Manitou MLT 735, MLT 741, MLT 742 Parts Catalog

If you have ever ordered a part for a Manitou MLT 735, MLT 741, MLT 742 and ended up with the wrong bolt, wrong hose, or a bracket that does not fit, you already know the pain. Aftermarket catalogs guess. Third-party websites guess. You end up with a bin full of parts that almost work but do not. This is the factory Parts Catalog – 1255 pages of what Manitou actually built. No shortcuts, no aftermarket interpretation. Every exploded diagram, every part number, every revision update from the factory floor in Ancenis, France.

Brake Circuit Breakdown: What Page 2 Shows

Flip to page 2 of this catalog and you will see the brake circuit – handbrake, repair kits, tube sizes from 1.1 mm to 8 mm, and the exact repair kit references (6 BA 240, 6 BA 241). The factory identifies every O-ring, every spring, every clip. You get a clear diagram with callouts that match the actual hardware on your machine. If you need to understand diesel engine basics while you work, check this Wikipedia article on diesel engines for background. But for part identification, stick with this catalog.

1255 Pages of OEM Parts Data

That page count is not padding. Catering to the MLT 735, MLT 741, and MLT 742 models – including the 120 LSU, LSU Powershift, and the MLT 742 Turbo – this catalog covers every nut, bolt, hose, bracket, and electrical component. The document spans multiple publication dates from 2003 through 2009, with revision updates marked IC 387, IC 435, IC 476, and IC 564. You get the parts breakdown for the Series 2-E2 chassis. No generic aftermarket replacement listing – only genuine Manitou part numbers in four languages (French, German, Spanish, English).

Why the Factory Parts Catalog Beats Aftermarket

Aftermarket parts catalogs often reuse the same generic diagram across multiple models. You end up with a hose that is 2 inches too short or a seal that does not seat. With this catalog, the exploded view shows exactly which tubes, 6 BA 122 handbrake kit, and which repair kit (size 8 mm, 1.5 mm, 6 mm, etc.) belongs to your specific variant. The factory number is right there. Order from that number and the part arrives correct. You can also read about diesel engine fundamentals in this Wikipedia article on diesel engines, but for genuine part data, this catalog is the only source you need.

Is This Manual for DIYers or Professionals?

Both. If you own a Manitou telehandler – whether a farm MLT 735 or a construction site MLT 742 Turbo – you need this catalog. A professional mechanic bills hours. Chasing wrong parts eats those hours. A DIYer does not have a parts counter open on Sunday. Having the factory diagrams and part numbers lets you order ahead and avoid downtime. The catalog is not a service manual – it does not tell you how to install the part. It tells you exactly which part to install. Pair it with the factory service manual for a complete setup.

Get the Right Part Number Every Time

Every assembly is broken down into numbered callouts. For example, the brake circuit on page 2 shows callout 10 AA and 10 BA with repair kit references. You see the hose connection kit (6 BA 240) and the tube specifications. No guesswork. The catalog also includes a full index and cross-references across the four-language entries. If you find a part number in French, the English equivalent is listed in the same table. This is the master list that Manitou dealers use when they quote you a price.

Does this manual include torque specs?

No. This is a parts catalog, not a service manual.

Can I use this to repair my MLT 742?

It helps identify parts needed for repair, but for procedures you need a separate service manual. The parts catalog gives exploded views and part numbers for ordering correct components. Without it, you risk ordering the wrong hose, seal, or bracket. The factory numbers here guarantee match. Use it alongside a service manual to complete the job.

What years does this cover?

The catalog includes revision dates from May 2003 through January 2009, covering Series 2-E2 models.

Is this the same as the dealer manual?

Yes. This is the exact OEM document with factory part numbers, not a copy or reprint.

• Manitou MLT Series Parts Catalog”>Related: Manitou MLT Series Parts Catalog
• Manitou MLT Series Parts Catalog 2010″>Related: Manitou MLT Series Parts Catalog 2010
• Manitou MLT Series 2007 Parts Catalog”>Related: Manitou MLT Series 2007 Parts Catalog

Stop wasting time cross-referencing sketchy online databases. When you order a part from this catalog, it fits. Plain and simple. Access the Factory Manual now and eliminate the guesswork from your next repair.
