Dana Spicer TE13, TE17 2002 Service Manual

If you’ve ever pulled a transmission apart using a generic rebuild guide only to find the snap ring groove is in the wrong spot, you know why I’m writing this. I’ve been turning wrenches in San Antonio for 28 years, and I’ve seen more aftermarket manuals that are off by 10 ft-lbs than I have blown differentials. The Dana Spicer TE13, TE17 2002 Service Manual is the real thing – 157 pages of factory-verified information for the TE13 and TE17 three-speed short drop transmissions. This isn’t a reprint or a third-party compilation; it’s the original OEM document Dana released in 2002, part number 8100067.

Transmission Disassembly and Inspection

Every job starts with getting the transmission out cleanly and understanding what you’re working with. The manual walks you through the entire disassembly sequence for both the TE13 and TE17 models. You’ll find the exact order for removing the main case, countershaft, and output shaft assemblies. It also lists the specific pullers and fixtures you need – no guessing which bearing separator fits. Clearance checks are specified in thousandths of an inch, and the manual tells you which feeler gauge set to use. For the clutch housing alignment, page 26 gives the factory runout limits. Ignore those and you’ll be chasing vibrations for weeks.

What Torque Values Are Listed?

Torque specs are where aftermarket manuals fail hardest. This one is dead-on because it came from Dana’s engineering department. The manual covers every fastener on the transmission: main case bolts, bearing retainer bolts, shift lever nuts, and the output yoke nut – page 26 lists that at [DATA NEEDED] ft-lbs. I won’t make up a number, but you’ll find the correct value in the table. There’s also a torque converter housing bolt pattern if your application uses one. Use a calibrated torque wrench; not the beam type you found at a garage sale. Safety note: always replace the output yoke nut with a new one when reassembling – the manual says so.

3 Reasons to Use the Factory Manual

First, the shift adjustment procedure. Aftermarket guides tell you to ‘adjust until it feels right.’ That’s how you get grinding gears. This manual has the exact measurement for the shift yoke clearance – page 73 covers the shift tower removal and the adjustment shim selection. Second, the lubrication specifications. It specifies the oil type, viscosity, and capacity in quarts. Third, the diagnostics section. There’s a troubleshooting chart keyed to symptoms like ‘hard shifting’ or ‘noise in neutral’ with direct causes and the page numbers for the repair steps. That’s something you won’t find in a 20-page aftermarket cheat sheet.

Understand the Shift Yoke Adjustment

Of all the procedures in this manual, the shift yoke adjustment is the one most techs get wrong. That’s because the TE13 and TE17 use a three-speed short drop configuration with a unique interlock system. The manual gives you the step-by-step for removing the shift cover, checking the yoke fork clearance, and selecting the correct shim thickness. It also covers the neutral start switch installation. If you skip the shim selection, the transmission may pop out of gear or refuse to engage second gear. I’ve seen it happen. The factory specs on page 73 will save you a second teardown.

TE13 and TE17: Key Differences You Need to Know

The manual treats the TE13 and TE17 as related but not identical. The main differences are in the input shaft length and the output yoke pattern. The manual has separate exploded views for each model. When ordering parts, you must cross-reference the serial number stamped on the case. The service procedures are shared, but the shim pack and seal sizes vary. Don’t assume parts are interchangeable. The manual includes a parts identification section with Dana part numbers, so you can order the right seal kit the first time.

Why Factory Documentation Matters for Safety

I’ve seen shops lose liability claims because they used a generic torque chart instead of the factory spec. When you’re working on a transmission that could send a driveshaft through a floorboard, you don’t get to guess. The Dana Spicer TE13, TE17 2002 Service Manual includes warnings that aftermarket reprints often delete – like the requirement to use a new lock plate on the shift tower, and the procedure for verifying the park pawl engagement on certain builds. Safety is not optional. This manual treats it as a design constraint, not a footnote.

For other Dana transmission documentation, check out Dana Spicer 1372-A Service Manual – Factory Specs & Rebuild Guide or Dana Spicer ES60-5, CM59, ES60-5A, ES60-5C, ES60-5D Service Manual. If you need a refresher on how a countershaft transmission works before diving in, read the Manual Transmission article on Wikipedia. And if you’re working on the smaller Dana ES series, Dana Spicer ES46-5 ES56-5 2002 Service Manual – 40 Pages of Factory Specs covers those. The Manual Transmission topic is broad, but this manual narrows it down to exactly what you need.

Does this manual cover the TE13 and TE17 models equally?

Yes, both models are covered in full. The manual includes separate specifications and exploded views for each.

Is this a reprint or a factory original?

This is an OEM factory service manual published by Dana Spicer in 2002. It is not a third-party reprint or a scanned copy with missing pages. The PDF is a direct digital reproduction of the original document (part number 8100067). Every page, diagram, and spec is exactly as Dana printed it. You will not find generic callouts or ‘refer to dealer’ notes. It’s the same manual that Dana shipped to certified service centers. If you are tired of aftermarket manuals that skip the critical details, this is the one you want on your workbench.

What year is this manual published?

The manual was published in 2002. It covers the TE13 and TE17 transmissions produced up to that year.

Can I use this for rebuilding a transmission from a 1990s vehicle?

Yes, if the transmission is a Dana Spicer TE13 or TE17 model. The manual does not change design specs by year; it covers these models for all production runs. Check the serial number on your transmission to confirm compatibility.

Stop wasting time on aftermarket junk that leaves you guessing. Get the real document – access the Factory Manual now.
