GEHL 7285, 7335 Parts Catalog – Factory OEM Documentation

You ordered a replacement valve for your GEHL 7285 mixer feeder based on a cross-reference from a parts website. Three days later, the bolt holes don’t line up. The threads are metric when you needed SAE. Now the machine sits, and you’re eating the return shipping. That’s exactly why I keep the factory OEM parts catalog on the bench. This GEHL 7285, 7335 Parts Catalog — 38 pages of exploded-view breakdowns, OEM part numbers, and torque call-outs — stops that guesswork cold.

GEHL 7285, 7335 Parts Catalog: Decal Locations and Safety Markings

Pages 2 through 5 in this GEHL 7285, 7335 Parts Catalog map every decal and safety label on the machine. Missing a warning decal after a repaint? These pages give you the exact part number and placement. The manual clearly states that “Right” and “Left” are determined from a position standing behind the Mixer Feeder facing the direction of travel — the Discharge Gate is on the left side. That orientation matters when you’re ordering a replacement decal for the wrong side.

PTO, Hitchjack, and Hydraulics Breakdown

Pages 6-7 cover the PTO shaft, hitchjack, guards, discharge gate, and hydraulic lines. Each component is numbered with a reference that ties directly to the parts list. If you need a new hydraulic fitting or a guard bracket, you pull the number from the exploded view, not from memory. For the hydraulics on page 20, the GEHL 7285, 7335 Parts Catalog includes a dedicated breakdown of the hydraulic motor and cylinders — each port, each seal, each mounting bolt is listed with an OEM part number. No cross-referencing needed.

Chaincase, Axles, and Scale Components

The drivetrain gets its own section. Chaincase components live on pages 10-11. Axles, wheels, scale and weighbars are on pages 12-13. When you’re replacing a sprocket or a bearing in the chaincase, the exploded view shows the assembly order. The parts list tells you the quantity used — often noted in parentheses after the reference number. The manual also warns that original replacement tires must be purchased locally; they sell wheel sets only. That’s a detail the aftermarket catalogs often skip.

Torque Values and Fastener Standards

Flipping to the inside back cover gives you the standard hardware torque specifications for all fasteners used on the machine. Unless otherwise noted, cap screws and bolts are Grade 5, cadmium or zinc plated, with Grade B hex nuts. If you see a hexagon symbol next to a reference number in an exploded view, that number inside the hexagon is the torque value in foot-pounds — right there on the page. No hunting for a separate chart. For example, if you’re reassembling the gearbox (Powerhead No. 8 on page 26), the torque spec for that particular bolt is called out on the same page.

Accessories and Conversion Kits

Pages 27 through 30 list accessories like the single valve conversion kit (page 27), battery box, magnet assembly, 3-point scale stand, safety tow chain, and the 1000 RPM conversion kit. Each kit comes with its own parts breakdown and part numbers. If you’re retrofitting an older GEHL 7335 with a remote scale indicator, the correct harness and bracket parts are right there. The index on pages 31-34 (alphabetical and numerical) lets you cross-reference any part number you already have to find its location in the catalog.

If your background is on diesel-driven equipment, you can reference general engine principles from this Wikipedia article on diesel engines to understand the power take-off coupling. For those who work on multiple GEHL models, also check the GEHL 7285, 7335, 7435, 7500 Installation Manual – Factory Specs for installation procedures, or the GEHL 7285 7335 7210 7435 7500 Installation Manual – OEM Specs for additional torque tables. For newer compact models, the GEHL SL4640, SL4840, SL5640, SL6640 2005 Parts Catalog covers skid-steer parts.

For further reading on engine fundamentals, see this Wikipedia article on diesel engines.

Does this catalog include torque specs?

Yes, on the inside back cover.

How do I verify a part number?

Use the model and serial number plate located on the left side of the main frame at the front left corner. Match the part description, reference number, and quantity from the exploded views. The alphabetical and numerical indexes on pages 31-34 help you find any part number quickly. Always specify the correct part number, full description, quantity, and unit model/serial number when ordering.
