Atlas Copco Xas 67 Parts Catalog

If you’re trying to order a replacement lubricator for an Atlas Copco Xas 67 and the aftermarket site gives you a part number that doesn’t match the bracket or the nipple, you already know the headache. These compressors have different option packages — lubricator, bypass aftercooler, water separator, PD-filter — and the wrong part means a week of downtime waiting for a return.

Atlas Copco designed these units so options bolt on in modular fashion. You need the exact nipple (1604 3819 02), the right o-ring (0663 2108 20), and the correct lock washers or you get leaks. The aftermarket catalogs swap drawings around and leave you guessing.

This is an OEM Parts Catalog, 61 pages, direct from the factory. It shows you exactly which part number goes with each assembly, down to the hexagon nut size and the o-ring type.

Lubricator Assembly Parts Breakdown

On page 1, the parts list starts with the battery cable (part 1615 7725 01), two brackets, a nipple, an o-ring, and the lubricator assembly itself (1615 8584 85). The table lists hexagon nuts (0266 2110 00), plain washers (0301 2335 00), and even the lubricating oil (8099 0202 36). That’s your reference for ordering.

That’s the difference between a wasted week and a working compressor. The factory parts list eliminates the back-and-forth with parts suppliers.

After Cooler with Water Separator: Exploded View and Part Numbers

Page 4 shows the after cooler with water separator assembly. The diagram references every component: the aftercooler (1604 3943 00), water separator (1615 8581 00), hoses, clips, o-rings, and restrictor. The exploded view includes a silencer (9090050700) and plastic tube (0070600205) that are often overlooked in aftermarket listings. Having the OEM part numbers means you can order the exact assembly from any Atlas Copco dealer without having to pull the old part and measure it.

Bypass Aftercooler and Other Options

The bypass aftercooler option routes compressed air around the aftercooler when full cooling is not needed. The parts list includes a pipe (1604 4031 00), bracket (1604 5900 00), and various hose nipples. Without the correct bracket, the assembly will vibrate loose. The factory drawing shows the exact orientation. Each option section has its own parts table. You can identify which configuration your compressor has by matching the assembly drawing.

Why This Catalog Beats Aftermarket Parts Lists

Aftermarket parts catalogs often consolidate multiple variants into one drawing. They leave out the lock washer sizes or substitute a generic o-ring part number. I have seen aftermarket catalogs list the same part number for two different hose assemblies. That mistake costs a day of labor tearing down the wrong section. The Atlas Copco factory catalog separates each option clearly. The lubricator option has its own bracket and nipple that are not interchangeable with the water separator bracket. The 61 pages are printed from the same database Atlas Copco uses for their own service centers. You pay for that accuracy once and use it for every repair.

Who Needs This Atlas Copco Xas 67 Parts Catalog?

If you own an Xas 67 or maintain a fleet, this catalog saves you from ordering the wrong water separator or lubricator. The drawings match the actual hardware. Beginners will appreciate the clear exploded views that show how the aftercooler connects to the water separator. Even if you are a home garage enthusiast working on a single compressor, spending money on the wrong water separator because you guessed the part number wastes more time than the catalog costs. Experienced mechanics will use the part numbers to get the exact o-ring or hose clip without measuring. The Automotive Industry Overview provides context for why portable compressors like this are used on construction sites and repair shops.

Does this catalog include torque specs?

No. This is a parts catalog, not a service manual. It lists part numbers and assemblies.

Can I use this to identify which option package my compressor has?

Yes. The catalog groups parts by option: Lubricator, Bypass Aftercooler, After Cooler with Water Separator, and Aftercooler with Water Separator and PD-Filter. You can match the assembly drawings to your compressor’s setup. The part numbers in each section correspond to the specific configuration. If your machine has a water separator, refer to the water separator section in the catalog. This eliminates ordering a lubricator when you need a PD-filter assembly.
