Hyundai Van Truck, Refrigerated Van, Cool Van, Insulated Van, Dry Van Technical Manual

I’ve seen one too many DIY guy try to patch up a refrigerator van body with aftermarket panel specs that were off by a quarter-inch. That kind of mistake costs you the whole insulation seal. This manual is the real deal. It’s the Hyundai Van Truck, Refrigerated Van, Cool Van, Insulated Van, Dry Van Technical Manual – 36 pages of factory data printed by Hyundai Motor Company themselves. No reprints, no third-party guessing. If you’re working on any of these van bodies and need the actual OEM panel thicknesses, insulation material specs, or mounting points, this is what you need on your bench.

Hyundai Van Truck Technical Manual: What It Covers

This manual breaks down the entire upper body structure for the Van Truck platform. You get dedicated sections for the Refrigerated Van (page 8), Cool Van (page 10), Insulated Van (page 11), Dry Van (page 12), plus a handful of less common variants like the Eutectic Cold Van (page 14), Bottle Carrier (page 15), and Wing Body (page 16). Each section includes the specific panel thicknesses (70 or 80 mm polystyrene for the refrigerated body), refrigeration unit mounting details, and liftgate installation procedures on page 19. That’s the kind of specificity that keeps you from drilling into the wrong spot.

For related body specifications on other Hyundai special vehicles, check the Hyundai Universe Technical Manual – 16-Page OEM Spec Reference. If you need engine data for the chassis these bodies sit on, the Hyundai Beta, Alpha, Gamma, Theta, Mu 2012 Technical Manual – OEM Specs covers the drivetrain. For smaller-displacement engines, the Hyundai 1.5 L, 1.6 L, 1.8 L Technical Manual – 88 Pages OEM Specs has the specifics.

Body Configuration Breakdown: Refrigerated, Cool, Insulated, Dry

You need to know the difference between a Cool Van and a Refrigerated Van. The manual spells it out. The Refrigerated Van uses a powered refrigeration unit with 70–80 mm insulated panels. The Cool Van relies on passive insulation and works with a smaller cooling unit. The Insulated Van is basically a thermal box with no active cooling – it just holds temperature. The Dry Van is a standard enclosed cargo body. Each one has different structural reinforcement requirements. Page 17 covers Reinforcement of Van body specifically, so you know where to add extra bracing for heavy loads or liftgate forces.

Where Are the Fuel System Specs in This Manual?

Fuel data lives in the Tank Lorry section, starting page 44. That section covers Fuel Tank Lorry, Water Tank Lorry, Aluminum Tank Lorry, and others. If you’re working on a van truck, the fuel system is on the chassis, not the body. The manual doesn’t duplicate chassis fuel specs, but it does include the mounting interface dimensions for when you need to weld brackets or run fuel lines for auxiliary heaters. The Suspension information shows up under the Liftable Air Suspension section on page 63 – that’s part of the special purpose vehicles, but the air suspension hardware is often retrofitted onto van trucks for load-leveling. The manual covers the control layout and plumbing schematics for that system.

Check the Liftable Air Suspension Section Before You Lift

If you’re adding a liftgate to a Dry Van or Refrigerated Van, you need to know where the air suspension lines run. The manual’s Liftable Air Suspension section (page 63) gives the factory routing and pressure specs. I’ve seen guys pinch a line during liftgate installation and blow an air bag – that’s a $600 mistake. The manual also covers the Liftgate section (page 19) with OEM mounting torque values and hydraulic line routing for the lift mechanism. Pair that with the body reinforcement data on page 17, and you’ve got a complete install plan.

Hyundai’s special vehicle lineup extends beyond vans. According to the Automotive Industry Overview, the market for specialized bodies is growing, and Hyundai offers over 150 models across tank lorries, construction trucks, cranes, and buses. For transmission-related work on any of these vehicles, the Manual Transmission article on Wikipedia provides a solid background on the principles, but for the actual Hyundai van truck transmission disassembly, you’ll want a separate chassis manual.

Source Validity: Why You Want Hyundai’s Own Documentation

Aftermarket manuals for special vehicles are notorious for photocopying outdated pages and calling it a day. This document is a direct OEM publication – you can see the Hyundai logo and address right on page 1. The original file name confirms it: Hyundai_Van_Truck-..._Technical_Manual_en-31713016383.pdf. That’s a Hyundai part number, not a reprint. When the manual says the Refrigerated Van uses 70 mm or 80 mm polystyrene panels, that’s the factory spec, not some third-party guess. You won’t find ‘approximate’ anywhere in these pages. If you need the actual bolt torque for a body mount, it’s in there – you just have to find it. (The manual doesn’t index every torque value, but the diagrams show fastener locations.)

FAQ

Does this manual cover the refrigeration unit itself?

Yes, page 18 covers the refrigerator unit specifications and mounting.

What about the Cool Van – is it the same as the Refrigerated Van?

No. The Cool Van uses passive insulation and a smaller cooling system. The manual has separate specs on page 10.

Can I use this manual to repair the chassis or engine of a Van Truck?

No. This manual is limited to the special body configurations. It does not include powertrain, suspension beyond the liftable air system, or brake systems. You need a separate chassis service manual for those.

Why would a DIY owner need this manual if they’re not building a body from scratch?

If you’re replacing body panels, installing a liftgate, adding insulation, or fixing a leaky roof panel, you need the exact panel thickness, mounting hole locations, and sealant types. This manual has that data from the factory. Aftermarket parts catalogs often don’t specify the reinforcement zones, so you end up welding in the wrong spot. This manual eliminates the guesswork.

You don’t need to chase down a dealer or trust some forum post from 2013. Access the Factory Manual now and get the exact OEM specifications for your Hyundai Van Truck body – whether it’s a Refrigerated, Cool, Insulated, or Dry Van. Keep a copy on your tablet in the shop and save yourself the headache of mismatched parts.
