Atlas Copco COP 1838 2007 Parts Catalog – Factory Specs

If you’ve ever ordered a replacement part for a rock drill and got the wrong size, wrong thread pitch, or a component that didn’t seal because someone guessed the number, you know the cost in downtime and rework. That is exactly why this Atlas Copco COP 1838 2007 Parts Catalog exists. It is the official 29-page document printed by Atlas Copco in 2007 for the COP 1838 rock drill – specifically units whose serial number ends with the letter E. No aftermarket compilation, no scanned third-party copy. This is the file you use when you want the part to fit the first time.

COP 1838 Parts Catalog: What’s Inside the 29 Pages

Every page is a spare parts list for the rock drill. The catalog starts with a multilingual instruction block reminding you to state description and part number (not the reference number) when ordering. It also warns about parts marked with a safety symbol – those are components whose failure can compromise product safety. The rest of the document is a structured list with exploded views and part numbers. You get the exact Atlas Copco genuine part number for each component, organized by assembly.

Serial Number Restriction: Locate the Final Letter E

This catalog applies only to COP 1838 drills where the serial number’s last character is E. If your drill ends in any other letter, the part numbers in this document do not match. Before you open the file, check the serial code stamped on your rock drill. Ordering against the wrong revision means wasted money and time. The factory document makes this restriction clear on the first page.

Ordering Spare Parts: The Right Info to Provide

When you call your Atlas Copco distributor, you give them the description and the part number printed in this catalog. Do not give them the reference number – the manual explicitly says that. You also need the type designation and the serial code. Without the serial code, the distributor cannot confirm revision compatibility. This catalog gives you the exact format to follow.

Safety Symbol – Pay Attention to This Marker

Some part numbers in this catalog have a symbol printed in front of them. Those are safety-critical components. The manual states: “the product safety is affected if defect, faulty or pirate parts are used.” That means if you install a counterfeit or worn safety-related part, you risk catastrophic failure underground or on a jobsite. The symbol tells you which parts require certified genuine replacements.

Aftermarket Parts vs. Atlas Copco Genuine Parts

Third-party parts lists online often skip the safety symbol and the serial number restriction. They also frequently mix up part numbers between revisions. This catalog is the only source that gives you the OEM-approved number for the specific E-series COP 1838. Using a generic list means you might order a piston that is 2 mm too short. The factory print eliminates that risk.

Why 29 Pages Matter on a Job Site

Twenty-nine pages is not a thick manual. But it is all you need to identify every replaceable component on the drill. You don’t flip through 600 pages of theory – you go to the exact exploded view, find the part number, and place the order. The document is compact enough to print and laminate for the toolbox. That is why experienced drillers keep a copy nearby.

For a broader look at heavy equipment documentation standards, see Automotive Industry Overview. The same principles of traceability and revision control apply to rock drills as to automotive assemblies. Also check Automotive Industry Overview for background on why factory specs matter in industrial maintenance.

Does this parts catalog include service procedures or torque values?

No. This is a parts catalog only – no repair steps, no torque specs.

Can I use this catalog for a COP 1838 with serial number ending in F?

No. This catalog explicitly states it applies only to rock drills whose serial number ends with the letter E. Using it for any other revision will give you incorrect part numbers. Always verify the serial code on your drill before referencing this document. Misidentification can cause incorrect parts to be ordered, leading to safety issues, equipment damage, and unnecessary downtime. If your drill ends with a different letter, you need the corresponding factory catalog for that revision. Atlas Copco produced separate catalogs for each serial code suffix.
