Dynapac CC1000 Parts Catalog – Factory OEM Spare Parts Guide

If you’re ordering parts for a Dynapac CC1000 vibratory roller and you don’t have the factory parts catalog in your hand, you’re going to get the wrong part. I’ve seen it happen. Some kid pulls a number from an aftermarket PDF that’s been photocopied three times, and suddenly the roller sits dead for a week waiting for a return. This catalog is 150 pages of the actual Dynapac print – the one they use in Karlskrona, Sweden. It covers the Dynapac CC1000 Parts Catalog from serial number 90132700 onward, with the Perkins 403D-11 diesel engine and all the vibratory, hydraulic, and frame breakdowns you need. No guesswork. You get the part number, the denomination, and the exploded view that shows you exactly where it lives.

Page 4 in this catalog shows the ordering instructions in six languages. That’s not filler. That’s the step sequence they use to avoid screw-ups: machine type, serial number, quantity, part number, denomination, dimensions. If you skip step two – the serial number – you could order a roller drum bearing that doesn’t fit. I’ve seen it happen. The manual also lists the catalogue issue dates and which serial numbers each revision covers (SCC1000-2EN3 covers serial numbers from 2009-12 onward). That matters because Dynapac changed the frame mounting brackets between revisions. You need the right revision.

Engine Components – Perkins 403D-11

The diesel engine section breaks down every gasket, injector, and mounting bolt for the Perkins 403D-11. You get the full exploded view with part numbers that cross-reference directly to Perkins OEM stock. No aftermarket “equivalent” that’s off by 0.5 mm. I’ve had a shop hand me a generic fuel filter that didn’t seat because the thread pitch was different. That doesn’t happen when you order from the catalog. The part number listed here is the one Dynapac stamped on the build sheet. Use it.

Hydraulic System Breakdown

Hydraulics on the CC1000 use a gear pump and a tandem valve bank. The catalog shows each cartridge, O-ring, and hose assembly with dimensions. When you’re rebuilding the propel pump, you need the seal kit number – it’s in the hydraulic section. Don’t guess the O-ring cross-section. The manual gives you the exact part number for the kit. Order it once.

Roller Drum and Vibratory Assembly

This section is where most of the wear parts live – eccentric weights, bearings, seals, and the drum shell itself. The exploded diagram shows the order of assembly, so you can see which shim goes where. If you’re replacing the vibratory bearing, you need the correct inner race size. The catalog lists it. Also includes the drum isolation mounts and the scrapers. Page references: the vibratory assembly starts after the engine section. I won’t give you a page number because the catalog layout is grouped by system, not page sequence. You flip to the vibratory group, and it’s all there.

Frame, Chassis, and Operator Platform

The frame section covers the articulation joint, steering cylinder mounts, and the ROPS structure. If you’re repairing a cracked frame gusset, you need the weld-on bracket part number – it’s here. Also includes the operator’s platform: seat base, floor plate, control levers, and the gauge panel. Each item has a part number and a reference to the assembly drawing.

Electrical System – Wiring and Connectors

Wiring diagrams aren’t included – this is a parts catalog, not a service manual. But you get the part numbers for the harness assemblies, connectors, and relays. If you need a replacement harness for the CC1000, you look up the serial number, then find the harness group. That prevents ordering a harness that’s two inches too short because the frame revision changed the routing.

Ordering Spare Parts Correctly – Page 4 Covers This

Page 4 of the catalog has a six-step ordering checklist. Six steps. That’s it. Type of machine, serial number, quantity, part number, denomination, dimensions. I’ve watched guys skip the serial number step and get a part that doesn’t fit. Then they blame the catalog. Don’t be that guy. This manual also includes the catalogue issue dates – so you know which revision your machine needs. If your CC1000 was built in 2008, you need the SCC1000-2EN1 issue. This specific catalog is SCC1000-2EN3, valid for serial numbers from 2009-12 onward. Verify your serial before you order.

Related manuals you might need for your shop:

• Dynapac CC1000 2015 Parts Catalog
• Dynapac CC1000 Parts Catalog
• Dynapac CC1000 Spare Parts Catalogue

For more about the manufacturer, visit Dynapac official site. And if you want the broader context of how OEM specs protect your liability, read Automotive Industry Overview on Wikipedia.

3 Reasons to Choose OEM Documentation

First, the part numbers come directly from Dynapac’s engineering database – not a third-party guess. Second, the exploded diagrams show the correct assembly order and orientation of seals, bearings, and fasteners. Third, the revision history tells you exactly which serial numbers each issue covers, so you don’t order a part that was changed in a later build. Aftermarket catalogs don’t give you that.

FAQ – Common Questions About the Dynapac CC1000 Parts Catalog

Does this catalog include torque specs?

No. This is a parts catalog, not a service manual. It lists part numbers and exploded views. For torque values, you need the Dynapac CC1000 workshop manual – we carry that separately.

How do I find the correct part for my specific roller serial number?

Look at page 3 of the catalog. It lists the catalogue issue date and the valid serial number range for each edition. If your roller serial falls within the range listed for SCC1000-2EN3 (from 2009-12 onward), this is the right manual. If not, go back to the earlier issue.

Can I order parts directly from this catalog?

Yes. The catalog gives you the part number, denomination, and dimensions. Take that to your Dynapac dealer. The ordering instructions on page 4 walk you through exactly what to tell them.

What engine is covered?

Perkins 403D-11 diesel. The catalog shows all engine components – cylinder head, fuel system, cooling, and mounts – with Dynapac part numbers.

If you need to keep that CC1000 running without chasing wrong part numbers, stop piecing together internet lists. Get the actual factory print. Access the Factory Manual and keep it on your shop tablet. 150 pages of OEM parts data beats a phone photo of a greasy serial plate every time.
