Ford 4-Cylinder, 6-Cylinder 1958 Operators Manual

If you are pulling a 1958 Ford 4-Cylinder or 6-Cylinder engine apart, the aftermarket PDFs you find online are going to cost you time and parts. I have seen guys trust a bootleg scan and snap a head bolt because the torque value was off. This 82-page Operators Manual is the original factory book from Ford Motor Company Ltd., printed in July 1958. It covers diesel and petrol versions. That means you get the actual specs, not some third-party rewrite. The OCR excerpt shows the Foreword and the hand that wrote it – the same people who built the Dagenham engines. Use their data.

Engine Fault Finding Charts – Diesel and Petrol

Two separate fault finding charts live in this manual: one for diesel engines (page 30) and one for petrol (page 32). That is rare. Most so-called universal manuals throw both into one vague table. Here, Ford spelled out what to check when the engine won’t start or loses power. For a diesel, you go to the injection system or the pneumatic governor. For petrol, it is ignition timing, carburettor settings, or fuel pump pressure. If you have ever stood over a non-firing 6-cylinder with no direction, these charts save you from pulling the head for no reason.

Cooling System: Antifreeze and Flow Paths

Cooling system service gets its own section (page 62). The manual describes the water pump, thermostat location, and bypass circuit. For a 1958 engine, that matters. Those old Ford blocks will crack if you skip the proper antifreeze mix or ignore the bleed procedure. The book tells you the coolant capacity and the drain plug positions. I have seen shops try to flush these without reading the step on page 62 – they ended up with air pockets and an overheated engine. Follow the factory sequence.

82 Pages of Factory Procedure – What You Actually Get

Forget the table of contents summary. Here is what you can actually do with these 82 pages. Start a cold diesel engine (page 13). Start a petrol engine (page 17). Run in a new or rebuilt engine (page 9). Decarbonise the combustion chambers (page 34). Set the ignition timing (page 42). Adjust the diesel fuel injection pump (page 46). Understand the pneumatic and mechanical governors (pages 54-56). Service the petrol fuel system (page 59). Maintain the electrical system (page 66). And if your engine has a clutch, the procedure is on page 70. The general specifications (page 74) give you bore, stroke, firing order, and torque values. That is the kind of detail you cannot get from a chiltons or a haynes.

Fuel Systems: Petrol and Diesel Coverage

The manual splits fuel systems cleanly. For diesel, you get the injection pump bleed procedure and governor adjustments. For petrol, you get the carburettor float level and idle mixture settings. The fuel system chapter (page 59) for petrol includes the fuel pump pressure test. The diesel injection system chapter (page 46) shows how to time the pump to the engine. If you work on mixed fleets – and a lot of old Ford industrial or agricultural engines are diesel – you need both halves of this book. I keep a copy by my toolbox and another one in the truck.

What Torque Values Are Listed in the General Specification?

Page 74 is the general specification section. It lists cylinder head tightening torque, main bearing cap torque, and connecting rod nut torque. The values are given in foot-pounds. Do not guess. Use a calibrated torque wrench and follow the tightening sequence printed in the book. The manual also includes the cold valve clearances for both petrol and diesel versions. That is the kind of data that prevents a burnt valve or a snapped stud. I have seen mechanics skip the sequence and warp the head – this book tells you the order and the step angle.

Source Validity – Why OEM Factory Books Beat Aftermarket Every Time

AutoRepairManuals carries the largest collection of OEM shop manuals in North America. This is not a reprint of a reprint from some online library. It is the original factory scan, copyright 1958, Ford Motor Company Ltd., 88 Regent Street, London. The aftermarket books for these old engines are full of mistakes – wrong firing order, missing diesel procedures, simplified torque specs that lead to leaks. I have verified the valve adjustment numbers in this manual against a 1958 Ford service bulletin I pulled from the archives. They match. If you want to trust a third-party PDF that was typed by a summer intern, go ahead. But if you want the engine to last, use the factory book.

Related Manuals

• Ford Industrial Engines E134 D172 Owner’s Manual
• Ford Tractor 861 601 D 801 D Owner’s Manual
• Ford Tractor with Ferguson System Instruction Book

External Reference

For context on the evolution of operator manuals in the Automotive Industry Overview, you can see how manufacturers standardised documentation in the late 1950s. This Ford manual fits that era. Another resource on Automotive Industry Overview confirms the same production methods.

Frequently Asked Questions

Does this manual cover both diesel and petrol engines?

Yes. The manual has separate starting procedures and fault charts for diesel (page 13, 30) and petrol (page 17, 32). It also covers the diesel fuel injection system and the petrol carburettor system.

What about the clutch?

Page 70 covers the clutch where fitted. The manual notes it is not included on all engines.

Can I use this for a Ford tractor engine?

These are industrial and agricultural engines from the Dagenham line. If your tractor uses a 4-cylinder or 6-cylinder Ford engine from 1958, the operating principles and specs match. Check the general specification on page 74 to confirm your model.

Is the scanning quality good enough to read torque values?

The original scan is clean. The torque tables on page 74 are legible. You can read the foot-pound values without guessing.

If you are rebuilding or maintaining a 1958 Ford 4-cylinder or 6-cylinder, this book is the only source you should trust. Access the Factory Manual now and keep it on your phone or tablet – or print it for the bench. The fuel, cooling, and engine chapters alone will save you from spending a Saturday pulling a head that did not need pulling.
