Massey Ferguson 290 2000 Parts Catalog – 450 Pages of Factory Specs

If you are turning wrenches on a Massey Ferguson 290 and you are using an aftermarket parts list printed off some forum, stop right there. I have seen more stripped threads and misordered gaskets from bad part numbers than from worn-out wrenches. This is the Massey Ferguson 290 2000 Parts Catalog — 450 pages of the same documentation the dealer’s parts counter pulls up when you need a bearing or a seal. That matters because a part number off by one digit means a return trip and a dead tractor.

Engine and Transmission Coverage – Factory Diagrams

This catalog is split by major assemblies. Group 10 – Engine is the first section you will flip to if you are rebuilding the Perkins or replacing a head gasket. The exploded views show every bolt, washer, and shim with an OEM part number. Same goes for 25 – Transmission — eight-speed manual with live PTO or the optional two-speed shift? The page layouts let you cross-reference by revision code stamps on the casting. You do not guess, you match the casting number to the illustration.

Why You Need Factory Part Numbers – Not Generic Cross-References

An aftermarket parts book will tell you a certain bearing fits the input shaft. But it will not tell you that the Massey Ferguson 290 uses a specific caged roller with a snap ring groove at 5.1 mm from the face. The 450-page factory catalog shows that. Look at page 5 of the PDF excerpt — you can see the part numbers like 3019858X1 for a bolt and 828123M2 for a bearing. Those are Massey Ferguson’s own numbers, not a sales code that maps to three different dimensions. Order the right part the first time.

What This 450-Page Catalog Actually Includes

The Table of Contents runs from RECOMM. STOCKING PARTS through 180 – Standard Parts. You will find sections for 30 – Rear Axle (differential, bull gears), 60 – Front Axle and Steering (kingpins, tie rods), 70 – Hydraulics and Linkage (pump, lift cover, control valve), 100 – Sheet Metal (hood, fenders, grille), and 120 – Lighting Equipment. Each section has its own numerical index and alpha index — you can find a part by name or by cross-reference from the old number. This is the same book the dealer printed in October 2000 (part number 819783M12).

Over 450 pages of exploded isometric drawings with callouts. No photographs, no fluff — just the lines and part numbers you need to break down a sub-assembly or order a replacement. If you are replacing a hydraulic pump seal, you turn to 70 – Hydraulic & Linkage, find the pump housing page, and note the O-ring part number. That takes sixty seconds.

Finding the Right PTO and Hydraulic Parts – No Guessing

The PTO on a 290 can be independent or live, and the internal parts differ. In 25 – Transmission you will see the shift rails, detent springs, and actuator shafts broken into subassemblies. The same approach applies to the three-point hitch lift arms. The 70 – Hydraulic & Linkage section shows the complete linkage from the draft control lever down to the lift cylinder. You need the lift cover gasket? The part number is right there with the torque values for the cover bolts (not written in this manual, but the parts catalog is meant to be paired with the service manual — see related options below).

Source Validity – OEM Factory Document, Not a Third-Party Reprint

This is a direct scan of the original Massey Ferguson publication printed in 2000. The cover page carries the official part number 819783M12 and the English/French/German/Italian/Spanish parts of the data. Aftermarket compilations leave out the language-specific columns and sometimes merge part numbers from different tractor series without saying so. This catalog keeps all original cross-references — you can decode the revision letters stamped on your transmission case and find the exact part supersession. That is the difference between fixing it once and fixing it twice.

FAQ

Does this parts catalog include torque specs or repair procedures?

No. This is strictly a parts catalog — exploded diagrams and OEM part numbers. For torque specs and overhaul steps you need the service manual. Look at the Massey Ferguson 290 Parts Catalog to see if the matching service book is in stock.

Will this work for a 1970s Massey Ferguson 290?

Possibly if the tractor was built after the 2000 production date of this catalog — but you need to check the serial number range. Massey Ferguson updated parts through the 1990s and into the 2000s. The catalog includes supersession info for many earlier part numbers. If your serial number falls outside the covered range, consider the earlier Massey-Ferguson MF500 1977 Parts Catalog – 517 Pages Factory OEM or Massey-ferguson MF300 Parts Catalog – 607 Pages – Factory OEM for older MF models.

This manual sits on my bench next to my torque wrenches when I am working on a 290. It eliminates the phone call to the dealer parts desk and the three-day wait for the wrong gasket. If you are rebuilding the engine or swapping the transmission, stop using generic part number databases and get the factory book. Access the Factory Manual and start ordering the right parts.
