KTM 690 SMC 2008 Installation Manual

If you’re uncrating a new KTM 690 SMC 2008 Installation Manual and the dealer didn’t leave the setup sheet, you need this. I’ve seen more than one bike rolled out with loose handlebar clamps or a dead battery because somebody skipped the pre-delivery steps. This 17‑page factory document is what KTM dealers use before handover. It’s not a service manual – it’s the installation manual for getting the bike ride‑ready. No guesses, no aftermarket interpretations. Just the original 2008 KTM setup instructions.

SET‑UP: What You Do Before the Customer Sees the Bike

The manual starts with unpacking and setting up the vehicle. Page 5 shows you how to remove the box, leave the protective foil on (don’t peel it off until the work is done), and check for transport damage. Then you remove the handlebar from the transport holder. The manual lists the screws and handlebar clamps that need torquing. If you skip this step, the bars can shift during the first ride. I’ve seen it happen. This section also covers checking the enclosure list so you don’t miss a part. Aftermarket manuals gloss over this – the OEM version doesn’t.

WORK: Seat, Battery, Fairing, Footrest, Heel Protector

This chapter covers the mechanical assembly that must happen after unpacking. You’ll find procedures for removing and mounting the seat, removing and installing the battery, recharging the battery before first start, and opening/closing the filler cap. The manual walks through removing the rear fairing and fitting it back, plus the rear footrest bracket and heel protector. Each step has a symbol that tells you what tool to reach for. The battery recharge step is critical – these bikes sit in crates for months. If you don’t recharge properly, the battery sulfates. The manual calls out the correct charging current. Follow it.

Chassis Tightening Torques: What the Factory Says

The TECHNICAL DATA – CHASSIS TIGHTENING TORQUES section is where most guys get sloppy. You need to know the exact ft‑lb for the handlebar clamp bolts, footrest bracket bolts, and seat mounting points. KTM provides these values in the manual. I’ve had to re‑torque more than one bike that was assembled with a “good enough” feel. Use a torque wrench. The manual lists the values – you bring the tool. If you don’t have the spec, you’re guessing. This manual eliminates that.

SUBSTANCES: What Goes Where

This short section lists the fluids and lubricants required for initial setup. It’s not a full fluid chart, but it tells you which grease goes on the footrest pins and which thread locker to use on certain fasteners. The manual mentions the ISO 9001 certification and the KTM quality standards. If you’re assembling a bike for a customer, you don’t want to use the wrong grease – it can cause corrosion. The OEM specification is right here.

MEANS OF REPRESENTATION: Earning the Symbols

Page 4 explains the symbols used throughout the manual. KTM uses a specific icon for expected reactions and unexpected reactions. There’s also a page reference symbol. This might seem minor, but when you’re working fast, misreading an icon can cause you to overtighten something or skip a step. The manual uses typographical formats like bold for proprietary names and trademark indicators. If you’ve ever been confused by aftermarket drawings that don’t match the bike, you’ll appreciate this clarity.

Related manuals that pair with this one: KTM 690 SMC 2008 Parts Catalog for ordering fasteners, 2008 KTM 690 SMC Chassis Spare Parts Manual for exploded views, and KTM 950 Adventure 2003 User Manual – Factory Specs & Maintenance for larger twin comparisons. For general transmission basics, see Manual Transmission and Manual Transmission on Wikipedia.

Does this manual cover oil change instructions?

No. This is the setup/PDI manual, not a service manual. It covers pre-delivery tasks like unpacking, seat mounting, battery charging, fairing fitting, and initial torque checks. Oil change procedures are in the owner’s manual.

Are the torque values in Nm or ft-lb?

The manual lists values in Nm. You can convert using a standard chart. Page 11 of the PDF gives chassis tightening torques for all assembly points. Use a torque wrench – don’t guess.

You’ve got the bike. You’ve got the tools. Now get the one piece of paper that makes the difference between a safe, reliable first ride and a call from the customer at mile 10. Access the Factory Manual and print the PDI checklist. KTM built the spec – use it.
