Dynapac CC2200C 2015 Parts Catalog – Factory OEM Spare Parts List

If you’re turning wrenches on a CC2200C vibratory roller, you’ve been burned by aftermarket catalogs that list the wrong part number. I have. Wastes a day and kills billable hours. This is the actual factory document. 540 pages of exploded views and part numbers that Dynapac uses on the line. No guessing. No cross-references that lead to a dead end. You open to the right section, find the part number, order it, and move on. That’s the job.

Front Frame: Steering Cylinder and Articulated Joint Illustrated

The front frame section starts on page 29. You get the steering cylinder (part 4700391023), the articulated joint (4812117737), tank structure module, hitch module, and all the brackets and hoses. I’ve seen guys order the wrong steering cylinder because they eyeballed it. This catalog gives you the exact exploded view with callouts. If you need the battery box, it’s on page 73 — part 4812114521. No scrolling through generic diagrams.

540 Pages of Factory Part Numbers – No Aftermarket Guesswork

540 pages is not a PDF you skim. It’s thick because every bolt, hose, bracket, and gasket is accounted for. Service kits from 50-hour to 1000-hour intervals are listed with their individual part numbers. Repair kits for the eccentric shaft (4812155792), drum rotation (4700938891), scraper (4812155791), and sprinkler system (4812155698). If you’re rebuilding a drum, you need the drum bearing and drive unit sections. This catalog has them. The start-up kit (4812159672) is also in there. You don’t guess which filter bundle you need; you look up the kit number and order it.

For a similar cold planer parts catalog, see Dynapac PL2000LS Parts Catalog (258 Pages) – OEM Factory Spec. It follows the same factory format, but for a different machine.

Engine and Hydraulic System: Full Parts Breakdown

The engine section covers the Deutz TCD3.6 L04 IIIB/T4i — part number 4812114075. Air cleaner, exhaust pipe, charge air cooler, water cooler, coolant hoses, belt guard. Every component has a part number. The hydraulic system is split into front drum, frame, and engine room. You get the fan assembly, hydraulic pump mod, and all the hoses. Sprinkler system is also covered: pump module, emulsion tank, water hoses, backup pump. If the sprinkler system on your CC2200C is leaking, you can trace the line to the exact part.

Service Kits: Order the Right One the First Time

Service kits are a common source of confusion. The 50h Plus kit (4812159352) is different from the 500h kit (4812159381). The 1000h Plus kit (4812159384) includes additional items. This catalog lists the contents of each kit. You can verify you’re ordering the correct interval kit. Don’t trust a third-party website that says “compatible.” Use the factory numbers. If you’re working on a cold planer as well, Dynapac PL2000LS Parts Catalog – Factory OEM Specs for Cold Planer has the same level of detail for the PL2000LS.

Does This Catalog Cover Your Machine?

This catalog covers the **Dynapac CC2200C** with serial number range 10000337x FA015716 and up, with the IIIB/T4i engine emission level. If your machine has an earlier engine or a different serial range, you need the correct version. Check your machine’s serial plate before ordering. The 2015 publication year matches the IIIB/T4i emission standard for North America. For a complete listing of OEM spare parts for the PL2000LS cold planer, Dynapac PL2000LS Parts Catalog – OEM Spare Parts Listings is available.

Dynapac has been part of the Dynapac group for decades. Their documentation is consistent across models. This catalog follows the same format as the Automotive Industry Overview standards for heavy equipment parts catalogs.

FAQ

What serial numbers does this catalog cover?

Serial numbers starting from 10000337x FA015716 and above. If your machine is earlier, you need a different catalog.

Does this include torque specifications?

No. This is a parts catalog, not a service manual. For torque specs, you need the service and operating instructions.

Can I use this for the CC2200C with a Tier 4 Final engine?

No. This catalog is specifically for the IIIB/T4i engine (Deutz TCD3.6 L04). Tier 4 Final machines have different part numbers for emissions components. Verify your machine’s engine tier before ordering.

Is this a reprint or a scanned copy?

It’s an original OEM factory PDF, not a reprint or third-party copy. The same document Dynapac distributors use. No blurry scans. 540 pages of clean, legible part numbers.

You need this catalog if you’re rebuilding a CC2200C or ordering any part for it. Access the Factory Manual from AutoRepairManuals and keep your shop running without the guesswork.
