Atlas Copco CC424, CC524, CC4200, CC5200, CC6200 Operators Manual

You’re running a CC4200 on a job site, the foreman is yelling, and you’re not sure if the oil you’re using is right for the ambient temperature. That’s how equipment gets wrecked. This 152-page Atlas Copco CC424, CC524, CC4200, CC5200, CC6200 Operators Manual is what you should have cracked open before you fired up the engine. I’ve torqued enough head bolts to know that guessing costs time and money. This manual gives you the factory-approved way to operate, maintain, and stay alive around these vibratory rollers.

That’s the manual you need.

Technical Specifications: What You’ll Find on Page 15

Page 15 lists the vibration levels at the operator station, noise level in dB, and the electrical system specs. You’ll also find acceptable slope angles – that’s the kind of number you want before you drive a CC524 near a grade. Page 18 gives you weights and fluid volumes, so you know exactly how much hydraulic oil to put in. None of this ‘add until full’ nonsense. Factory spec means weight and volume down to the decimal. The manual also covers dimensions from side and top views, and working capacity. These numbers are for CC424, CC524, and CC6200 models, and they differ – don’t assume they’re the same.

Safety Procedures: The Real Cost of Skipping Page 5

Page 5 starts the safety general instructions. I don’t care if you’ve been running heavy equipment for 20 years – every machine has its own quirks. The CC6200 is a different beast than an old CC424. The manual tells you about driving near edges, work driving, and optional safety gear like edge cutters and air conditioning service. Skip these pages and you’re rolling dice with your life. There’s a whole section on Xenon working lights and how to handle them safely. And if you have ROPS or a cab, verify the Roll Over Protective Structure instructions on page 12. That’s not optional reading.

Audience: Who Needs This Operators Manual?

This isn’t a repair manual – it’s the operating and maintenance instruction book. If you own a CC424, CC524, CC4200, CC5200, or CC6200, you need this. If you’re renting one and the rental company didn’t give you the manual, you need this before you turn the key. Beginners: the section on ‘Lower ambient temperature – Freeze risk’ on page 11 could save you a cracked engine block. Fleet operators: keep a copy in the break room so every operator uses the same lube specs. For the DIY mechanic who services their own gear, this manual spells out the correct fluids and intervals. Pair it with the related Atlas Copco CC424 CC524 CC624 CC4200 CC5200 Operators Manual for a complete set.

Why Factory Documentation Beats Aftermarket Copies

Aftermarket manuals often reprint specs from unknown sources. This Operators Manual is the original Atlas Copco instruction book. Serial number ranges are listed for each model – that means you can verify it matches your machine. The CE marking and Declaration of conformity are included on page 3. You won’t find that in a third-party photocopy. The manual was printed in Sweden and includes translations of original instructions. If you’re also maintaining vehicles with a Manual Transmission, our separate manuals cover that – but for your roller, stick with factory documents. For additional Atlas Copco documentation, see Atlas Copco CC424/524/624/4200/5200/6200 Instruction manual and Atlas Copco CC424 CC4200 Operators Manual.

Special Instructions: Don’t Overlook Page 11

Page 11 covers standard lubricants and recommended oils. Important: if you’re working in ambient temperatures above 104°F or below freezing, you need the guidelines there. There’s a fire fighting section that every operator should read. And the battery handling and jump starting section (page 13) is critical if you ever need to boost a roller that won’t start. Follow the 24V jump start procedure exactly – wrong polarity and you fry the electrical system. The high pressure cleaning warning on page 12 is also something most operators ignore until water gets into a connector. Don’t be that guy. That’s the manual you need.

Frequently Asked Questions

Does this manual cover the CC624HF model?

Yes. The cover lists CC424/524/624HF. The manual includes all models.

What page shows the serial number range?

Page 1 lists serial number ranges for each model. You can match your machine’s serial number to confirm the manual covers your unit. For example, CC4200 serial numbers from 10000345x0A010586 to 10000347x0A010744. That’s important because if your serial falls outside, you may need a different edition. Always verify before using the manual for critical specs.

Is this manual suitable for repair work?

No. This is an Operators Manual for operation and maintenance. For major repairs like engine overhaul, you need a separate service manual. This manual covers daily checks, fluid fills, and safe operation.

Can I use this manual for a different Atlas Copco roller model?

Only if that model is listed on the cover. The specific machine configurations and specs differ. Using the wrong manual can lead to incorrect fluid capacities or safety data.

If you work on other heavy equipment with a Manual Transmission, our separate resources can help. But for your Atlas Copco roller, you want the factory book. Access the Factory Manual now and keep it on your tablet – the cost is less than one hour of downtime.
