GEHL 7210 Parts Catalog

Orders that go sideways because you picked the wrong auger drive or guessed at a torque spec cost time and money. Aftermarket catalogs skip the serial number break points, and then you’re stuck with a part that doesn’t fit. This GEHL 7210 Parts Catalog is an OEM factory print — 36 pages of exploded views, reference numbers, and torque callouts that match what came off the line. No reprints, no aftermarket redraws. You get the same document the dealer uses to pull parts.

GEHL puts the model and serial number on a plate on the left side of the main frame, left front corner. Write it down before you crack this catalog. Right and left are determined from behind the mixer feeder — discharge gate on the left. That orientation carries through every diagram in here. Page 2 makes that clear, along with the abbreviations table for fastener descriptions. Standard hardware torque values live on the inside back cover.

Decal Locations: Why This Section Matters

Pages 2 through 5 map every decal on the 7210. Safety decals fade, get scraped off, or are missing on used equipment. If you’re replacing a decal, you need the exact part number and placement. This section shows where each decal goes and gives the factory part number. Don’t rely on memory — one wrong decal location can obscure a pinch point or a PTO hazard. The catalog lists them all in order, so you can restore the machine to original safety configuration.

Not a cosmetic thing. It’s a liability thing. If you skip a safety decal and someone gets hurt, you’re on the hook. Use the decal index to verify every sticker before the machine goes back to work.

Augers, Rear Drive & Guard – Serial Number Break Points

Two separate sections cover the augers and rear drive: one for machines after SN8863 and another for before SN8864. That’s pages 8–9 and 10–11. If you order the wrong auger assembly because you ignored the serial number, you’ll be staring at a bolt pattern that doesn’t line up. The catalog gives you the exact reference numbers for each range. Check your serial number against the plate location described on page 2. This is where aftermarket catalogs fall apart — they merge the two ranges and you end up with a part that fits neither. The OEM manual keeps them separate.

Same deal with the component breakdowns on pages 23 and 24. The auger breakdowns split by the same serial number threshold. Page 23 covers after SN8863, page 24 covers before SN8864. No ambiguity.

Component Breakdowns: Universal Drive to Hydraulic Cylinder

Pages 20 through 25 drill into specific assemblies: Universal Drive (page 20), Hitchjacks from Hammerblow and Weasler (page 21), the 092664 Powerhead (page 22), the 091882 Hydraulic Cylinder (page 22), and the 065500 Hydraulic Motor (page 25). Each breakdown uses reference numbers. Some reference numbers have a quantity in parentheses, like (4), telling you how many of that part are used at that location. A teardrop symbol means a wet product — oil — and the number inside corresponds to the description in the parts list. A hexagon symbol next to a reference number gives you the torque value in foot-pounds for that fastener. That’s factory spec, not a generic table. Page 20 for the Universal Drive, for example, shows torque callouts right in the diagram.

If you’re rebuilding a powerhead or swapping a hydraulic cylinder, you need those torque values. The inside back cover gives standard hardware torque specs for Grade 5 bolts and Grade B nuts, but the inline hexagon values are assembly-specific. Don’t mix them up.

Accessories: Single Valve 804570 and Transport Lighting Kit

Pages 26–28 cover the bolt-on extras. The Single Valve 804570, Transport Lighting Kit, Safety Chain, Battery Box 804569, Magnet Assembly 804568, and Tripod Kit. Each accessory comes with its own parts list and exploded view. The lighting kit, for instance, includes the wiring harness and brackets — part numbers are there so you can order exactly what broke. The safety chain section lists the chain, hooks, and mounting hardware. If you’re adding a magnet assembly to an older 7210, page 28 shows the mounting plate and hardware. Don’t try to cobble together parts from a generic catalog — the OEM brackets are shaped to clear the frame.

One note from the introduction: GEHL does not sell replacement tires through their parts system. Replacement wheel sets are available, but the tire itself must be purchased locally. The wheel set listing includes tire size information so you can buy the correct tire from a local dealer. That’s on page 14–15 in the axles, wheels, and scale section.

What Torque Values Are Listed on the Inside Back Cover?

Standard hardware torque specifications for cap screws, bolts, and nuts are printed on the inside back cover. Unless otherwise specified, all cap screws and bolts are Grade 5, cadmium or zinc plated. Hexagon nuts for Grade 5 screws are Grade B. The torque table gives values in foot-pounds for various thread sizes and grades. That’s your fallback when a diagram doesn’t have an inline hexagon symbol. But any time you see a hexagon number on an exploded view, use that number — it overrides the generic table. The manual tells you that on page 2. Trust the factory numbers, not a third-party chart. If you are curious about how these torque specs relate to engine fasteners, check out this Wikipedia article on diesel engines for background on bolt grades and clamping forces. Or directly this Wikipedia article on diesel engines for more on fasteners in high-vibration environments.

Get the Right Part Numbers for Your 7210

Numerical index on page 31 lists every part number in the catalog alphabetically with the page where it appears. Use it when you have a part number from an old parts list but need to verify the current supersession. The catalog also notes when a reference number has additional info like quantity or torque. If you are working on multiple GEHL machines, consider the GEHL 7285 7335 7210 7435 7500 Installation Manual – OEM Specs for setup procedures, or the GEHL SL4640, SL4840, SL5640, SL6640 2005 Parts Catalog for skid steer parts. For larger loader models, the GEHL SL7610, SL7710, SL7810 2005 Parts Catalog – OEM Factory Specs covers late-model machines.

Bottom line: if you are ordering parts for a 7210 Mixer Feeder, this 36-page Parts Catalog is the only document that gives you the serial number splits, factory torque callouts, and OEM part numbers. No generic diagrams, no merged revisions. You get the original GEHL service parts manual, scanned from the factory print.

Stop wasting time with parts that don’t fit. Access the Factory Manual and get the exact numbers you need.

Does this manual cover serial number breaks for the auger drive?

Yes. Two separate sections: one for after SN8863 (pages 8–9) and one for before SN8864 (pages 10–11). The component breakdowns on pages 23 and 24 also split by the same serial number threshold.

What is the difference between a Parts Catalog and a Service Manual?

A Parts Catalog gives you exploded views and part numbers for ordering components. A Service Manual gives you repair procedures, tolerances, and diagnostic steps. This is a Parts Catalog — 36 pages focused on part identification and ordering.

Where is the serial number plate located on the GEHL 7210?

On a plate on the left side of the main frame, left front corner. Page 2 describes the location. The catalog also defines “right” and “left” from a position behind the machine with the discharge gate on the left.

Can I use this catalog to order replacement tires?

No. Tires must be purchased locally per company policy.
