Terex TA400 2011 Operators Manual

If you are running a Terex TA400 on a job site and you don’t have the factory Operators Manual in the cab, you are asking for downtime. I have seen guys guess the gear select sequence on a 40-ton hauler and lose a clutch pack. This 181-page document from Terex Equipment Limited, dated 2011, is the only source for how that machine was designed to be operated, serviced, and kept out of the ditch. Skip the aftermarket reprints – the OEM manual has the warning labels, the brake function checks, and the exact fluid capacities that keep the wheels turning. You want to keep the loader operator happy? Keep this PDF on your tablet.

Safety Decals and Hazard Warnings

Page 1 of this manual lays out the safety alert definitions: DANGER, WARNING, CAUTION. The factory takes the time to separate imminently hazardous situations from property damage risks. The manual includes the exact decal placements for the TA400 – something the third-party books always mess up. If you are training a new operator, make them read the section on “Intended Use Of Machine” (page 1) and the theft deterrent practices. I have been on too many sites where a machine gets left unlocked overnight. The manual tells you to immobilize the starter system and record serial numbers. That is not fluff – that is job security for the shop.

Controls and Operating Procedures

Chapter 3 covers controls and operating. The TA400 has a specific pre-start routine. Do not skip the brake function checks – the manual devotes a sub-section to brake checks before driving. Driving and stopping procedures are spelled out with reference to the Manual Transmission engagement points. If you have ever had a haul truck roll away on a grade because the operator skipped the neutral check, you understand why this manual exists. It also details how to stop the engine properly. That step prevents turbo bearing coking. Page 4 – conventional wisdom says let it idle, but this manual tells you the exact idle time. I trust the factory over the guy in the breakroom every time.

Technical Data and Fluid Capacities

Chapter 9 is the technical data section. It lists capacities for engine oil, transmission, axles, and hydraulic fluid in imperial units. Need the cooling system volume? It is there. The manual also includes tire pressure specs and planetary axle ratios. If you are swapping a component, cross-check the serial number range – the manual notes revisions. This is the kind of data that keeps you from overfilling a differential and blowing a seal. Page 9 has the full table. I have that page bookmarked in my copy.

Moving a Disabled Machine

Chapter 7 covers moving a disabled TA400. This is not the section to guess on. The factory procedure details towing speed limits, steering pump lockouts, and brake release sequences. One wrong move and you can ruin the driveline. The manual includes a warning about transmission damage if towed without disconnecting the driveline. I have seen a field mechanic skip that step and cost the company $12,000. Get this manual and print the towing section. Keep it in the glovebox.

Lubrication and Servicing Intervals

Chapter 8 spells out the lubrication and servicing schedule. The TA400 needs grease on the kingpins and steering linkages every 50 hours – not 100, not “when it squeaks.” The manual gives the interval for engine oil and filter changes, transmission fluid changes, and hydraulic return filter replacement. It includes the note: “1 More often if required.” That is the factory telling you to read the conditions. If you are in dusty Texas like me, you cut those intervals in half. The manual gives you the baseline so you can adjust it right.

Does this manual cover the transmission rebuild procedures?

No. This is an Operators Manual, not a service repair manual. It covers daily operation, controls, and preventive maintenance. For rebuild specs, you need the Terex TA350 TA400 Maintenance Manual.

Can I use this manual for the 2009 TA400?

The 2011 edition supersedes earlier versions. Some controls and safety decals changed. If you have a 2009 machine, the TEREX TA350/400 Operator Handbook Owner Manual 2009 is more accurate for that year.

What torque values are in this manual?

The Operators Manual lists wheel nut torque and a few fastener values in the technical data section. Full engine and drivetrain torque specs are in the Maintenance Manual referenced earlier.

Is the PDF searchable?

Yes. The document is OCR-processed, so you can search for terms like “brake” or “transmission oil.” The file is 181 pages and includes bookmarks for each chapter.

You have the machine. You have the job. Now get the information that keeps the TA400 hauling. Access the Factory Manual from AutoRepairManuals and stop relying on faded photocopies in the cab. This is the document Terex wanted with the truck. Pay once, print once, and keep it in the door pocket.
