Atlas Copco CA1400 2016 Parts Catalog – Factory Parts for the Vibratory Roller

I have spent 28 years under hoods and under heavy equipment, and there is one thing that burns my ass more than a stripped bolt: ordering the wrong part because the exploded view looks like a Picasso painting. If you are maintaining an Atlas Copco CA1400 vibratory roller, you need the exact OEM part numbers, not some aftermarket reprint that swapped out a bearing for something that looks close. This Atlas Copco CA1400 2016 Parts Catalog is the real deal – 208 pages of factory-issue numbers, service kit references, and drawings that match what Atlas Copco actually bolted on at the factory. No guessing, no “that should fit”.

What’s Actually Inside This Parts Catalog

This catalog covers the CA1400 (IIIB/T4i) with serial number range 10000169xxA016225 and up. Engine is the Kubota V3307-CR-TE4-DYP-1 – 55.4 kW, and the manual breaks down every system into indexed sections. Here is exactly what you get from page 1 to page 208:

• Service kits – 50h, 500h, 1000h, 1500h, 2000h intervals with Plus variants and a start-up kit. Part numbers like 4812159573.
• Repair kits – eccentric shaft kit (4812159976), drum rotation kit (4812157275), shock absorber kit for drum (4812159975).
• Frame sections – front frame, steering hitch, rear frame, bumper, and optional scrapers (rubber, PD Hardox).
• Drum and transmission – drum drive, bearing, splined sleeve, rear axle assembly (4700378165), differential with limited slip, housing, brakes, planet gear.
• Engine room – cooling system, hydraulic motor (4812123163), air cleaner, fuel system, exhaust, expansion tank, lock handles, fender module.
• Hydraulic system – propulsion front/back, vibration front/back, hydraulic pump (4812116870), steering valve (4812123629), cylinders.
• Electrical equipment – cables, ECU module, back-up alarm, battery disconnector, relay holder, fuse box, lights (driving, side, rotating beacon, working lights), and registration plate holder.
• Driver’s platform – forward-reverse control, steering column, instrument panel, seat, ROPS.
• Decals – all factory decal part numbers.
• Optional equipment – rear view mirror, fire extinguisher, SMV-sign.
• Parts Index – Appendix B, paging through 208 pages.

Service and Repair Kits: The Numbers You Need

If you are rebuilding a drum or doing a 500-hour service, you don’t want to piece together a seal kit from three different suppliers. This catalog lists every service kit with its part number. For example, the 1000h service kit is 4812159486, and the corresponding Plus kit is 4812159487. The eccentric shaft repair kit (page 23) gives you every bearing and seal needed. Drum rotation kit (page 25) – same deal. Those numbers are the only ones that guarantee the parts will push into a press fit without being 0.002” off. I have seen aftermarket seal kits that leaked oil within 50 hours because the o-ring groove was cut wrong. Do not waste your shop’s time. Use OEM numbers.

Need the part number for the steering valve? It is 4812123629. Hydraulic pump on the same machine? 4812116870. Engine assembly itself? 4812123920 – that is the Kubota V3307-CR-TE4-DYP-1, 55.4 kW. Every component has a reference number that ties directly to the Atlas Copco supply chain.

Does It Cover the Kubota V3307 Engine?

Yes, and it does not just list the long block. The engine section (starting page 75) includes brackets, belt guard, cooling system with the hydraulic motor, air cleaner, fuel system, fuel tank, fuel hoses, exhaust system, expansion tank, engine structure, lock handles, and fender module. If you need to replace a coolant hose or a fuel line clamp, the part number is there. This is not a generic engine manual – it is specific to the CA1400 installation. The cooling system even has a dedicated hydraulic motor (4812123163) that drives the fan.

Frame, Drum, and Hydraulic Systems – Full Breakdown

Every welded assembly and bolt-on part for the frame is shown in exploded views. The front frame, steering hitch, rear frame, bumper – all separate. The scrapers have four different module options: standard, rubber, assembly, and PD Hardox. The drum section covers the drum itself, drive, suspension, bearing, splined sleeve, and optional pad shell. Hydraulic system is split into propulsion front and back (two separate circuits), vibration front and back, rear frame hydraulics, tank module, pump, steering, and cylinders. Each subsection has its own table of part numbers.

Transmission: the rear axle assembly (4700378165) includes the differential with limited slip (page 65), differential housing and brakes (page 67), and planet gear (page 71). If you are rebuilding the final drive, you will find every shim, gear, and seal listed.

Source Authenticity: Why OEM Beats Aftermarket Every Time

This is an original factory print from Dynapac Compaction Equipment AB (Atlas Copco), published in 2016, part number 4812160790. The OCR excerpt at the top of this page shows the warning: “Use only authorized parts. Any damage or malfunction caused by the use of unauthorized parts is not covered by Warranty or Product Liability.” That is not just legalese – I have seen a $12,000 drum wrecked because someone used a Chinese bearing that had the wrong internal clearance. Aftermarket catalogs often transpose exploded views from older models, leaving you with parts that sort-of fit but fail early. This manual is the same one the dealer’s parts counter uses. You get the exact illustrations and revision levels from the 2014-2016 production run. If you care about downtime costs, pay for the OEM data once.

Who Needs This Catalog?

If you own or maintain an Atlas Copco CA1400 vibratory roller (Dynapac brand) – whether you are a rental fleet manager, a construction company mechanic, or a solo operator – this Parts Catalog is the only way to order parts without calling the dealer and reading off serial numbers. You will also need the corresponding Atlas Copco CA1400 User Manual – Factory Specs for Vibratory Roller for operating limits and torque specs. If you work on older Atlas Copco equipment, check out the Atlas Copco XRVS455Md 1998 Parts Catalog – OEM Factory Parts List and the Atlas Copco V6000TV 2015 Parts Catalog – OEM Factory Parts List for other models. For context on how proper documentation affects fleet uptime, read this Automotive Industry Overview.

Is this the same as a service repair manual?

No. This is a parts catalog – it gives you part numbers, exploded views, and kit references. For repair procedures, torque specs, and adjustments, you need the service manual. The parts catalog helps you order the correct components before you start the job.

Can I use it for a CA1400 with a different serial number prefix?

This catalog covers S/N 10000169xxA016225 and up. Earlier machines (IIIB/Tier 3) may have different parts. Check your serial number plate. If your machine falls outside that range, you need the earlier edition. We also carry older CA1400 parts listings – contact us if you need help cross-referencing.

You have the serial number, you have the machine in the shop, and you need the right bearing to get back to compacting asphalt. Do not waste two days chasing wrong parts. Access the Factory Manual and get the OEM part numbers that match your CA1400. It is a PDF with 208 pages, fully searchable, and printable. Put it on your shop tablet and stop flipping through dog-eared copies that were last updated in 2008.
