Cub Cadet 782, 1711, 1712, 784 Parts Catalog

You have a Cub Cadet 782 on the lift with a missing air cleaner cover. The local dealer wants a serial number. The aftermarket book in the drawer shows a part that looks right but the bolt holes don’t line up. Been there. That wasted hour buying the wrong part is why you need this factory parts catalog. Not a generic listing scraped from some database. This is the original 119-page PDF that the dealer parts counter uses – 1711, 1712, 782, 784 models from the factory line. Every part number, every exploded view, every serial number split. No reprints, no third-party editing.

Trust OEM Part Numbers Only

I have seen guys order a carburetor gasket set using a part number from an online forum. Then they wonder why the stud pattern is off by half a millimeter. This catalog gives you the exact IH and KH prefix numbers that came off the assembly line. Page 4 shows the air cleaner and breather for tractors with serial number 669970 and below. Page 1 covers the A-frame hitch adapter for units with serial 720000 and up. That serial number split is the difference between a bolt-on and a weld-on job. You do not guess with tractor parts unless you like making two trips to the hardware store.

What’s Covered in the 119-Page Breakdown

The book is organized by assembly – hitch, air cleaner, engine components, electrical. Each section has a figure number and a table with reference numbers, part numbers, quantities, and descriptions. For example, the air cleaner section (page 3 and 4) lists the wing nut (KH-X-276-7), the cover (KH-52-082-02), and the element (759-3547). When you need a precleaner element for a 1712, you see ref #7: KH-52-083-01. That is the factory number. Cross-check it with the dealer or order direct. No ambiguity.

Cub Cadet 782, 1711, 1712, 784 Parts Catalog: What You Get

Four model families in one document. The 782 is a popular garden tractor with a Kohler engine. The 1711 and 1712 are diesel models that share many chassis parts. The 784 is another variant. This catalog covers all of them, with separate sections for different serial number ranges. You get the official exploded drawings with callouts. You get the hardware specifications – lock washers, jam nuts, grade 5 bolts. That matters when you are torquing a hitch pin to spec and the aftermarket nut strips at half the value.

Air Cleaner Assembly: Serial Number Splits

Pay attention to the serial number breaks. Tractors with serial 669970 and below use a different air cleaner base and breather hose than those with 779971 and up. Page 5 shows the later design. If you own a 782 built in 1982, you need to check your serial plate. Ordering the wrong base gasket (KH-52-055-04) will cause a vacuum leak. The catalog flags superseded parts – the gasket replaces IH-79320-C2. That kind of detail saves you from buying obsolete stock.

Real-World Use: Ordering the Right Air Filter Element

Let’s say your 1711 is blowing black smoke. You pull the air cleaner cover and the foam precleaner is disintegrating. You flip to the air cleaner section, find your serial range, and see ref #7: precleaner element KH-52-083-01. You call the parts house, give them that number, and get the correct filter. No more “is this the right one?” The catalog also lists the breather kit (KH-52-755-09) that comes with the umbrella valve. If your engine is puking oil out the breather, you replace the whole kit, not just the valve. That is the factory procedure.

Source Authenticity: OEM vs Aftermarket Parts Books

I have seen aftermarket parts catalogs that combine multiple brands into one jpeg. The part numbers are sometimes correct, sometimes a supersession that doesn’t match the original bolt pattern. This Cub Cadet catalog is original manufacturer documentation. The Part Number column is the exact number stamped on the factory bin. When it says “IH-106998-C1 Pin”, that is the pin your grandfather’s tractor came with. The “S/P/F” column tells you if the part is serviceable, a package, or frame. That data comes from the engineering release, not from someone eyeballing a photo.

3 Reasons to Choose This Factory Catalog

One: serial-number-specific part lists eliminate the “will this fit?” doubt. Two: original part numbers let you cross-reference with current inventory. Three: the exploded views show how assemblies go together – handy when you have a bag of leftover bolts and no memory of which hole they go in.

Related manuals you should consider: Cub Cadet 1512 882 782 Parts Catalog if you work on the lighter-frame models. For the newer hydrostatic tractors, grab Cub Cadet 21121C29025 Parts Catalog – 73 Pages of Factory Specs. And if you need the dedicated 984 series breakdown, Cub Cadet 984 Parts Catalog – 128 Pages of OEM Factory Parts Breakdowns.

For general background on tractor manufacturing standards, see Automotive Industry Overview. The same engineering rigor applies to garden tractors. For a deeper dive into industry parts numbering systems, Automotive Industry Overview covers the logic behind part number supersession.

Does this manual include torque specs or engine rebuild data?

No. This is a parts catalog, not a service manual. It lists part numbers and exploded views, not torque values or repair procedures.

Can I use this to identify parts for my 782 with serial number above 720000?

Yes. The catalog splits sections by serial number break points. For the A-frame hitch, page 1 covers SN 720000 and up. For the air cleaner, two different serial ranges are shown. You must locate your tractor’s serial number and match it to the correct figure. If your 782 falls between the breaks, check both sections – some parts carry over, but fasteners may change. The catalog also lists supersessions, so if a part is NLA (no longer available), the note tells you. Always verify your serial plate before ordering. That single step prevents the most common ordering mistake I see in the shop.

When you are tired of playing part-number roulette with generic listings, get the real thing. Access the Factory Manual and keep it on your bench or tablet. One lookup and you know exactly which nut, which gasket, which filter belongs on your Cub Cadet 782, 1711, 1712, or 784. No fluff, no reprints, just the OEM data that keeps the tractor running.
