Dynapac CA600PD Parts Catalog

I’ve lost count of how many times a shop has tied up a machine for days because someone ordered the wrong gasket or hose. A parts catalog isn’t just a list of numbers—it’s the difference between a job that goes right and a field repair that turns into a disaster. This Dynapac CA600PD Parts Catalog is the real deal: 238 pages of OEM exploded views, part numbers, and ordering procedures. Not aftermarket fluff. Not a reprint of a reprint. Original factory documentation.

Ordering Spare Parts: What You Must Know

Page 4 spells out the six things you need to give your dealer every single time: machine type, roller serial number, quantity, part number, part name, and dimensions if ordering by length. I’ve watched guys skip the serial number and end up with a fuel filter that doesn’t fit the engine revision. The CA600PD went through five catalogue revisions (SCA600PD-1EN1 through 1EN5) between 2004 and 2009. If you ignore the serial number range printed on page 3, you’re gambling with downtime. Don’t guess. Use the numbers.

Engine Coverage: Cummins B5.9-VE-TAA

This vibratory roller runs a Cummins B5.9-VE-TAA diesel. The catalog covers every engine-related part in the exploded diagrams—fuel system, cooling, mounting brackets, the works. You’ll find the exact Dynapac part number listed alongside each component, not a generic cross-reference. That matters when the bolt pattern changed mid-production. One part number, one revision, one call to your parts guy. No second-guessing.

Why OEM Documentation Beats Aftermarket Copies

I’ve had customers bring in aftermarket catalogs that list a part number that was superseded five years ago. The Dynapac factory printed this manual themselves—part of the Atlas Copco Group, based out of Karlskrona, Sweden. Page 2 is blank intentionally; that’s how they handled revision notes. The PDF you get is a direct scan of the original print, not a third-party rekey. You see the exact numbering, the exact Swedish and English text side by side. If you need to verify a bearing number against the machine tag, this is the source you can trust. Check out the official Dynapac site for supporting technical bulletins, but for parts ordering, this catalog is the final word.

Think about the cost of one wrong hydraulic seal. A $15 part plus two hours of labor to tear down the drum again. That’s not a minor expense when the roller is sitting on a grading job with penalty clauses. The 238 pages here are built to prevent that.

7 Systems Covered in the Catalog

The exploded views break the CA600PD into major assemblies. You get part breakdowns for the engine compartment, vibration system, drive train, steering, braking, and electrical harnesses. Each section lists the revision level and the serial number range it applies to. I’ve used this catalog to pin down a misordered drum bearing that had been superseded three times. The page numbers line up with the factory parts numbering system—no guesswork about which figure matches which assembly.

Related Manuals for Your Dynapac Roller

• Dynapac CA600PD Parts Catalog
• Dynapac CA600PD 2009 Parts Catalog – OEM Factory Specs
• Dynapac CA600PD 2011 Parts Catalog – OEM Factory Spare Parts Manual

FAQ: Common Questions on This Parts Catalog

Does this catalog include engine parts for the Cummins B5.9-VE-TAA?

Yes.

How do I order the correct parts if my roller is a different revision?

You need the roller serial number printed on the machine’s identification plate. Turn to page 3 of the catalog—there’s a table listing valid serial number ranges for each catalogue issue (SCA600PD-1EN1 through 1EN5). Match your serial number to the correct issue. Then use the exploded views on subsequent pages to find the part number that corresponds to your revision. If you skip this step and order based on model year alone, you risk getting parts for a different engine calibration or vibration system. I’ve seen it happen: a 2006 machine with a late-2005 harness, but the catalog shows the 2007 revision number. Cross-check every time. The extra five minutes saves you a week of waiting for the right part.

You want to keep your CA600PD running with minimum headaches. That starts with having the right part number in your hand before you pick up the phone. Access the Factory Manual now and stop burning time on parts counter guesswork. For background on why factory documentation matters across the industry, see this Automotive Industry Overview.
