Dynapac CP132 Parts Catalog – OEM Spare Parts Manual (171 Pages)

If you’ve had a machine down waiting on the wrong part to show up, you know the frustration. This Dynapac CP132 Parts Catalog is what the factory uses to identify every bolt, hose, and seal on your pneumatic tire roller. Guessing part numbers costs you billable hours and sometimes a second restocking fee. This catalog ends that. 171 pages of exploded views and part numbers, straight out of Sweden.

Why a Factory Parts Catalog Matters

Aftermarket parts lists are frequently wrong. They copy old data or skip revisions. This is the genuine Dynapac publication – SCP132-1EN3. Each part number ties to a specific serial number range. Page 3 lists the catalog issue dates and valid serial numbers for the CP132. You match your machine’s serial number to the correct edition. No guesswork, no returns because the part doesn’t fit.

What’s Inside This 171-Page Parts Catalog

Every section breaks the roller down by system. You get exploded line drawings with callouts. Each callout has a part number, description, and quantity. Need the steering cylinder seal kit? Find the assembly group, note the part number, order it. The catalog also includes the Cummins 4BT 3.9C Elite engine groups. If you’re swapping an injector or a water pump, you’ll see exactly which gasket kit to order. No need to measure old parts and hope.

That’s 171 pages of exact part numbers. The document is searchable, so you can jump to the brake system group or the tire ballast section in seconds. Any mechanic who’s turned wrenches on heavy equipment knows the value of an OEM parts breakdown. It saves you the trip to the dealer with a pile of dirty parts on the passenger seat.

Ordering Spare Parts: The Right Way (Page 3)

Page 3 of this Parts Catalog spells out exactly what info you need when you call the parts counter: machine type, roller serial number, quantity, part number, part name, and dimensions for cut-to-length items. Write that down and keep it on the clipboard. If you give the counter guy the serial number from the frame tag, he can cross-reference the correct catalog issue. That keeps you from getting the wrong hydraulic filter or a hose that’s six inches too short.

The catalog also notes which serial numbers each edition covers. For SCP132-1EN3, the valid range is from 21620132 to 21620330. If your roller falls outside that, you need the earlier issue. We also carry the Dynapac CP132 2001 Workshop Manual – Factory Wiring & Electrical Diagrams and the Dynapac CP132 Workshop Manual for repair procedures. Pair the parts catalog with a workshop manual and you’ve got a complete service package.

Know Your Serial Number Range

Before you order anything, locate the serial number on the roller. It’s stamped on the frame near the engine or on the data plate. Compare it to the valid serial numbers listed on page 3 of the catalog. Using the wrong edition means you might get a part that superseded or was replaced. That’s lost time you can’t bill to the customer. The Dynapac CP132 2005 Parts Catalog – Factory OEM Spare Parts Manual covers later machines. Check the range first.

Related Manuals for the CP132

• Dynapac CP132 Workshop Manual – repair procedures, troubleshooting, specs.
• Dynapac CP132 2005 Parts Catalog – Factory OEM Spare Parts Manual – newer edition for later serial numbers.
• Dynapac CP132 2001 Workshop Manual – Factory Wiring & Electrical Diagrams – electrical schematics and wiring harness breakdowns.

For background on how construction equipment parts catalogs are structured across the industry, see the Automotive Industry Overview. The Dynapac official site Dynapac also lists distributor contacts.

Frequently Asked Questions

Can I use this catalog for repair instructions or torque specs?

No. This is a parts identification manual only. You need the workshop manual for repair steps.

How do I know if this catalog covers my specific CP132 roller?

Check the serial number on your machine. Page 3 lists the valid serial number range for this edition: 21620132 to 21620330. If your serial number falls outside that, you need a different catalog issue. We stock the earlier and later editions – verify before you access. Using the wrong edition may result in ordering obsolete or incorrect parts, which can delay repairs and create safety hazards if mismatched components are installed.

Stop chasing parts numbers from worn-out tags. Access the Factory Manual for the Dynapac CP132 and get the exact part data your shop needs to keep that roller rolling.
