Land Rover SERIES II, SERIES IIA 1958 Parts Catalog

If you’ve ever spent an afternoon ordering a part for a Land Rover Series II or IIA only to get the wrong one because the part number was off by a single digit, you know the frustration. That’s what happens when you rely on aftermarket drawings or a parts list that’s been photocopied three times. This catalog is the original 1958 edition from The Rover Co. Ltd., printed in Solihull, England. It’s the same document the dealership parts counter would have used. 596 pages of part numbers, exploded views, and factory revisions. I’ve been turning wrenches for 28 years, and I’ll tell you straight: if you’re working on a Series II or IIA and you don’t have this thing, you’re guessing. And guessing costs money.

Parts Identification: Why the Factory Catalog Matters

The difference between a correct part and a “close enough” part is often a letter suffix. The Rover Co. Ltd. issued this catalog in January 1958 with a second revision in October 1961. It covers both petrol and diesel models for the 88-inch and 109-inch wheelbases. Every part number listed here was verified against the factory build sheets. You won’t find generic illustrations that combine multiple model years. The exploded diagrams show exactly what you need for a 1958 Series II or a later Series IIA. If you’re trying to match a brake cylinder or a steering box, this is the only source you should trust.

That’s 596 pages of factory data.

What Does This Catalog Cover?

The catalog is organized by vehicle systems. You get the full parts breakdown for the engine, transmission, axles, chassis, electrical, and body. Each section includes the part number, description, and quantity per vehicle. The front pages list the vehicle types and serial numbers so you can cross-reference your chassis number. The manual also includes a section for special equipment and optional accessories. If you need to find the correct part for a 2.25L petrol engine or the 2.0L diesel, the index will get you there. This is not a repair manual — it’s a parts identification tool. But if you’re rebuilding a Series II, you need both.

596 Pages of Part Numbers

Every page is a direct scan from the original printed document. The paper is long gone, but the information is as correct as the day it was typed. The binding is a PDF, so you can search for part numbers quickly. The catalog includes a numerical index at the back, so you can look up a part number if you have it and find the page and section. For a DIY mechanic, this saves hours of cross-referencing. For a professional shop, it means you quote the right part the first time. I’ve seen too many rebuilds stalled because someone ordered a Series III brake shoe for a Series IIA. Don’t be that guy.

Get the Right Part the First Time

When you’re ordering parts for a Land Rover that’s over 60 years old, you don’t have the luxury of a dealer network. You’re on the phone with a supplier who needs a part number. This catalog puts that number in your hand. The exploded diagrams are clear enough to show the orientation of washers and seals. You can also use it to verify that a part from a later model (like the Land Rover One Ten / Defender 110 Parts Catalogue) will interchange. But for the 1958-1961 Series II and IIA, this is the definitive source. Combine it with the Land Rover Series I 1948-1953 Parts Catalogue – Section: Section Iii if you’re working on an earlier truck, but for the II and IIA, this is your book.

OEM vs Aftermarket: The Source Difference

Aftermarket parts catalogs often renumber parts or group them in ways that don’t match the original factory grouping. That leads to mistakes. The Rover Co. Ltd. designed this catalog to be used by dealers and mechanics. The part numbers are the same ones stamped on the castings. The manual lists the original equipment manufacturer (OEM) part numbers, not aftermarket cross-references. If you’re restoring a vehicle to original condition, you need these numbers. The 1958 publication date is important because Land Rover changed part designs during the IIA production run. The October 1961 revision is included in this edition, so you get the updates. For a history of the company, see Automotive Industry Overview. For general battery info, see Automotive Battery — but for the exact battery clamp part number, this catalog is the authority.

Does this catalog include torque specifications?

No. This is a parts catalog, not a service manual. Torque specs are in the workshop manual.

How do I use this catalog to find a part number for a specific component, like a water pump?

Start by identifying the section that covers the engine cooling system. The table of contents lists major sections like “Engine” and “Cooling System.” Look for the water pump illustration. The exploded diagram will show each component with a reference number. The part list below the diagram gives the part number, description, and quantity. If you have a chassis number, cross-reference it with the vehicle identification pages at the front to ensure you’re looking at the correct sub-model (e.g., 88-inch petrol vs 109-inch diesel). The numerical index at the back of the catalog can also help if you have a partial part number. This method works for any component — brakes, axles, electrical. The catalog is indexed by both system and part number, so you have two paths to find what you need. If you’re struggling, the Jaguar Land Rover Integrated Diagnostic System (IDS) Training might help with modern diagnostics, but for part numbers, stick to this book.

This catalog is a direct access. You get the complete 596-page PDF, no watermarks, no missing pages. If you’re rebuilding a Series II or IIA, you need the factory part numbers. You can access the factory manual now and start matching parts correctly. Access the Factory Manual.
