Dynapac CA152PD Parts Catalog – 372 Pages of Factory Parts Data

I’ve lost count of how many times a rookie has come to me with a wrong part because he ordered from a third-party listing that didn’t match the serial number. That’s money down the drain and machine downtime you can’t get back. The Dynapac CA152PD Parts Catalog slaps the information you need on page 3: the exact serial number range your roller falls into, and which catalogue issue applies. No guesswork.

Ordering Spare Parts: The 6 Things You Must Get Right

Page 4 of this Parts Catalog lays out the ordering procedure in no uncertain terms. You need six pieces of data: machine type, roller serial number, quantity, part number, parts denomination, and dimensions if ordering by length. Miss one, and you’re liable to get a box of wrong hardware. I’ve seen it happen with a hydraulic pump seal – the guy typed the model wrong and ended up with a seal that didn’t even fit the mounting flange. With this Dynapac CA152PD manual, you align the part number with the exploded view. That’s the only way to be sure.

Vibratory Roller CA152PD – Engine and Serial Number Cross-Reference

The manual opens with the Cummins 4BT 3.9C Elite engine designation and lists the five catalogue issues from SCA152PD-1EN1 through -1EN5, each with its valid-from date and serial number break. If your roller’s serial number starts with 64320167, you need the -1EN5 edition. That’s the one in this 372-page PDF. Without that cross-reference, you risk ordering a part that was superseded three revisions ago. I don’t care how good your memory is – factory documentation is the only way to track those changes.

Parts Service Information: What the Notes Pages Tell You

Page 5 of the catalog includes a notes section with group and page references for service info. That might sound minor, but when you’re searching for a specific bearing or seal, those notes flag superseded part numbers or special tool requirements. The Parts Catalog is not a service manual – it won’t tell you torque specs – but it does tell you which fastener goes where and whether a part has been replaced. That saves you a return call to the dealer.

Does This Catalog Cover Your CA152PD Serial Range?

This edition covers rollers from serial number 64320167 onward (the -1EN5 release, dated 2003-04). If your machine falls outside that range, you’ll need the earlier catalogue issue. Check Dynapac CA152PD 2009 Parts Catalog – Genuine OEM Spare Parts Guide for the later publication, or Dynapac CA152PD Parts Catalog – OEM Factory Specifications | 372 Pages for the same base reference. I always keep a copy of the correct edition in the shop binder – you should too.

Why Factory Parts Catalogs Beat Aftermarket Listings

Aftermarket parts websites love to slap a generic part number on a diagram and call it good. Then you install the part and the bolt holes don’t line up. This Dynapac catalog comes straight from Metso Dynapac AB in Karlskrona, Sweden – the same people who built the machine. Every part number, every illustration, every note is verified against the roller’s original engineering drawings. You want to trust the official Dynapac source for your equipment. For background on why OEM documentation matters, read the Automotive Industry Overview – the principles apply to construction gear just as hard.

If your PL2000LS needs the same treatment, grab Dynapac PL2000LS Parts Catalog (258 Pages) – OEM Factory Spec. Different machine, same philosophy.

FAQ – Two Questions You’re Going to Ask

Does this catalog include torque specs or repair procedures?

No. This is a parts catalog, not a service manual. It lists part numbers and diagrams – not torque values or step-by-step repairs.

How do I order parts correctly using this manual?

Start by confirming your roller’s serial number on page 3 to match the catalogue issue. Then turn to the section for the assembly you’re working on (e.g., vibratory system, engine, frame). Identify the part in the exploded diagram, note its part number, and cross-reference it with the accompanying table. When you call the dealer, you give them: machine type (CA152PD), roller serial number, quantity, part number, part name, and dimensions if the part is sold by length. That’s the procedure spelled out on page 4. Follow it and you will get the right part every time. I’ve used it for two decades – it never fails when you use the correct catalogue issue.

Stop burning money on wrong parts and machine downtime. Access the Factory Manual and keep a copy in your tool box.
