Ihimer 80 Parts Catalog – Stop Guessing Part Numbers

If you own an Ihimer 80 mini excavator and you’ve ever ordered the wrong sponge panel, you know the feeling. That part you pulled off the machine – it’s covered in grease, numbers are worn off, and the local parts counter hands you something that looks right but doesn’t fit. Then you lose half a day waiting for the return. This catalog – all 185 pages of it – is the factory-issued parts list that Ihimer shipped with the 80. It’s the same document a dealer uses. No guesswork, no aftermarket reprints. Every part number, every quantity, every serial number range is printed in black and white from the original Japanese engineering release.

Noise Absorbent Assembly – The Most Misordered Set

Page 1 of this catalog lists the “Noise Absorbent Ass’y” (key number 0) with part number X 8353 420 00. That’s the entire sound-deadening sponge assembly for the Ihimer 80. But most people don’t need the whole thing – they need one of the 23 individual sponge panels that go inside the canopy. Look at the list: panel D467 460 00, panel 4469 244 07, panel D467 453 00. Each one has a specific location and a serial number range starting at WK000001. If you order the wrong one, it won’t line up with the clips. Page 2 continues with panels 30 through 52, including a variant for “Haitter” after serial WK008001. The catalog tells you exactly which part fits your machine based on the serial number stamped on the frame. That’s information no aftermarket website is going to give you.

Get the right part the first time – IHI 80VX/NX3 Hydraulic Excavator Parts Catalog also covers later models, but this is the one for the base 80.

Why a Factory Parts Catalog Beats Aftermarket Numbers

I’ve seen techs try to cross-reference Ihimer parts with aftermarket databases and end up with bolts that are a quarter-inch too short. The Ihimer 80 uses metric fasteners, Japanese-style sealing washers, and sponge panels that are die-cut to exact dimensions. An aftermarket “equivalent” might be close, but close doesn’t seal against dust and noise. This catalog gives you the OEM part number – not a suggested substitute. If you see a part number like D467 472 00, you look it up on page 1 or 2, verify the serial number range, and order that exact piece. Automotive Industry Overview might tell you about design trends, but this catalog tells you what to bolt on.

How to Use the 185 Pages for Accurate Ordering

This isn’t a novel – you don’t read it cover to cover. You open to the section that matches your machine’s system. The table of contents is organized by assembly groups: engine, undercarriage, boom, electrical, and noise absorption. Each page shows a key number, the part number, a description in both Japanese and English, the quantity used, and the applicable serial number range. For example, on page 2, key number 47-1 is sponge panel D468 039 00, quantity 1, but only for machines after WK008001. If your serial is WK000001–WK008000, skip that line. If you’re replacing a sponge panel that’s disintegrating under the seat, find the illustration, match the key number, and write down the part number. Then order. That’s it.

Do You Need This Catalog If You Own an Ihimer 80?

Yes. Unless you enjoy taking parts off, driving to a dealer, hoping they guess right, and driving back to find a mismatch. The Ihimer 80 is a specialized machine – it’s not a pickup truck. Parts are not interchangeable with other brands. This catalog saves you the trip. It also saves you from stripping threads because you used the wrong bolt grade – every fastener specification is listed in the later pages. IHIMER 14NXT Blade Control Assy Parts List and IHIMER 14NXT Mini Excavator Spare Parts Catalog cover the bigger machines, but for the 80, this is the one.

Source Authenticity – OEM Japanese Documentation

The PDF you access is a direct scan of the original Ihimer factory parts catalog. It’s not a typed-out version with typos. It’s not a Chilton compilation. The Japanese characters for part names are right next to the English descriptions – ‘スポンジ パネル’ reads “Panel, Sponge.” Serial number columns are printed exactly as Ihimer intended. If you’ve ever been burned by a third-party PDF that skipped pages or blurred the key numbers, you’ll appreciate the clean, unaltered pages here. Every digit is readable. Every part number is the same one Ihimer engineers assigned.

Can I use this catalog to find parts for the Ihimer 80 if I don’t have the original part number?

Yes. The catalog groups parts by assembly – you find the illustration for the area you’re working on, match the key number to the list, and get the OEM part number. For the noise absorber alone, there are 52 sponge panels. Pick the right one by its shape in the drawing.

Does this catalog include torque specifications or repair steps?

No. This is a Parts Catalog – it lists part numbers, quantities, and serial number applicability. It does not contain step-by-step disassembly instructions or torque values. For those, you need the separate factory service manual.

Stop burning time and money on parts that don’t fit. Access the Factory Manual for the Ihimer 80 Parts Catalog now and get the exact numbers you need to keep that mini excavator running.
