ZF 12 AS 1800 2009 Parts Catalog – OEM Factory Specs

You’re pulling a ZF 12 AS 1800 transmission out of an IVECO and you need the correct part numbers for a clutch actuator. That’s where this 47-page 2009 Parts Catalog earns its keep. Not some aftermarket reprint that guesses which seal ring fits. This is the original ZF document – material numbers, production codes, and amendment numbers straight from Friedrichshafen. Page 3 lists the repair kit 1318.298.001 with its specific casting code. Page 5 gives you the clutch actuator 0501.216.296, an 18-pin AS1 assembly. If you bolt in the wrong actuator because a third-party catalog said “fits all,” you’re pulling the transmission again. I’ve seen it happen.

Clutch Actuator and Repair Kit Data

Every component in this Parts Catalog is keyed to a material number. The clutch actuator on page 5: material 0501.216.296, weight 0.000 kg (data blank, but the catalog notes it). The repair kit on page 3: 1318.298.001, amendment start C0100983, with a note “KPL.KUPPL.STELLER*SANDGUSS” – that’s the clutch actuator assembly in sand-cast housing. That level of detail matters when you’re ordering from a dealer. Hand them a material number, not a description. You get the right box every time.

47 Pages of Factory-Coded Information

Forty-seven pages. Not a thick manual, but every page carries the weight of ZF’s engineering. The catalog uses a graphic position system – pos. numbers like 069.a1.01-1 for the basic transmission model 12 ASI TD 1, followed by individual part rows. Each row lists material number, name, VKF (exchange status), amendment no., production no., technical info, and OTK external material number. You also get a “SP” column (special part flag). That’s the kind of structure that prevents ordering a part that doesn’t match your production date. And yes, the copyright notice on page 1 is clear: “All rights reserved by ZF Friedrichshafen AG.” This is the real thing.

Why Does Part Number Matter on an IVECO 12 AS 1800?

I worked on one of these in a 2015 IVECO Stralis. Customer had replaced the clutch actuator with a generic unit from a parts store. Drove fine for three weeks. Then the transmission went into limp mode every time it hit 4th gear. The generic actuator didn’t have the correct CANbus logic – the ZF 12 AS 1800 uses an Astronics CAN interface cable (material 6029.013.037, listed on page 3 of this catalog). Swapped in the genuine ZF actuator with the correct cable, problem gone. A parts catalog like this stops you from making that mistake on your first try.

Source Authenticity: ZF vs Aftermarket Catalogs

Aftermarket parts catalogs are dangerous. They often compress multiple transmission families into one table and say “fits 12 AS 1800, 16 AS 2200, etc.” But the 12 AS 1800 has unique solenoid valve assemblies, different cable harnesses, and a specific repair kit. This ZF catalog assigns each part to a model line (12 ASI TD 1, 16AS2200*12AS1800) and amendment dates. If you rely on a third-party list, you’re flying blind. Stick with OEM documentation. For other ZF transmissions, check the ZF 16S151 ECOSPLIT III & 16S151 R 2007 Parts Catalog [LINK_ID_REL_0] for similar factory-level data.

Check Your Material Number Before Ordering

Before you call the dealer, look up your transmission’s material number (stamped on the housing). The catalog starts with 1318.001.011 for the 12 ASI TD 1. Cross-reference that with the pos. groups. If you need the clutch actuator, note the amendment start date (C0100983) – a later production run might use a different revision. That’s in the catalog. Don’t skip it.

Related Manuals

• ZF 16S151 ECOSPLIT III & 16S151 R 2007 Parts Catalog
• ZF 16S221 ECOSPLIT III 1316 2007 Parts Catalog OEM Specs
• ZF 16 S 2521 TO 2010 Parts Catalog – OEM Factory Specs

ZF supplies transmissions for heavy commercial vehicles across the globe – a key player in the Automotive Industry Overview that you can read about for broader context. Even though this is a gearbox parts catalog, electrical components like the clutch actuator wiring (cable astronic 6029.013.037) require proper grounding – similar to how you’d handle an Automotive Battery connection. Use the right OEM specs from the source.

Does this catalog include torque values?

No, it’s a parts catalog, not a service manual.

Can I use this to find aftermarket substitute parts?

You can try, but I don’t recommend it. ZF catalogs are indexed by material numbers and production codes specific to the 12 AS 1800. Aftermarket cross-references miss those nuances. For example, the clutch actuator on page 5 (part 0501.216.296) is an 18-pin AS1 assembly. An aftermarket catalog might list a generic actuator that physically fits but lacks the correct CAN bus logic. Then you’re chasing electrical faults. Stick with ZF’s own listings.

Stop wasting time with mismatched parts. Keep this catalog on your workbench the next time you crack open an IVECO with a ZF 12 AS 1800. Access the Factory Manual now.
