JCB 1D Parts Catalog – Factory Part Numbers You Can Trust

Let me tell you something straight. If you’re rebuilding a JCB 1D and you don’t have the factory parts catalog open on your bench, you’re wasting time and money. I’ve seen guys order three different bearings before they got the right one. That’s billable hours down the drain. This JCB 1D Parts Catalog runs 119 pages and it’s printed by RSL Technical Publications, the OEM source. It’s not a reprint from some guy scanning dog-eared copies. It’s the real deal.

Brake System Breakdown – 15 cwt, 22½ cwt, 30 cwt

The index splits the brakes by capacity. You’ve got Brakes 15 cwt on page 9A, Brakes 22½ cwt on page 10A, and Brake Disc 30 cwt with pages 11A and 12B. The Brake Hydraulic section sits at 13A, and Brake Linkage at 16A. If you’re doing a full brake overhaul, you need to know which hub and drum dimensions match your machine. This catalog gives you the factory part numbers—AXB/135 Brake Drum, AXB/133 Spring – Brake Assembly—all referenced to the exploded views. You won’t guess and you won’t round up.

Engine – JCB and Petter Options

Two engine sections: Engine – JCB at 20A and Engine – Petter at 19A. The JCB engine is the one most of you will work on. The catalog lists every gasket, bearing, shim, and fastener. If you need to order a head gasket or a piston ring set, the part number is right there. Cross-reference with the numerical index starting on page iii. Want to understand how these engines relate to other equipment? Read this Wikipedia article on diesel engines for background on the JCB 1D’s power plant.

Axle and Drivetrain Coverage – Driving and Steering

Four axle sections: Axle – Driving 15 cwt (6A), 22½ cwt (7A), 30 cwt (8A), and Axle – Steering (5A). Each page shows the exploded assembly with every part labeled. The numerical index lists AXB/25 through AXB/136 with page numbers. If you’re swapping out a hub bearing (AXB/52) or a pinion (AXB/60), you’ve got the exact reference. No aftermarket guessing games.

Does This Manual Cover the Clutch and Gearbox?

Yes. Clutch and Linkage sits at 17A, Gearbox at 16A. The index also includes Handbrake Caliper (12A, 12B), Handbrake Lever (15A), and Hydraulic Brake Pipework for the 30 cwt (13A). Tool Kit (18A), Skips (2A), Steering Column (4A), Wheels and Tyres (3A) are all there. It’s a complete parts catalog for the JCB 1D, not just a few selected chapters.

Source Validity – Why OEM Matters for Parts Catalogs

I don’t trust aftermarket documentation. Period. This catalog is printed by RSL Technical Publications and carries publication number PC. A102. The numerical index runs part numbers like AXB/136 Bolt right to the page. When you order a part from a dealer, you hand them the number from this manual. If it doesn’t match, you’ll get the wrong piece. Aftermarket catalogs skip details or renumber things. This one is the factory doc.

Related Manuals for Your JCB Fleet

If you’re maintaining a mixed JCB shop, grab these as well: JCB JCB1 Parts Catalog – 94 Pages of Factory Part Numbers, JCB 7 7C 8C 8D Buckets & Attachments Index, and JCB Mini – Midi Excavators Technical Information Sheets.

FAQ – Two Questions You’ll Ask

Does this parts catalog include torque specs?

No. This is a parts catalog, not a service manual. It lists part numbers, exploded views, and quantities. For torque values, you need the corresponding service manual (sold separately).

Will this manual help me identify brake parts for a 30 cwt JCB 1D?

Yes. The Brake Disc 30 cwt section spans pages 11A and 12B. The Handbrake Caliper is on 12A and 12B. The Hydraulic Brake Pipework is on 13A. You’ll find every seal, piston, and pipe part number with the factory drawing.

Look, you can waste hours on forums chasing part numbers that may or may not be accurate. Or you can open this 119-page factory catalog and have the correct number in thirty seconds. That’s the difference between a professional job and a headache. Access the Factory Manual now and keep it on your tablet or printed out—you’ll use it every time you touch a JCB 1D.
