Dynapac CG233HF Parts Catalog – 252-Page Factory Document for Spare Parts Ordering

I’m Mike Callahan, and I’ve been wrenching for 28 years. When you’re ordering parts for a Dynapac CG233HF, the last thing you want is to guess the part number and end up with a seal kit that doesn’t match your machine’s serial number. That’s why you need the Dynapac CG233HF Parts Catalog. This is a 252-page OEM document, straight from the factory, with exploded views, part numbers, denominations, and ordering instructions. It covers the vibratory roller with Deutz BF4M 2011 / TD2011 L04W diesel engines, and it’s indexed for serial numbers from *86110400* onward. Aftermarket parts lists? Don’t trust them. This catalog is the only source that matches every bolt, clamp, and hose to the production line.

What’s Inside the 252-Page Parts Catalog

Each group in the catalog is broken down by machine system. You get part numbers, quantities, and dimensions for everything from the vibration system to the engine mounts. The ordering section on page 4 spells it out: you need the machine type, roller serial number, quantity, part number, parts denomination, and dimensions when ordering a length item. No shortcuts. The manual also includes change notes and service info page references so you can cross-check against the latest revisions. I’ve used these books for decades, and I can tell you—if the part number doesn’t match what’s in this catalog, it’s the wrong part.

3 Reasons to Use OEM Parts Data Instead of Aftermarket Lists

First, aftermarket catalogs frequently miss supersessions. Dynapac updates part numbers without fanfare, and the factory catalog captures those changes. Second, the exploded views show exactly how each component fits into the assembly—something a generic list can’t do. Third, the dimensions in the manual are in millimeters and inches; when you order a meter of hose, you need the correct inside diameter and length. I’ve seen a mechanic order a ⅜” hose when the machine needed a ½” because he used a third-party cross-reference. That mistake costs half a day and a return shipping fee. Stick with the OEM source.

Ordering Parts: The Information You Need to Provide

Flip to the front of the catalog—page 4—and you’ll see the six pieces of information Dynapac requires for an accurate order. It’s printed in Swedish, English, German, Italian, Spanish, and French. The roller serial number is critical: this catalog applies starting from serial *86110400*. If you have an earlier machine, you need a different edition. Don’t skip the denomination field either—a “screw” can be M8x25 or M10x30, and the catalog tells you which one. When you call your dealer, have the part number from this manual ready. It saves you the frustration of “we need more info” emails.

Does This Manual Cover Engine and Hydraulic Components?

Yes. The catalog includes the complete breakdown for the Deutz BF4M 2011 and TD2011 L04W diesel engines, plus the hydraulic system that drives the vibration and steering. You’ll find the pump, motor, valves, and hoses all illustrated with callouts. If you need to identify a seal kit or a filter, the part number is right there. This isn’t a service manual—it won’t tell you how to rebuild the pump—but it will tell you exactly which O-ring ring kit to order. For repair procedures, pair this catalog with Dynapac CG233HF 2006 Technical Manual – Factory Specs for Vibratory Roller.

How to Use the Manual on the Job

Keep this PDF open on a tablet or printed out in the shop. When a customer brings in a CG233HF with a leaky hydraulic hose, pull up the exploded view for the hydraulic group. Identify the hose by its position in the diagram, note the part number, and verify the length from the dimension column. Place the order with the dealer using the information from page 4. You’ll get the correct part the first time. I also recommend checking the Dynapac PL2000LS Parts Catalog (258 Pages) – OEM Factory Spec and Dynapac PL2000LS Parts Catalog – Factory OEM Specs for Cold Planer if you work on other Dynapac models—they follow the same numbering logic.

The catalog is published by Dynapac, part of the Atlas Copco Group, and you can find official updates on their Dynapac website. For a broader understanding of heavy equipment documentation standards, you can reference the Automotive Industry Overview. But for your everyday parts ordering on the CG233HF, this 252-page Parts Catalog is the only tool you need.

Frequently Asked Questions

What type of machine does this catalog cover?

The Dynapac CG233HF vibratory roller.

Does this include torque specs or repair procedures?

This is a parts catalog, not a service manual. It contains exploded view diagrams with part numbers, quantities, and order information. For torque specs and repair procedures, you need the Dynapac CG233HF technical manual Dynapac CG233HF 2006 Technical Manual – Factory Specs for Vibratory Roller.

What serial number range does this catalog apply to?

Valid from roller serial number *86110400* onward. Earlier models may use different parts.

Can I use this to order parts for other models?

No, it’s model-specific.

Access the Factory Manual. Get the 252-page Dynapac CG233HF Parts Catalog in PDF format and start ordering parts correctly.
