Atlas Copco MB 1700, MB 1700 DP 2013 Parts Catalog – OEM Factory Parts List

If you’ve ever tried ordering parts for a hydraulic breaker by guessing from a worn-out serial plate, you know the drill. One wrong seal kit and the whole job stalls. Atlas Copco MB 1700, MB 1700 DP 2013 Parts Catalog kills the guesswork. This is the official factory spare parts list, not some aftermarket rewrite with missing diagrams. You get 36 pages of exploded views, part numbers, and tightening torques. That’s it.

What the Atlas Copco MB 1700, MB 1700 DP 2013 Parts Catalog Covers

This manual splits the breaker down into logical sections so you can find exactly what you need without flipping through irrelevant pages. The spare parts list starts on page 6 and covers both the standard MB 1700 and the MB 1700 DustProtector variant. Each illustration includes the part number, description, and quantity. For example, the percussion unit is broken into three sub-sections: cylinder cover (page 10), cylinder (page 12), and lower breaker part (page 14). You also get the connecting kit for ContiLube II, the StartSelect system (AutoStart/AutoStop), and a full list of optional parts.

36 Pages of Factory Specs

Thirty-six pages may sound thin, but every page carries weight. General information starts on page 5. After the spare parts list, you hit the tightening torques on page 21 — critical if you’re reassembling the cylinder or lower breaker. Then working tools (pages 22–23) list the moil points, chisels, and blunt tools approved by Atlas Copco. Accessories include hydraulic hoses and optional equipment on page 24. Kits start on page 25: label kits, seal kits, plastic parts kit, tensioning bolt kit, DustProtector kit, noise protection kit, and lower breaker part kits. Each kit comes with its own part number. No guesswork.

Need a Specific Seal Kit?

Page 27 lists the seal kit for the swivel joint (ContiLube II) and a separate general seal kit. If you’re rebuilding the cylinder, you want the correct O-ring and backup ring set. Ordering from memory causes leaks. Use the part number from this catalog.

Tightening Torques: Page 21 Specs

Torque values are factory-sourced and given in lb-ft. Don’t assume generic numbers. The percussion unit bolts see a lot of vibration. Under-torque and the cylinder cover walks; over-torque and you stretch the bolts. Page 21 lists the exact values for each fastener size.

OEM vs Aftermarket: Why This Parts Catalog Wins

Aftermarket parts lists often rearrange illustrations or omit superseded part numbers. This 2013 Atlas Copco document is a direct scan of the original factory publication. It’s valid for serial numbers beginning with 54. You get the official parts breakdown without third-party edits. I’ve seen too many techs order a lower breaker part kit from a generic supplier only to find the bushing diameter is off by 0.5 mm. That doesn’t happen with the factory list. Related: the Atlas Copco XRVS455Md 1998 Parts Catalog – OEM Factory Parts List and Atlas Copco V6000TV 2015 Parts Catalog – OEM Factory Parts List follow the same level of detail, as does the Atlas Copco ROC F9-11 2002 Parts Catalog – OEM Factory List.

FAQ

Does this catalog include part numbers for the MB 1700 DP only?

Yes. Both MB 1700 and MB 1700 DP are covered, with separate sections for each variant.

Can I use the tightening torques on page 21 for aftermarket bolts?

Only if the bolts meet the original grade specification. The torque values are calculated for factory-supplied fasteners. If you replace a bolt with a different grade, the torque will be wrong. You must verify the bolt’s tensile strength before applying the listed torque. Otherwise you risk damaging the percussion unit or causing a leak. Always match the bolt grade indicated in the parts list.

This manual saves you from ordering blind. You see the exact part, the exact number, and the exact torque. The Automotive Industry Overview background on equipment maintenance applies here: proper parts are the foundation of reliable operation. For a broader view, the Automotive Industry Overview reference underscores why OEM documentation matters across all machinery.

Stop cross-referencing sketchy online listings. Access the Factory Manual and get the parts right the first time.
