Mitsubishi S3L2 2008 Parts Catalog – OEM Factory Part Numbers

If you’ve ever pulled a part off an engine, walked to the computer, and spent an hour chasing numbers that don’t match, you know the frustration. The Mitsubishi S3L2 2008 Parts Catalog cuts that time to zero. 120 pages of factory-verified part numbers, assembly diagrams, and ordering codes. No aftermarket abbreviations. No “fits like OEM” guesswork. Published August 2008 by Mitsubishi Heavy Industries, this is the same book that sits behind the dealer parts counter.

Mitsubishi S3L2 diesel engines used in generators, pumps, and small equipment need exact parts. A wrong piston ring or an incorrect gasket set means a tear-down two months later. This catalog lists every piece – from the crankcase assy to the last dowel pin – with Mitsubishi genuine part numbers. Serial range 167435-UP. You get the part name, part number, and quantity per engine. That’s it. No fluff, no reprints.

What the Parts Catalog Covers

Group numbers and reference numbers organize the engine into logical assemblies. The sample page (page 4 of the catalog) shows the crankcase group: crankcase assy, main bearing cap, dowel pins, shims, hanger brackets. Each item has a part number and description. You also get code notes like “B/W” for bolts with washers – those are listed separately starting at page D1 so you can order the exact fastener. The catalog also includes a numerical index (page C1) for cross-referencing. 120 pages of pure OEM data.

How to Order Parts for the S3L2

Open to page 3. You’ll see a guide that tells you exactly what information to give the dealer: part number (or assembly number), part name, quantity, and your engine model and serial number. The S3L2-V363JG model is listed for generator use, serial 167435-UP. If your engine falls outside that range, this catalog won’t match – you need the earlier edition. This isn’t a “one size fits all” PDF. It’s serial-specific. Check the applicable serial number before you order.

Why OEM Genuine Parts Matter (Page 2)

Mitsubishi includes a full page on genuine parts policy. Quote: “Imitation parts are not reliable from the viewpoints of their material and manufacturing method.” That’s not marketing – that’s engineering. Aftermarket parts often change dimensions, hardness, or coatings. A cylinder head gasket that’s 0.1mm thicker changes compression. A main bearing shell with different alloy composition wears out in half the hours. This catalog lists only genuine Mitsubishi part numbers. Use it to order from any authorized dealer. The parts counter will respect you when you hand them a catalog page with a real part number.

3 Reasons to Use Factory Parts Documentation

First, compatibility. Mitsubishi updates part numbers across serial breaks. The catalog tells you which parts apply to your engine build. Second, accuracy. Every part number in this catalog was verified against production drawings. Third, traceability. When you order a genuine part, you get a warranty and a paper trail. For a professional shop or a serious DIYer, that saves phone calls and returns.

Does This Catalog Include Service Procedures?

No. This is a parts catalog, not a service manual. It does not contain torque specs, overhaul steps, or timing marks. If you need that, you want the service manual. Check our related listings: Mitsubishi S-Series Diesel Engines 2001 Service Manual”>Mitsubishi S-Series Diesel Engines 2001 Service Manual covers the S3L2 overhaul. For a later parts reference, see Mitsubishi S3L2 2009 Parts Catalog – OEM Factory Specs”>Mitsubishi S3L2 2009 Parts Catalog – OEM Factory Specs. And if you work on larger Mitsubishi diesels, Mitsubishi S6A3-PTA PTK 1991 Parts Catalog – Factory OEM Specs”>Mitsubishi S6A3-PTA PTK 1991 Parts Catalog might be your next buy.

Source Authenticity – Factory Print, Not a Scan

You’re buying a direct digital copy of the original Mitsubishi publication (Pub. No. 98615-MW200). No third-party reformatting, no “reproduced” plates. Every page is legible, every part number sharp. The guide page (page 3) explains exactly how the catalog works – group numbers, model columns, quantity columns, change codes. Nothing is lost in translation. This is the same document that ships to Mitsubishi dealers worldwide. For an overview of the automotive industry and parts documentation standards, see Automotive Industry Overview”>Automotive Industry Overview.

FAQ

Can I use this catalog to rebuild my S3L2 engine from scratch?

It will give you every part number you need, but not the order of assembly or torque specs. You need the service manual for that. This catalog is your shopping list.

What if my engine serial number is lower than 167435?

Then this catalog does not cover your engine. Mitsubishi splits parts catalogs at serial breaks. You need the earlier edition for S3L2 engines below that number. Check our selection or contact us. We also carry the Automotive Battery”>Automotive Battery category if you are chasing electrical parts – but for engine parts, get the correct serial range catalog.

If you work on Mitsubishi S3L2 engines, you need this catalog on your hard drive or printed out. It stops parts-ordering mistakes cold. No more “I think this is the right injector line.” No more calling the dealer with a vague description. Access the Factory Manual and get the correct part numbers from the source.
