ZF 16 AS 2630 2009 Parts Catalog

You’ve got a ZF 16 AS 2630 transmission on the bench, and the input shaft bearing is shot. You pull the old one, squint at the number, and order what looks right. Part shows up — wrong shoulder height. That’s a half-day wasted. This ZF 16 AS 2630 2009 Parts Catalog is what you print out and tape to the toolbox so you don’t make that mistake again.

54 pages of factory-sourced information from ZF Friedrichshafen AG, dated 27.10.2009. This is the original spare parts catalog for the 16 AS 2630 transmission used in IVECO trucks. Every material number, every revision code, every position number in the exploded views comes straight from the OEM. No aftermarket reprints, no guesswork.

Inside the 54-Page Parts Catalog for the 16 AS 2630

Each section of this catalog lists the transmission assembly with graphic position numbers, material numbers, names, VKF amendment codes, and production number ranges. Page 3 shows the start of the parts listing with entries like 1328.004.015 for the main transmission assembly and 6009.097.109 for the GS 33 shift unit. You get the full breakdown: inspection program codes, technical feature IDs, and start dates for each component revision. This is the same data ZF sends to dealerships.

Use the position numbers to locate the exact part on the exploded diagrams. Cross-reference the material number with the accompanying table. That’s it — one correct number, one correct part. No phone calls to a parts guy who reads the screen wrong.

Why Does the OEM Parts Catalog Matter for the 16 AS 2630?

Aftermarket parts catalogs often combine multiple transmission models into one confusing list. They drop revision codes, ignore production breaks, and leave you with a part that fits a different build date. This ZF catalog isolates the 16 AS 2630 variant (TO – IO prefix for IVECO applications) and lists every supersession step. The VKF column and Amend. no. tell you exactly when a part changed. If you ignore those, you’re ordering blind.

I’ve seen guys order a synchro assembly for a 16 AS 2630 build before 2003 and get a part that only works after 2005. That’s the cost of guessing. This catalog eliminates that gamble.

3 Common Mistakes When Ordering ZF Transmission Parts

1. Ignoring the production number (Prod. no.) range. ZF changes internal specs at specific serial numbers. The catalog lists start and end production numbers for each component. One digit off and the bearing race thickness differs.

2. Using the name alone instead of the material number. ‘Input shaft’ might look the same but have a different number of splines. The 16 AS 2630 uses material numbers like 1328.031.023 — that 023 suffix matters.

3. Overlooking the amendment service note. The catalog is marked “For information only, not subject to the amendment service” — that means it’s a snapshot of parts as of October 2009. If your transmission has been revised after that date, you need the latest OEM bulletin. Cross-reference with the ZF 16S151 ECOSPLIT III & 16S151 R 2007 Parts Catalog for similar model families, or the ZF 16S221 ECOSPLIT III 1316 2007 Parts Catalog OEM Specs for a different series, or the ZF 16 S 2521 TO 2010 Parts Catalog – OEM Factory Specs for higher torque variants.

Read the Graphics Correctly: Position Numbers and Material Codes

Every exploded view in this catalog uses a three-level position code: for example, 105.a1.01-1. The first number (105) indicates the main assembly group. The letter-number combination (a1) points to a subassembly. The final dash (01-1) identifies the specific item in that view. The material number next to it is the only number you write on the order. Ignore the graphic if the position number font looks different — ZF uses a specific font for each revision.

On page 3, the table header lists “Graphics Pos.”, “Material number”, “Name”, “VKF”, “Amend. no.”, “Amend. start”, “Prod. no.”, and “Material feature / tech. info. ID”. The VKF column is critical: it references the ZF group code for interchangeability. If two parts have the same VKF but different material numbers, they are direct replacements.

Aftermarket Parts Lists: The Risks You Take Without OEM Specs

Generic parts websites pull numbers from unclean databases. They might list a throwout bearing that fits both the 16 AS 2630 and a different ZF box, but the pilot bore diameter is off by 2 mm. The result: clutch chatter, premature wear, or a broken housing. This OEM catalog gives you the exact dimensions and features in the “Material feature / tech. info. ID” column. You match that ID to the part in your hand.

For a deeper understanding of transmission industry standards, check the Automotive Industry Overview. And if you’re working on the electrical side of the vehicle (speed sensors, shift solenoids), proper battery voltage is critical — see the Automotive Battery guide for testing procedures.

Frequently Asked Questions

Can I use this catalog to rebuild the transmission?

No. This is a parts catalog, not a service manual. It lists components and their numbers but does not include assembly procedures or torque specifications.

How do I find the correct part number for my 16 AS 2630?

Start by locating the production number stamped on the transmission housing. Then find the assembly group in the catalog’s graphic index (e.g., 105 main group). Match the position number from the exploded view to the table on pages 3–54. Note the VKF code and amend. start date to confirm the revision level. If your production number falls between the listed start and end numbers, you have the correct part. Always double-check the material feature ID — it may include modifications like “GS 33” shift unit versions.

Whether you’re stocking a shop or rebuilding one unit, having the factory parts catalog on hand saves callbacks. I’ve torqued enough bolts to know that the right part number is as important as the right torque. Access the Factory Manual and keep it in your service folder — you’ll thank yourself when that bearing arrives with the correct shoulder height.
