Atlas Copco CA2500, CA3500, CA6000 2016 Operators Manual

You bought an Atlas Copco vibratory roller. Good machine. Now you need the book that tells you what the machine actually wants. This Atlas Copco CA2500, CA3500, CA6000 2016 Operators Manual is the factory document, not some aftermarket rewrite. It is 168 pages long, printed in Sweden in 2016, and covers the CA2500, CA3500, and CA6000 with the Cummins QSF 3.8 engine. If you are a shop owner or a DIY operator running one of these rollers, you need this on the tablet in the cab.

Safety is the part most guys skip. This manual dedicates the first dozen pages to safety. Page 5 lists general instructions. Page 7 covers operating near edges and work driving. If you do not read that before taking a machine onto a slope, you are gambling with your crew. The manual has a section on Roll Over Protective Structure (ROPS) and welding restrictions. Battery handling and jump starting (24V) are on page 13.

Safety Instructions: Why You Read Page 5 Before Starting

The table of contents spells it out: Safety – General instructions, Safety – when operating, Safety (Optional) for air conditioning. This is not a joke. The manual includes warnings for high pressure cleaning, fire fighting, and handling fluids. Every operator should review the section on driving near edges. The specifications for maximum slope angle are on page 15. Do not guess that.

We have that manual too: Atlas Copco CA2500 Vibratory Roller Operating & Maintenance Manual covers maintenance intervals and procedures.

Technical Specifications in the Atlas Copco CA2500, CA3500, CA6000 2016 Operators Manual

Pages 15 through 18 lay out technical specs: vibration data, noise levels, electrical system, slopes, dimensions from side and top view, weights and volumes, working capacity. You need these numbers for transport permits, job planning, and choosing the right trailer. The manual lists standard lubricants and fluids on page 11, with recommendations for high ambient temperatures above 40°C. No guesswork.

One thing I always check is the vibration operator station data. If the machine is shaking you apart, you need to ensure the settings match the manual. The CA6000 model has different specs than the CA2500. This manual covers all three.

Fluid Capacities and Recommended Lubricants

Page 11 is your go-to for lubricants. Standard oils and fluids are listed. Also note the high-temperature specs. The manual tells you what to use for the hydraulic system, the engine, and the vibratory system. Do not mix fluids. Also note the section on fluid-filled tires (ballasted tires) on page 22. That is a common source of mistakes. Hydraulic system details start on page 23. If you have a leak or pressure issue, you need the factory numbers. This manual gives you the system pressure specs. For more detailed repair steps, see the service manual: Atlas Copco XAHS 146 Dd 2006 Operators Manual – Factory Specs is for a different machine but shows the level of detail you want.

Jump Starting Procedure (24V) – Page 13

Battery handling and jump starting are covered on page 13. These machines run 24V systems. One wrong connection and you fry the ECU. The manual includes welding precautions too. If you are going to weld on the frame, you need to read the ROPS and welding section first. It can void the safety certification.

I have seen guys skip this and then complain when the machine won’t start. Follow the procedure exactly.

If you need a separate manual for the transmission, check our Manual Transmission category. And for more on the engine, see Manual Transmission – though that may be for automotive; we have dedicated engine manuals too.

3 Critical Safety Warnings from the Manual

First: do not operate near edges without reading page 7. Second: do not bypass the ROPS modifications. Third: when jump starting, use the correct sequence on page 13. These are not optional. The manual also covers air conditioning safety if equipped.

Source Validity: Factory OEM vs Aftermarket

This is a genuine Atlas Copco publication, printed in Sweden. The file name is AtlasCopco_CA2500-CA3500-CA6000_2016_Operators_Manual_en-15031009239.pdf. It is not a reprint or a third-party compilation. Every page matches the factory print. If you rely on aftermarket summaries, you miss details like the CE marking and declaration of conformity on page 3.

At AutoRepairManuals, we stock the largest collection of OEM manuals in North America. You can verify the specs against the machine serial number range: 10000167xxA015825 – 10000168xxA018468. That covers production.

Related manuals you might need:

• Atlas Copco CA2500 Vibratory Roller Operating & Maintenance Manual
• Atlas Copco XAHS 146 Dd 2006 Operators Manual – Factory Specs
• Atlas Copco Boomer L1 D L2 D ML2 D Mark VII 2008 Operators Manual

Does this manual cover all three models (CA2500, CA3500, CA6000)?

Yes. One PDF covers all three with separate data for each.

Are torque specifications included?

This operators manual does not list internal engine or fastener torque values. It includes hydraulic system pressures and fluid capacities. For torque specs, you need the service manual. The manual covers daily checks but not disassembly. I always recommend having both manuals if you do any component work. Page 23 gives hydraulic pressures but that’s it. If you need to rebuild the vibratory drive or the engine, this is not the right document. However, it does list all the specifications you need for safe operation, including noise levels, slope limits, and dimensions. That information is critical for job planning and compliance. Many operators ignore the weight and volume data on page 18, but that is key when transporting the machine. So while torque values are absent, the manual is still essential for daily use. The factory manual is the only way to get these numbers right.

Can I use this for daily maintenance?

Absolutely. It has sections on standard lubricants, jump starting, and general operation. It also includes noise level and vibration data for operator safety.

Is this a reprint or a scanned copy?

This is a factory OEM PDF direct from Atlas Copco. Clear, searchable, 168 pages. No third-party markings. The original file is from 2016.

Access the Factory Manual now from AutoRepairManuals and keep your roller running right.
