ZF 16 S 1650 2009 Parts Catalog – Factory OEM Specs for Heavy Truck Transmissions

You have a ZF 16 S 1650 transmission on the bench or in the truck, and you need to order parts. The last thing you want is a mismatched synchronizer or an input shaft that’s 10mm too short. That’s why you need this ZF 16 S 1650 2009 Parts Catalog – a factory-issued document from ZF do Brasil Ltda., dated September 2009. It’s 55 pages of exact part numbers, assembly drawing references, and vehicle data. No guesswork, no aftermarket cut-and-paste jobs. This is what ZF sent to JINHUA YOUNG MAN for the 16S-1650 / OD*LL*D-L H-H* build. If you’re rebuilding or repairing one of these heavy-duty boxes, you work off this catalog or you risk ordering the wrong flange, wrong clutch housing, or wrong gear shift lever.

What the 55-Page Parts Catalog Contains

Page 5 alone lists nine critical components with their ZF part numbers. You get the gear shift lever (0097 083 001 / 6005 183 535), the clutch housing (0097 900 001 / 6060 110 366), the input shaft (0097 002 003 / 0091 102 282), and the gearbox housings. Each item has a figure reference and technical information column. The catalog also includes the master part list (1297 095 160) with modification numbers, so you can cross-reference which parts changed between revisions. You won’t find that level of detail in a generic cross-reference website.

Vehicle Application and Transmission Specs

This catalog is not just a parts list – it documents the exact vehicle setup this transmission was built for. The data on pages 2-4 shows customer JINHUA YOUNG MAN, an artic tractor 6×4 with a HINO P11C-UJ Euro 3 engine (259 kW at 2100 rpm, 1460 Nm at 1100 rpm). Ratios run from 15.39 down to 0.85 overdrive, with a crawl ratio of 13.09. Shift system is cable control, horizontal right, H-H pattern. Input shaft is SAE 10C 2” with length 116 mm. Clutch bell housing is SAE 1, length 175 mm, release fork pull type 78 mm. Oil capacity is appr. 14.5 liters of TE-ML02 grade. If your truck doesn’t match these specs, you still get the base part numbers and assembly drawing IDs (1297.695.160, 1295.173.010, 1297.095.019) to work from.

OEM Authenticity: Why ZF Documentation Beats Aftermarket

Aftermarket parts catalogs often copy old data, drop a digit, or omit the “mod.nº” column that tells you which revision fits your build. This catalog came straight from ZF do Brasil. The cover title reads “SPARE PARTS CATALOGUE 0091 757 053 09/2009 16 S 1650”. Every page has the ZF logo and the part list number 1297 095 160. When you’re holding a ZF OEM catalog, you’re not guessing whether the output flange bolt pattern is 4xM14x1.50×50 at 150 mm PCD – you’re reading the factory spec. That’s the difference between a transmission that seals up and one that leaks oil on the dyno.

3 Ways This Catalog Saves You From Wrong Orders

1. Exact part numbers with figure references – Every component on page 5 links to a figure number. You can visually confirm the part shape before you order.
2. Modification numbers (mod.nº) – The catalog tracks which engineering changes apply. If a clutch housing was superseded, the mod.nº column shows it. No more installing an obsolete casting.
3. Assembly drawing IDs – M12, M14, M16 entries in the data block give you the drawing numbers for the overall assembly, sections, and details. Use those to see how parts fit together before you start wrenching.

Who Should Own This Catalog

Fleet shops that run heavy trucks with ZF 16 S 1650 transmissions. Independent transmission rebuilders who see these boxes on a regular basis. DIY owners who pulled a ZF out of a European truck and need to find the right internal parts. If you’re ordering a new input shaft or a clutch housing, you need the ZF part number from this catalog – not the one stamped on the old part, which may have been renumbered. The catalog also gives the mass (400 kg appr.), paint spec (Tiefschwarz RAL 9005), and preservation code (KA2T/KI2/S09). That matters if you’re storing a spare unit.

Does this catalog include torque values for reassembly?

No – this is a parts catalog. Torque specs and service procedures are in the factory service manual for the ZF 16 S 1650.

How do I find the right part number for my transmission when this catalog lists a specific customer build?

The main list on page 5 shows generic part numbers for the 16S-1650 family. Use the assembly drawing numbers and the modification column to match your gearbox’s serial number. If your transmission has a different shift lever (R=69) or a different output flange (AD=180, LZ2x2, D=14.5), the catalog still gives you the base part. Cross-check with the “mod.nº” column to confirm supersessions. For example, if your gearbox has a different shift system (e.g., direct control instead of cable), you’ll need to look at the variant list on page 2 (F34 SHIFT SYSTEM: CABLE CONTROL- HORIZONTAL RIGHT *H-H*). That tells you which parts are unique to that configuration. If you’re still unsure, contact ZF with your transmission data plate – the catalog provides the customer spec number and all F-series codes to help them identify the correct variant.

Related Manuals for ZF Transmissions

• ZF 16S151 ECOSPLIT III & 16S151 R 2007 Parts Catalog
• ZF 16S221 ECOSPLIT III 1316 2007 Parts Catalog OEM Specs
• ZF 16 S 2521 TO 2010 Parts Catalog – OEM Factory Specs

For background on the heavy-duty transmission market, see Automotive Industry Overview. If you’re also dealing with the truck’s electrical system, Automotive Battery might be useful, but that’s a separate system – this catalog stays focused on the gearbox.

Stop ordering parts blind. Access the Factory Manual – the ZF 16 S 1650 2009 Parts Catalog – and get every part number, figure, and spec from the people who built the box.
