Caterpillar C175, 3600, C8.7, C12.9 Service Manual

You’ve got a Caterpillar C175, 3600, C8.7, C12.9 Service Manual in front of you — and if you’ve ever torqued a head bolt using a guess or a third-party spec, you know exactly why this thing exists. I’ve seen a cylinder liner walk because a tech used the wrong tool for a liner seal. That’s a $4,000 mistake. This manual stops that. It’s the Dealer Service Tools Catalog from Caterpillar, July 2017, covering every specialty tool and procedure for these four engine families. No aftermarket rehash. Factory-issued, 1706 pages of what you need to pull the job right the first time.

Engine Tools: 3600, C8.7, C12.9, and C175 Specific Sections

Flip to the Engine Tools chapter. You’ll find dedicated subsections for each of the four engine models: 3600 Engine Tools, C8.7 Engine Tools, C12.9 Engine Tools, and C175 Engine Tools. Each subsection lists the required pulling, lifting, and specialty tools — part numbers included. Need a cylinder block liner tool for a 3600? It’s in there. Camshaft timing gear tools for a C175? Covered. The manual also groups tools by system: Cylinder Head, Valves and Cam Followers; Crankshaft, Main Bearings and Flywheel; Cooling Systems; Fuel Systems; Lube Systems; Pistons, Rings and Connecting Rods. If you’re rebuilding an engine, you work through these sections with the exact tool list Cat expects you to have. Skip that, and you’re gambling with alignment and seal integrity.

Electrical Tools and Electronic Engine Diagnostics

The Diagnostic Tools chapter opens with Electrical Tools (section 1-1) and Tools for Electronic Engines (section 1-39). These aren’t generic multimeter instructions — they’re factory procedures for testing sensors, injectors, and control modules on the C8.7 and C12.9 electronic platforms. Speed-measuring tools, temperature-measuring tools, and flow tools are all specced out. If you’re chasing an intermittent fault on a C175, the manual shows which breakout harness and diagnostic adapter to use. Aftermarket manuals usually skip this. This one doesn’t.

What Torque Values Are Listed?

This is a service tool catalog, so torque values aren’t listed per bolt — but the torque tools are. You get the factory-recommended torque wrenches, click-type and dial-type, with ranges for every fastener on these engines. Section Hand Tools > Torque Tools lists every part number. Combine that with a factory engine rebuild manual for the torque specs, and you’re set. The clickable subject index at the back (also bookmarked in the PDF) lets you jump straight to any tool by name. No flipping through pages blindly.

3 Reasons to Trust OEM Documentation Over Aftermarket

First, third-party reprints often crop out tool part numbers. This manual keeps every factory part number intact. Second, aftermarket catalogs substitute generic tools that might not fit the Cat thread pitch or clearance. The OEM listings tell you exactly which puller, which adapter, which hydraulic cylinder. Third, the safety warnings about load capacities and pressure limits are written by the people who built the engine. When the manual says “do not exceed 10,000 psi on this cylinder,” they mean it. Trust the factory originals.

Get the Right Tool for the Job

You’re pulling a piston on a 3600? You need the specific driver listed under 3600 Engine Tools. Doing an air induction service? Air Induction has its own subsection with tool part numbers. The manual even covers shop supplies — caps, plugs, cleaning equipment, personal protective equipment. It’s not just an engine manual; it’s the complete tool catalog for the entire shop. Manual Transmission tools? They’re in the Power Train Tools chapter under Drive Line and Axle, Final Drive, and Flywheel Clutch and Direct Drive Transmission. Need Manual Transmission overhaul tools for a Cat marine gear? That’s covered under Marine Gear. Every specialty mining tool gets its own subsection too.

If you’re working on any of these four engine families — C175, 3600, C8.7, C12.9 — don’t waste time digging through generic tool sites. This 1706-page PDF gives you the factory tool list, the diagnostic procedures, and the safety specs. Related manuals you might want to look at include Caterpillar 3500 C175 2009 Technical Manual for the rebuild specs, Caterpillar Diesel Fuel Systems Application Installation for fuel system setup, and Caterpillar 368-9910 Multi-Tool Group Diagnostics Manual for advanced electronic diagnostics. Bookmark this one, print the tool lists, and bolt the job.

Does this manual cover engine rebuild procedures or just tools?

It’s a dealer service tools catalog — it lists every specialty tool, puller, gauge, and fixture required to service these engines. You’ll need a separate engine rebuild manual for step-by-step overhaul procedures and torque values, but this manual tells you exactly which tools to buy or rent.

Can I use this manual for a C8.7 engine swap into a non-Cat machine?

Yes, for tool selection. Use the C8.7 Engine Tools subsection to identify the lifting fixtures, flywheel housing tools, and electrical diagnostic adapters. The tool part numbers are OEM — they’ll match Cat service parts.

You’ve got a dead C175 or a 3600 that needs a full teardown. The tool list is here. The factory part numbers are here. The diagnostic flow is here. Get it right the first time. Access the Factory Manual now.
