Terex AC200-1 Operators Manual – 16 Pages of Factory Runner Operation

I’ve seen too many crane repairs go sideways because someone grabbed a third-party pdf that skipped the critical steps. The Terex AC200-1 Operators Manual is a 16-page factory document, not a rehash. It covers the optional runner system used on the AC200-1 crane. If you’re fitting that runner or folding it for transport, you need the OEM procedure — not assumptions. This manual came off the Terex server, and it shows. No generic diagrams, no missing torque callouts.

Runner General Information – Page 3

Page 3 lays out the runner’s purpose. The hoist rope can be reeved up to four times using the runner (80). The hook block stays reeved on the main boom head. That matters when you’re switching between load raising and transport. The manual also warns that main boom operation with the runner fitted in transport position reduces load capacity. That’s not the kind of detail you get from a knockoff. Terex AC200-1 Crane Head Roller Operation Manual covers a different attachment, but the same attention to clearance applies.

The runner can only be fitted onto a crane with matching construction number. Exceptions require documented proof in the crane passport. A lot of shops skip that check. Don’t.

Separate Transport – Page 7

When you need to move the runner separately from the crane, page 7 spells out the rigging points and axle load limits. The manual calls for suitable lifting equipment — ladders, platforms, auxiliary cranes. Walking on the boom is prohibited. I’ve seen the aftermath of that shortcut. Not pretty.

Converting to the Folded Position – Page 13

Page 13 details the conversion procedure. Folding the runner to the side of the main boom head requires specific sequences to avoid crushing. The manual states: “When fitting or removing the runner, there is risk of crushing between the main boom head and the runner.” That’s a direct quote. Follow the procedure, use the right lifting gear, and check all tubes for damage before proceeding. If you find damaged tubes, stop. Period.

Folding into Transport Position – Page 15

Page 15 walks through the final folding steps. The runner’s draw bars must be inspected at least once a year by a specialist per accident prevention regulations (VBG 9a / BGV D6). Inspection intervals depend on operating conditions — heavier use means shorter intervals. Document each inspection in the crane log. This isn’t optional. Terex AC200-1 Main Boom Dismantling & Assembly Training covers complementary procedures for the main boom, but the runner manual stands on its own for its component.

Why This 16-Page Manual Matters

You get 16 pages of OEM data. No guesswork. The manual includes the warning that only trained personnel may fit or remove the runner. That’s not liability avoidance — it’s how you keep the crane working and people alive. Terex AC200-1 Operation: Telescoping Training Manual is a separate document for the boom, but this runner manual is the only source for that specific attachment. If you try to use a generic crane operation guide for the runner, you’ll miss the folding clearance specs and the draw bar inspection intervals. I’ve seen hoist ropes fouled because someone thought “it’s close enough.” Close isn’t enough on a crane.

OEM vs Aftermarket – Source Authenticity

This is a direct scan of the Terex Global Crane Training document. The file name ends with “en-28931013082.pdf” which matches Terex’s internal numbering. Aftermarket “manuals” often re-type procedures and introduce errors — wrong diagrams, missing pages, incorrect torque values. This one gives you the original layout with the original warnings. No reprints. Compare it to a Manual Transmission guide from a third-party and you’ll see the difference in density. The OEM version doesn’t sugarcoat anything.

If you need to check the crane’s superstructure electric content, the manual covers it on page 2 with a table of contents. You get sections: Runner general information, Separate transport, Converting to folded position, Folding into transport position. That’s it. Clean. No filler.

FAQ

Does this manual cover the runner assembly for all AC200-1 cranes?

Yes, but only for cranes with matching construction numbers as marked on the runner. Exceptions require crane passport documentation.

What is the page count and what sections are included?

16 pages. Sections: Runner general information (page 3), Separate transport (page 7), Converting to folded position (page 13), Folding into transport position (page 15). Also includes a superstructure electric content table on page 2 and important notes on page 3 with safety warnings. The manual emphasizes that only trained personnel may perform assembly. It also mandates annual specialist inspection of draw bars per VBG 9a / BGV D6 regulations. Inspection intervals must be shortened under heavy use. This is not a general crane operation manual — it is specific to the runner attachment. If you need torque specs for the main boom, you’ll want the Manual Transmission or the separate boom manual, but for runner folding and transport, this is the only OEM source.

This is the factory document. Not a scan of a scan. Not a rewrite. 16 pages, direct from Terex. If you work on AC200-1 cranes with the optional runner, you need this on your tablet or printed out. Access the Factory Manual and stop guessing about folding sequences and axle loads.
