Iseki SG13 Parts Catalog – Factory OEM Parts ID

If you are ordering parts for an Iseki SG13 without the factory parts catalog, you are wasting time and risking getting the wrong piece. I have seen it too many times – a guy buys a part based on a blurry screenshot from an online forum, and it does not fit. Then the tractor sits for another week. This Iseki SG13 Parts Catalog solves that. It is the exact same document used by dealers to order parts. No reprints, no third-party errors. 167 pages of exploded diagrams and part numbers straight from Iseki & Co., Ltd.

Iseki SG13 Parts Catalog: What’s Inside

Open this catalog and you find every component and option part used across the SG13 lineup. Table on page 1 lists the model variants – SG13 with different sections for Japan, Germany, UK, France, and Italy. Engine codes E255-G and E255-G01 are noted for each destination. If you are working on a 48E20S model built for Germany, this catalog tells you exactly which parts apply and which do not. That level of specificity is what keeps a job from turning into a parts run.

How to Use the Parts Catalog

Page 2 explains the key system. Each diagram has a key number (①, ②, etc.) that links to a table with part code, description, quantity, and model applicability. Some part numbers start with V or W – those are standard market parts you can cross-check locally. The symbols are simple: ‘*’ means standard, ‘T’ for optional, ‘R’ for replacement. Serial number ranges are given so you get the right revision. ITC codes show interchangeability between old and new parts. Spend ten minutes studying page 2 and you will not order a wrong part again.

Get the Right Part the First Time

Aftermarket parts catalogs compile data from multiple sources. They drop a number, but they do not tell you if that part was superseded or only fits a specific serial range. This OEM catalog lists every supersession. The ITC column (page 2) uses arrows: OLD ↔ NEW means they can swap; OLD → NEW means only old works with new; OLD ↮ NEW means no interchange. That information saves you the headache of bolting on a part that does not match the hole pattern or port location. On an agricultural machine like the SG13, a mismatched filter or hydraulic fitting shuts you down fast.

3 Systems Covered in This Catalog

The catalog breaks down the tractor into assemblies. You get the engine section with gaskets, rings, and fuel system parts. The drivetrain section covers axles, transmission, and PTO components. Hydraulics include pumps, cylinders, and steering gear – each with separate diagrams. Because this is a parts catalog, not a service manual, you do not get repair procedures. You get the numbers that let you order the correct seal, bearing, or bracket. Pair it with a service manual when you are ready to tear down.

Is This Catalog for You?

If you own or maintain an Iseki SG13, yes. It is for the home-garage mechanic who wants to order parts with confidence and the shop owner who needs to reduce customer wait times. Beginners will find the diagrams clear enough to follow after a few tries. Professionals will appreciate the direct OEM data without marketing fluff. You can find related Iseki documentation like the Iseki TS3110 Parts Catalog – Factory OEM Parts Breakdown, the Iseki TXG23 TXG23FH TXG23TH TXG23E 2003 Parts Catalog, and the Iseki TXG23 Parts Catalog – Factory OEM Parts Breakdown. For broader context on why factory specs matter, read Automotive Industry Overview and Automotive Industry Overview.

Can I use this catalog to service my SG13?

No, this is a parts catalog, not a service manual.

How do I find the correct part number using the diagrams?

Refer to page 2 of the catalog. Each diagram has a key number that corresponds to a part number in the table. The table includes the part code, description, quantity per unit, and which models it fits. Pay attention to the symbols: ‘*’ for standard, ‘T’ for optional, ‘R’ for replacement. Also check serial number ranges. If a part number starts with V or W, it is a standard market part. The ITC column shows interchangeability between old and new parts. This system takes a few minutes to learn but eliminates guesswork.

Stop guessing on part numbers and getting stuck with wrong returns. Access the Factory Manual and get the OEM catalog on your screen or printed out for the shop. That piece of paper with the correct part code is what separates a one-and-done repair from a two-week fiasco.
