Schäffer Lader Parts Catalog

If you’ve ever tried to order a replacement part for a Schäffer Lader using some generic aftermarket list, you know the drill: wrong number, wrong fit, wasted time. This Schäffer Lader Parts Catalog is the original OEM document, 54 pages thick, printed for the Kubota V2003-T-EBB diesel engine used in these loaders. No reprints, no third-party reinterpretation – just the factory illustrations and part numbers straight from Schäffer. I’ve been torquing head bolts for 28 years, and I can tell you: if you need a part, start here.

Parts Breakdown by Engine System

Page 3 kicks off the illustrated parts list with the full Kubota V2003-T-EBB-EC-1 engine. Every subsystem gets its own exploded view: cylinder head, oil pump, fuel injection pump, cooling fan, alternator bracket. Each illustration calls out individual components with a reference number that links directly to the ordering table. You won’t find torque specs here – this is a parts catalog, not a service manual. What you get is the exact part name, part number, and quantity per engine. Need a gasket set for the head? Find it in the top-end section. Need the injection pipe clamps? They’re in the fuel system spread.

Does This Catalog Cover the Fuel System?

It does – and thoroughly. The fuel system chapter lists every pipe, clamp, filter head, and injection nozzle for the V2003-T-EBB. Part numbers for the Kubota 97898-06390 filter assembly are included. If you’re rebuilding a Lader that sat in a field for five years, you’ll need to cross-reference the injection pump components. This catalog uses the original Kubota numbering scheme, so you can order directly from any Kubota dealer. I’ve seen techs waste half a day chasing a fuel return line part. With this catalog, you have the number in thirty seconds.

54 Pages of Factory-Sourced Data

Every page is a scan from the original Schäffer print – notice on page 5 states the catalog is subject to change without notice, but the revision date (29.04.2004) is fixed. The parts list covers both the European and North American engine variants. You get the code number 1G820-00000 for the base model. The illustrations use metric measurements and call out bolt grades where applicable (though again, not a torque document). If you need to order a cylinder head gasket for the V2003-T-EBB, the exploded view on the engine block page shows you exactly which gasket fits and its part number. No guesswork.

Why OEM Documentation Beats Aftermarket Lists

I’ve got a stack of aftermarket parts catalogs in my office that I use for nothing but fire-starting. They omit the small clips, the O-rings, the specialty bolts that always break. This Schäffer catalog includes every nut, bolt, washer, and seal as listed by the OEM. The exploded views are taken from the actual prototype drawings. You can hand this to a counterman and he’ll find the part in two minutes. Compare that to a generic list that says “cylinder head gasket – one size fits all” – that’s how you end up with a 20-ton loader down for a week. Access the factory document and work off the real data.

Ordering and Cross-Referencing

Page 1 shows the cover with the model V2003-T-EBB and the Kubota logo. The parts catalog is organized by engine system, not by loader model. So if you need a part for a Schäffer Lader that uses this engine, you look up the system, find the illustration, and pull the part number. The catalog also lists the quantity per engine – critical when ordering sets of bolts or seals. For example, the cylinder head bolt set shows twelve bolts – don’t order six. The manual is in German, English, and French, so language isn’t a barrier.

Frequently Asked Questions (FAQ)

Does this catalog include torque specifications?

No. This is a parts catalog only. You need the Schäffer service manual for torque values.

Can I use this catalog for a different Kubota engine?

It’s specific to the V2003-T-EBB. Other Kubota engines (e.g., D1503, V2203) have different part numbers. Check our related listings for those engines – Schäffer Lader Z600-BBS-EC-1 Spare Parts List and Schäffer Lader D1503-M-E3B Spare Parts List.

How do I find a part number for a starter motor?

Turn to the electrical section. The exploded views show the starter, solenoid, and mounting hardware. Each component has a reference number that matches a row in the parts table. The table lists the part number, description, and quantity. If the manual doesn’t cover a specific electrical system, check the Schäffer Lader Spare Parts List for additional coverage.

What if the part number in the catalog is superseded?

Kubota and Schäffer occasionally update part numbers. The catalog reflects the revision up to April 2004. For supersession information, contact a Kubota dealer with the old part number. The exploded views help identify the correct replacement even if the number changes. For background on how OEM systems work, see the Automotive Industry Overview for supply chain context. Another resource at Automotive Industry Overview explains parts numbering conventions.

I’ve seen too many loaders sitting dead because a parts order had the wrong item. Don’t be that guy. When you need to order parts for a Schäffer Lader with the Kubota V2003-T-EBB engine, get the direct-from-factory document. Access the Factory Manual now and have the real part numbers on your bench.
