Bromma XD 25, XD 30 2006 Workshop Manual

You have a Bromma XD25 or XD30 on your lift and need real numbers – not some aftermarket rehash with guesses. I have seen guys waste a billable hour because they trusted a third‑party sheet for head bolt torque. That does not happen with this original OEM workshop manual. It is the factory appendix, code 60424134, for the 4158 series trucks equipped with the F4M2011 engine. Published 2006, 47 pages, and nothing in it is a copy of a copy. Every spec comes straight from Bromma.

Technical Operating Data Chapter 10

Chapter 10 is where you live if you are setting up a truck or verifying a replacement component. It starts with overall lift truck dimensions on page 2 – you need those numbers before you roll a unit into a bay with overhead clearance issues. Then it goes straight into technical data: wheel characteristics, noise and vibration levels, and the recommended lubricants and fluids on page 6. If you are topping off the transmission or the hydraulic system, that list saves you from grabbing the wrong oil and cooking a seal.

F4M2011 Engine: Data and Adjustment Values

Get the engine serial number plate location, cylinder numbering, and all adjustment data on page 8. Valve lash, injection timing, compression pressures – it is all there in imperial units. The manual also includes views of the control side and exhaust air side so you can trace the lubrication oil circuit and fuel circuit without pulling the whole engine apart. I have used those diagrams to chase a fuel pressure drop faster than any wiring schematic ever let me.

Transmission and Brake Specifications

Transmission technical features, power take‑off data, and brake specs are listed with their oil requirements. If you are swapping a pump or resealing the PTO, you need the exact fluid viscosity and capacity. This manual gives you those numbers. It also covers the checks and adjustments in Chapter 20 – that includes belt tension, brake pedal free play, and steering linkage play. Skipping those steps makes a test drive dangerous.

47 Pages of Factory Specs – No Aftermarket Guesswork

This is not a generic repair manual written by someone who never touched a lift truck. It is the original OEM document – appendix to the workshop manual series 4158. The code 60424134 and revision 01 from June 2006 confirm it. When you see a torque value in here, it came from Bromma’s engineering department, not a forum post. That matters when you are torquing wheel nuts or cylinder head bolts on a machine that lifts heavy loads.

Does This Manual Cover the Fuel System?

Yes. The fuel circuit is detailed in Chapter 10, showing line routing and component locations. For injection pump removal or injector service, you still need the specific engine service manual; this appendix covers the overall layout and adjustment data for the F4M2011. Use it to confirm pump timing marks and line order before you crack any fittings.

Removal and Fitting Operations – Chapter 30

Chapter 30 walks through removal and fitting of major components. It references the specific manuals for engine and transmission removal because those are separate documents – this is an appendix, not a full service manual. But it does give you the preliminary steps: draining fluids, disconnecting lines, labeling connectors. Follow that order and you avoid finding out the hard way that you left a drain plug tight.

Diagrams – Chapter 40

Chapter 40 contains the wiring and hydraulic diagrams for the XD25 and XD30. If you are chasing an electrical fault or a hydraulic leak, those schematics are your roadmap. They show connector pin numbers, wire colors, and pressure test points. Do not start a diagnostic without them.

Who Should Buy This Manual

If you own or work on Bromma XD25 or XD30 lift trucks built with the F4M2011 engine, this manual saves you from expensive mistakes. Home garage enthusiasts who service their own industrial equipment need the OEM data because a wrong torque value on a wheel lug can cause a wreck. Professional mechanics need it for the same reason – plus the liability goes away when you follow factory specs. The manual is 47 pages, but every page earns its keep.

For related factory documentation, check the OM Workshop Manual Series 4027-4030 XE35-XE50, the OM Workshop Literature XE60 XE70 XE80, and the OM Workshop Literature XE13/3ac to XE20ac Series 4032. Need background on lift truck transmissions? See the Manual Transmission entry and the Automotive Industry Overview for broader context.

FAQ

Is this manual only for the XD25 and XD30?

Yes, it covers both models with the F4M2011 engine.

What if I need to remove the transmission or engine – does this manual show that?

It gives the preparatory steps and references the specific service manuals for engine and transmission removal. The appendix is meant to supplement those manuals, not replace them. For the full removal procedure, you need the main workshop manual for the series 4158. This document supplies the torque specs, fluid capacities, and adjustment data that the main manual might omit for the XD25 and XD30 with the F4M2011. Do not attempt a removal without both documents on the bench.
