Volkswagen 31.310 Technical Manual – Factory Specs for the 6CTAA 8.3

If you’re working on a Volkswagen 31.310 Technical Manual and reach for a generic aftermarket data sheet, you’re asking for trouble. I’ve seen guys trust a third-party website for injection timing on a Cummins 6CTAA 8.3 and end up with a runaway engine because the number was off by two degrees. This original 13-page document from Volkswagen gives you the exact specs – bore (114 mm, which is 4.49 inches if you need it), stroke (135 mm, 5.31 inches), compression ratio 16.5:1, governor speed at 2200 rpm, and the full injection order: 1-5-3-6-2-4. No reprints. No photocopies. This is the factory file.

Volkswagen 31.310 Technical Manual: What’s Inside the 13 Pages

Page 1 opens with the motor características: manufacturer Cummins, model 6CTAA 8.3 EURO II, inline 6-cylinder, 8.27 liters, net power 303 cv at 2200 rpm (223 kW), max torque 122 kgfm at 1400 rpm (1192 N·m). Page 2 gives you the valve lash – intake 0.30 mm (0.012 in), exhaust 0.61 mm (0.024 in) on a cold engine – and the lubrication system pressure: 375 kPa (3.75 bar, about 54 psi) at 2200 rpm hot. The cooling system thermostat opens at 83°C and fully opens at 95°C. That’s the kind of data you need to set up a fresh rebuild or diagnose a temperature issue.

Engine and Fuel System Specs You Need

The fuel system is direct injection with a Bosch P-7100 inline pump. Injection order is stamped on page 3: 1-5-3-6-2-4. The turbo is a Holset HX 40W with wastegate, air-to-air aftercooling. If you’re pulling this engine apart and need the governor settings or the exact fuel timing, this manual has it. No guesswork. You’ll also find the aspiration type – turbocharged and aftercooled – and the fan drive is viscous clutch. That matters when you’re sourcing replacement parts or checking cooling airflow.

Does This Manual Cover Valve Lash and Transmission?

Yes, and it gives you the cold valve adjustment specs on page 2. But the transmission data is just as detailed. The clutch is an Eaton double-disc organic, 365 mm diameter, hydraulic with air assist, pull-type. The gearbox is an Eaton RT 8908 LL, 10 forward speeds and 2 reverse, with reduction ratios from 19.58:1 in low-low to 1.00:1 in 8th. The rear axle is a Meritor MT 50-168 with reduction options 5.29:1, 5.38:1, or 4.89:1. If you’re swapping differentials or rebuilding the transmission, you need these numbers. Page 4 lays out all ratios.

Front Axle Alignment and Chassis Specs

Page 5 covers the front axle – Meritor or Sifco FF-844, 13,000 lb rating. Caster, camber, toe-in, and turning angles are given with tolerances. For example, caster with load is 3°10’±30′, without load is 3°±30′. Camber without load: left 45’±30′, right 15’±30′. Toe-in: 0.5±0.5 mm. If you’re setting up alignment on a 31.310 chassis, these factory numbers keep the tires from scrubbing off in 10,000 miles. The manual doesn’t include wiring diagrams or body panels – it’s a technical spec sheet, not a full service manual. But for engine, drivetrain, and chassis, it’s the final word.

Audience Fit: Who Benefits from This 13-Page Manual?

If you own a fleet of Volkswagen 31.310 trucks – or you’re a diesel tech who works on them – this manual saves you the time of calling a dealership or trusting a forum post. It’s 13 pages, so it’s not a 2000-page monster. You get the critical numbers: displacement, compression, injection order, valve lash, oil pressure, thermostat range, transmission ratios, axle ratios, and front alignment specs. Beginners can use it to confirm what they’re seeing on the engine tag. Professionals can cross-check their own notes. I’ve been turning wrenches for 28 years, and I still pull factory spec sheets like this one when I’m working on a model I don’t see every day.

Is this manual in English?

The original file is in Spanish. The specs are universal – numbers don’t need translation. But you’ll need basic Spanish or a phone translator for the column headers.

Does it include torque specs?

Not in the scanned pages. You get valve lash and oil pressure, but not head bolt or main bearing torque. For torque values, you need the factory service manual for the 6CTAA engine.

What models does this cover exactly?

It covers the Volkswagen 31.310 chassis with the Cummins 6CTAA 8.3 EURO II engine, Eaton RT 8908 LL transmission, and Meritor axles. Not the 31.320 or later models.

Can I use this for a 31.310 with a different engine?

No. The spec sheet is specific to the Cummins 6CTAA 8.3. If your truck has a different power plant, this manual won’t have the correct data.
