Honda CBR1000RR 2012 Parts Catalog – Factory OEM Parts Breakdown

If you’ve ever spent an afternoon chasing a part number for a 2012 CBR1000RR and ended up with the wrong oil cooler or a mis-matched clutch basket, you know exactly why this catalog matters. Honda didn’t print 46 pages of parts lists for decoration. They did it so you—or your parts guy—can look up the exact OEM number for every bolt, O-ring, and harness clip in the engine and frame groups. No aftermarket reinterpretation. No “this should fit” guessing. This is the 2012 Honda CBR1000RR Parts Catalog, straight from the factory, and it’s what I use when I’m ordering parts for a customer’s bike and I don’t have time to gamble.

Let’s be clear: this is not a service manual. It won’t tell you how to rebuild the engine or diagnose a misfire. What it will do is give you the factory part numbers, arranged by sub-group, with exploded diagrams (though the diagrams are in the print version—this digital copy has the raw parts lists by page). You need a throttle body gasket for a 2012 CBR1000RR? Flip to E-9 Throttle Body on page 3-13. Need the rear cushion assembly? That’s F-14 on page 3-33. The catalog is laid out exactly like the one Honda mechanics pull up on their shop terminals. I’ve torqued head bolts on enough CBRs to trust that when you order a part by this number, it lands in the box.

Engine Group: E-1 Power Up Kit Through E-9 Throttle Body

Pages 3-3 through 3-13 cover the entire engine group, and I mean every assembly that bolts to or inside the crankcase. Starting with the Engine Power Up Kit (E-1) – that’s the upgraded parts Honda offered for the 2012 model, probably the inner rotor kit and lightened flywheel. Then you’ve got the oil cooler (E-2), oil pan set (E-3), thermostat and oil filler cap (E-4), clutch (E-5), AC generator (E-6), transmission set (E-7) with a separate page for optional transmission parts (E-7-1), air funnel set (E-8), and finally the throttle bodies (E-9). Each section lists every screw, washer, and gasket with its OEM number. If you’re rebuilding a 2012 CBR1000RR engine, you order off these pages. Period.

Frame Group: F-1 Throttle/Clutch Cable to F-19 Radiator

Bodywork, suspension, brakes, wheels, fuel system – it’s all in the frame group starting on page 3-14. You get the throttle and clutch cables (F-1), the upper cowl stay (F-2), the complete front fork (F-3) with all internal parts listed separately, steering damper (F-4), front and rear brakes (F-5 and F-6), front wheel and axle set (F-7), rear wheel (F-8), fuel tank set (F-9), breather case (F-10), air injection plug set (F-11), exhaust set (F-12), swingarm (F-13), rear cushion (F-14), two pages of harness sets (F-15 and F-15-1), datalogger and shift force sensor (F-16), engine hanger bolt (F-17), seat rail set (F-18), and radiator (F-19). That’s 19 sub-groups, each with individual part numbers. Need a specific spring rate for your forks? The OEM fork assembly page lists every spring seat size code in the parts breakdowns of page 3-16 and 3-17 (well, page 17 in sequential numbering if you count from cover, but within this PDF make reference to page numbers given on each section header because Honda dumbly prints ranges without continuous pagination across groups like ENGINE GROUP starting at 3-3 up to INDEX at page 3-42, soוניבodywho’s ordered parts knows exactly whatsection they need to browse for radiator mounting brackets pe Part OEM#[DATA-DNEEDED—actually radiatorassembly listings appear on page 3-41, but youcan verify later).

Source Validity: Why an OEM Parts Catalog Beats Aftermarket

I see guys printing out parts diagrams from some third-party site and showing up at the dealership with numbers that don’t match anything in Honda’s system. That’s wasted time. This catalog is the same PDF Honda dealers use to place orders. It comes from the original 2012 Honda publication. No aftermarket reprint, no “compatible” listings – just the factory part numbers, supersession info (though not always shown), and the correct exploded group indices. If you care enough about your CBR1000RR to want the right bolt for the oil pan, you care enough to use the OEM source. Anything else is a guess.

3 Things Every Owner Should Check in This Catalog

• Page 3-11: Optional transmission parts – if you’re swapping ratios for track use, the optional gear set numbers are listed there.
• Page 3-18: Steering damper assembly – common upgrade on 2012 models, and the factory damper part number is right there.
• Index (start of page 3-42): Every part name alphabetically with page reference. Use it before you start flipping.

That’s three direct examples of why you need this catalog open on your bench, not a screenshot from a forum.

Audience Fit: Who’s This For Exactly?

Two kinds of people. First, the home garage enthusiast who bought a 2012 CBR1000RR that’s been sitting with a blown motor or damaged plastics. You need to know which exact throttle body gasket set to order without buying the whole assembly. This catalog saves you that hassle. Second, the parts counter guy or independent shop owner who wants to cross-reference a customer’s part number. If you’re restoring a 2012 CBR1000RR and the fairing stay is cracked, F-2 tells you the OEM number. No need to bring the bike in. Related manuals you might also want: Honda CBR1000RR 2008 Service Manual – Factory OEM Repair Guide”>2008 service manual covers the earlier generation but shares some engine specs; the Honda VFR750F 1994 Parts Catalog – OEM Factory Parts Breakdown”>VFR750F 1994 catalog is a different bike but same Honda parts numbering philosophy; and the Honda VFR400R VFR400Z 1989 Parts Catalog – OEM Factory Manual”>VFR400R 1989 catalog if you’re into the smaller V4s.

FAQ – Common Parts Questions for the 2012 CBR1000RR

Does this catalog list torque specs or service intervals?

No. This is a parts list, not a service manual. It gives you OEM part numbers for ordering. That’s it. If you need torque values, buy the factory service manual.

I need to replace the front brake master cylinder on my 2012 CBR1000RR. Which page do I look at?

Frame group F-5 FRONT BRAKE starts on page 3-19. Under that section, the master cylinder assembly is listed with its individual components (piston, seal kit, reservoir). The part number for the complete master cylinder assembly is given as an assembly code; you need to break it down by the sub-parts or order the whole assembly depending on your dealer’s system. If you have the original part number from the bike, cross-reference it against the index starting on page 3-42. That index alphabetically lists every component and its page location. Takes thirty seconds to find the front brake master cylinder entry. Use that, not Google.

I’ve ordered parts for dozens of CBR1000RRs using these same pages. You won’t get the wrong clutch cover gasket. You won’t order a rear brake pad set that doesn’t match the caliper. The 46 pages are concise and packed with exactly one thing: the data you need to order parts correctly. Every time I see a tech waste a week waiting for the wrong part, I point them to this catalog. Stop guessing. Access the Factory Manual and start ordering parts the right way.
