universal torque because the value differs between the 4.0L, 4.2L, and supercharged variants. For example, the 4.2L SC uses a different cap bolt design than the 4.0L NA. If you use the wrong value, you risk spinning a bearing or snapping a bolt. Always verify the exact code before torquing any critical fastener.

Stop wasting time cross‑referencing bad data. Access the Factory Manual and keep a copy at your workbench. 146 pages, OEM correct, written for the technicians who built these cars. Your engine will thank you.
