Cub Cadet 466 Parts Catalog – Factory Specs for the 466 Diesel 4X4

If you are wrenching on a Cub Cadet 466 Diesel 4X4 Utility Vehicle and need to track down a specific part number, you already know the headache of guessing. Aftermarket cross-reference lists get the thread pitch wrong, or the bolt length is off by a quarter inch. That is why this Parts Catalog exists. It is the same 63-page document the dealer uses when you call 606-678-9623 or 606-561-4983 for discount Cub Cadet parts. Every ref number, every part number, every description is pulled straight from the factory floor.

This catalog covers serial numbers 11018G through 11019G. That is a narrow production window, which means the parts listed here match your machine exactly. No generic “fits all models” nonsense. You get exploded-view diagrams for the axles and steering system, plus the full parts breakdown for the rear housing, brake calipers, CV joints, and sway bar mounts. Page 2 alone lists 37 individual components for the rear axle assembly, including the differential seal (921-04005) and the CV boot kit (731-05083).

Axles & Steering – 63 Pages of Factory Data

The bulk of this catalog is dedicated to the axle and steering assemblies. You get the complete rear housing (619-04188), the CV joint axle assembly (611-04063A), and the upper and lower control arm assemblies for both the right and left rear. Each part is tagged with a ref number, a factory part number, a quantity, and a description. The “S/P/F” column tells you if it is a service part, a production part, or a field replacement. That matters when you are ordering a brake disc (707-04436A) or a hub assembly (918-04489).

Need the sway bar bushings? Ref 27, part 731-05352. The shock absorbers? Ref 28, part 732-04423, 5.0 stroke rear. Every fastener is listed with its grade and thread size — screw 3/8-16, 4.00, grade 5 (ref 16) is not the same as screw 3/8-16, 3.00, grade 8 (ref 14). The catalog does not let you mix them up.

Does This Manual Cover the Fuel System or Engine?

This is a Parts Catalog, not a service manual. It does not include step-by-step repair procedures, torque specs, or troubleshooting flowcharts. What it does give you is the exact part number for every nut, bolt, seal, bearing, and assembly on the axles and steering system. If you are rebuilding the rear differential or replacing a CV boot, you need this catalog to order the correct parts. For engine overhaul or hydraulic system diagnostics, you will want the separate service manual. But for parts identification, this is the only source that matches the factory build sheet.

3 Reasons to Choose OEM Documentation Over Aftermarket

First, aftermarket parts catalogs often combine multiple model years into one document, which leads to wrong part numbers. This catalog is specific to the 466 Diesel 4X4 with S/N 11018G-11019G. Second, the exploded-view diagrams show exactly how components fit together — the orientation of the hog ring (759-04173) on the CV joint, the placement of the brake hose (927-04228), the routing of the sway bar link. Third, the part numbers are verified by the manufacturer. When you call the discount Cub Cadet parts line, they will ask for the ref number from this catalog. That saves you the back-and-forth of “Is this the right seal?”

I have seen too many DIYers order a brake caliper for the wrong side because the aftermarket catalog did not specify LH vs RH. This catalog lists the RH caliper as ref 37, part 961-04043, and the LH as ref 37, part 961-04044. Clear as day.

Who Needs This Catalog?

If you own a Cub Cadet 466 Diesel 4X4 Utility Vehicle and plan to maintain it yourself, this catalog is your parts bible. Home garage enthusiasts who want to rebuild the rear axle or replace the steering components will save hours of cross-referencing. Professional mechanics working on these machines in a shop will appreciate having the factory part numbers on hand instead of calling the dealer every time. Even if you are just ordering a set of brake pads (ref 37, kit 761-04064), having the correct part number means the difference between a one-day job and a week of returns.

For related manuals, check the Cub Cadet 466 Parts Catalog for the full utility vehicle lineup, or the Cub Cadet 466 Utility Vehicle Parts Catalog for additional diagrams. If you need a broader reference, the Cub Cadet 21121C29025 Parts Catalog – 73 Pages of Factory Specs covers a different model range but follows the same factory format.

Source Validity – Why This Is Not a Reprint

This is a direct scan of the original factory document, not a third-party compilation. The watermark on every page reads “www.mymowerparts.com” and the header includes the discount parts phone number. That is the same document the dealer network uses. Aftermarket parts catalogs often omit the “S/P/F” column or combine multiple revisions into one file. This catalog preserves the original layout, including the exploded-view diagrams with ref numbers that match the parts list. If you have ever tried to use a generic parts list and ended up with the wrong bolt grade, you understand why this matters.

For a broader look at how OEM documentation fits into the Automotive Industry Overview, factory parts catalogs are the foundation of accurate repairs. The same principle applies here — the Automotive Industry Overview confirms that OEM data reduces error rates in parts ordering.

Frequently Asked Questions

Does this catalog include torque specifications for the axle bolts?

No. This is a parts catalog, not a service manual. It lists part numbers and quantities only. Torque specs are found in the factory service manual for the 466.

Will this catalog help me identify the correct CV joint for my 466 Diesel 4X4?

Yes. The CV joint axle assembly is listed as ref 4, part 611-04063A, with separate part numbers for the differential-side boot (731-05082) and the wheel-side boot (731-05083). The exploded diagram on page 2 shows the exact orientation of the hog ring and the CV boot clamps. If you are replacing a torn boot, you can order the boot kit by itself instead of the entire axle assembly. The catalog also lists the axle shaft seal (921-04005) and the differential lock actuator seal (721-0212) — both common failure points on high-hour machines. Ordering the wrong seal diameter is a common mistake; this catalog gives you the .375 ID spec for the actuator seal and the 1.0 x 62mm x .375 spec for the input shaft seal. That level of detail is why you want the factory document on your bench.

Stop wasting time with aftermarket parts lists that leave you guessing. Access the Factory Manual and get the exact part numbers for your Cub Cadet 466 Diesel 4X4 Utility Vehicle.
