ZF 2 HL 290 2010 Parts Catalog – The Only OEM Part Number List You Should Trust

You ordered a seal, got a bag of wrong-size O-rings. Three days of downtime, a pissed-off customer, and your shop’s reputation takes another hit. That stops when you own the real **ZF 2 HL 290 2010 Parts Catalog** — not some third-party reprint that blurs part numbers. I’m Mike Callahan, and I’ve seen too many techs waste hours because they used a generic parts list. This 37-page catalog comes straight from ZF Passau, dated April 2010, and it lists every damn component with the exact OEM material number. No guessing. No returns. Just the part you need.

Input Housing and Multi-Disc Brake: Exploded Views That Save Time

Page 3 of this catalog lays out the input housing (material number 4143.125.045) right next to the multi‑disc brake (4143.151.015). The graphics aren’t blurry photocopies — they’rexa0factory drawings with position numbers that match the ZF service manual. You see the housing, the brake pack, the coupling (4143.152.013), and the oil pipe (4143.121.011) all in one spread. When a customer brings in a 2u202fHLu202f290 with a dragging brake, you don’t disassemble blind. You pull up that page, identify the part by its position, and order the exact ZF part. No chasing cross-references. The catalog also notes the amendment number and start production number — that’s how you know if your unit uses the updated seal or the old one. I’d rather have this on my bench than a stack of aftermarket listings any day.

Planetary Drives: Vertical vs Horizontal – Know Your Variant

Same transmission, two different planetary drive assemblies. The horizontal version is 4143.115.017; the vertical unit is 4143.115.405. The catalog flags them with “VERTIKAL” and “HORIZONTIAL” in the technical info field. Miss that, and you get the wrong ring gear, wrong carrier, wrong everything. This is where most parts catalogs fall apart — they lump all variants into one line. ZF’s 37-page breakout gives you separate entries for each, with the correct material feature. If you’re rebuilding a 2u202fHLu202f290 from a Hyundai excavator, you need to know which orientation your unit has. The catalog tells you. No phone calls to ZF tech support needed.

Gear Shift Sensors: Two different Part Numbers – One Application

Page 3 lists two gear shift sensors: 4143.142.025 and 4143.142.406. The third one, 4143.142.407, is marked “2HLu202f270” — that’s a different model. The catalog gives each sensor its own position number and amendment code. The 4143.142.025 starts with amendment N2301/0710; the 4143.142.406 has no amendment start date. That tells you the 406 superseded the earlier version. If you’re ordering a sensor for a 2011‑built transmission, check the production date on your type plate. The catalog doesn’t spell out the supersession explicitly, but the amendment data is your clue. Experienced buyer. Read the header fields.

Type Plate and Identification Codes – Why You Should Never Ignore It

The catalog includes the type plate (4143.139.001) as a separate part. That plastic tag carries the material number 4143.020.067, the ZF model, and the Hyundai part code. When I get a transmission that’s been swapped, I always photograph the type plate before I order anything. This catalog’s page 3 shows you exactly which type plate standard is used. Match that to your unit, and you’ve got the correct baseline. Cross‑reference that ZF material number with the ZF 16S151 ECOSPLIT III & 16S151 R 2007 Parts Catalog if you’re working on a mixed fleet. The same identification logic applies across ZF driveline products.

37 Pages of Factory Spec – No Guesswork, No Aftermarket Guess

Thirteen April 2010. That’s the copyright date. 37 pages, packed with OEM material numbers for every seal, piston, spring, O‑ring, and housing. Page 5 lists the piston assembly (4143.201.021) with its weight (48u202fkg?) and the gasket (0501.320.897) with a note that it’s used in the modulator valve for the 2u202fHLu202f290. The compression spring (0732.042.890) has a weight of 475 grams — that’s not a typo. You can verify the spring rate against the service manual if you’re rebuilding the valve body. The catalog also gives the external material numbers like ZGAQ‑01980 for the piston kit, which helps when your local supplier only stocks ZF’s industrial catalog. This is the kind of detail you only get from the factory source.

Buy the genuine OEM document. Not a PDF copy that’s been scanned twice and lost resolution. Not a recompiled list from a third party. The ZF 16S221 ECOSPLIT III 1316 2007 Parts Catalog OEM Specs and the ZF 16 S 2521 TO 2010 Parts Catalog – OEM Factory Specs follow the same format — ZF doesn’t cut corners on part numbering. Neither should you.

For background on why OEM cataloging matters, check the Automotive Industry Overview and Automotive Battery pages — both underscore that factory data beats aftermarket every time. But the real lesson is here, in this 37‑page booklet. If you work on ZF 2u202fHLu202f290 units, this is the one part you should own before you order one.

Does this catalog include torque specifications for assembly?

No. This is a parts catalog, not a repair manual. It lists part numbers and exploded views. Get the ZF service manual for torque values and clearances.

How do I identify which planetary drive variant my 2u202fHLu202f290 has without pulling the unit apart?

Check the type plate on the input housing. The material number 4143.020.067 is printed on it. Compare that to the catalog’s entry for the input housing (4143.125.045). Then look at the planetary drive entries: 4143.115.017 (horizontal) or 4143.115.405 (vertical). If the type plate is missing, you’ll need to remove the cover and inspect the gear orientation. The catalog won’t tell you which variant is in your unit — that’s your job. But once you know, the catalog gives you the exact part numbers for seals, bearings, and carriers. I’ve done this on a 2u202fHLu202f290 from 2009 and it took ten minutes to confirm the vertical variant. The catalog’s technical info field (“HORIZONTIAL” or “VERTIKAL”) matched the actual assembly.

Access the Factory Manual now and put this 37-page reference on your shop tablet or printed binder. Every part you order will fit. Every number will match. That’s how you keep a 6‑bay shop profitable — stop reordering mistakes.
