Mitsubishi S4S, S6S Service Manual – Factory Engine Specs

You know what gets under my skin? Watching a guy pull a head bolt torque from a forum post written by someone who owns a socket set and a prayer. That’s how engines come back on a hook. If you are working on a Mitsubishi S4S, S6S Service Manual engine—whether it’s in an excavator, a forklift, or a generator—you need the factory book. Not a reprint. Not a third-party summary. The 241-page PDF that Mitsubishi engineering signed off on. That is what I keep on my bench, and that is what you’re looking at right now.

This manual comes straight from the same source dealers use. Every torque value, every clearance, every step for disassembly and reassembly is printed the way the factory specified it. You want to avoid a scored cylinder wall or a fuel injection pump that won’t time? Follow the book. I’ve seen what happens when someone skips the Safety Cautions (page 1 of the manual) and decides to pressure-test a cooling system cold. You don’t want to be that guy.

Engine Overhaul Coverage: From General to Performance Tests

Section 1 (General) kicks off with the basics—how to use the manual, the safety marks (DANGER, WARNING, CAUTION), and the structure of each group. But the real meat starts with Maintenance Standards and Special Tools. That section lists the factory-specified tools you need before you touch a bolt. Got a torque wrench that hasn’t been calibrated in three years? Don’t bother. The manual expects you to have the right gear. Then Overhaul Instructions walks through Preparation for Disassembly and Disassembly of Main Engine Parts. Every step is numbered, every inspection point is boxed in the exploded views. This isn’t a guide; it’s a procedure.

Fuel System: Removal, Disassembly, and Installation

Section 3 of the manual covers the Fuel system completely. You get removal steps for the injection pump, injectors, and lines. Then disassembly, inspection, and reassembly—all in the same section. I’ve used this section to pull a stuck plunger on an S4S pump without damaging the housing. The manual tells you which shims to measure and what the injection timing should be. If you rely on aftermarket data, you risk getting a spec that’s 2 degrees off. That is a big deal on these direct-injection diesels.

Cooling System: Factory Flow Rates and Bleeding Procedures

The Cooling section (Section 5) is another place where guesswork kills engines. The manual covers removal of the water pump, thermostat, and radiator. It also includes inspection points for impeller wear and thermostat opening temperature. You get the exact torque for the water pump bolts—something that changes between aluminum and cast-iron housings. The manual specifies the coolant bleed sequence for the S4S and S6S. Skip that, and you’ll have air pockets that cause hot spots. I’ve seen it crack a head. Don’t be that guy.

Who Needs This Manual?

If you are a home-garage mechanic wrenching on a Mitsubishi-powered forklift or excavator, this book saves you from having to pull the same job twice. Beginners: this manual shows you where to measure, what to replace, and when to call it. Professionals: you already know that having the OEM Service Manual on your tablet is the difference between a flat-rate win and a warranty comeback. Check the full manual details here.

Source Authenticity: Factory PDF vs. Aftermarket Copies

I’ve bought aftermarket manuals that claimed to cover the S4S and S6S. They had the right photos but wrong torque specs. One book told me to use 90 lb-ft on the connecting rod bolts—factory spec is closer to 50 lb-ft. That kind of mistake costs you bearings. This PDF is a direct scan of the original Mitsubishi publication (Pub.No.99616-10180). It has the safety section, the part numbers, the wear limits. Nothing is interpreted. Nothing is guessed. If you want to work on these engines, you use the same book the factory sent to the dealer network.

3 Reasons to Choose This OEM Documentation

• Every section—Lubrication System, Inlet and Exhaust System, Electrical System—is arranged by removal, inspection, and reassembly. You don’t flip back and forth.
• The Inspection, Adjustment, Break-in Operation and Performance Tests section gives you an after-overhaul checklist that includes compression test pressures and blow-by limits.
• The manual is 241 pages of pure engineering documentation. No reprints. No fluff.

FAQ

Does this manual cover the fuel injection pump timing for both S4S and S6S?

Yes. Section 3 (Fuel System) includes the removal, disassembly, inspection, and reassembly of the injection pump. It specifies the timing marks and the shim thickness for pump installation. You will also find the injection pressure settings for the nozzles. This applies to both inline and distributor-type pumps used on these engines.

Is the cooling system torque data in foot-pounds or Newton-meters?

Both. The manual lists torque in Newton-meters (Nm) and foot-pounds (lb-ft) in the maintenance standards tables. Always cross-check your torque wrench’s scale before tightening any cooling system bolt.
