GEHL 480 2006 Parts Catalog – Factory Specs for Your All-Wheel-Steer Loader

If you’ve ever ordered a hydraulic hose that’s four inches too short or a seal kit that doesn’t match the O-ring groove, you know the pain of guessing parts off a generic aftermarket list. That stops here. The GEHL 480 2006 Parts Catalog is the only reference that tells you exactly which fastener, gasket, or assembly goes where, based on your loader’s serial number range. I’ve burned billable hours fixing other people’s “close enough” parts decisions. Do it once, do it right.

This catalog covers the 480 All-Wheel-Steer Loader beginning at serial number 342010001. It’s 104 pages of factory-original exploded views, part numbers, and fastener grades. Page 2 gives you the torque conversion: Newton-meters to foot-pounds by multiplying by 0.738. No guessing. No “metric bolt that looks close enough” crap.

Using the GEHL 480 2006 Parts Catalog on the Workbench

Pull a part out, read the number off the old piece, then cross-check it here. The manual uses alphabetical indices (A–Q and R–W) plus a numerical index. You can find any component in under a minute. Page 3 shows the table of contents—engine mounting, cylinder head, injection system, decal locations, you name it. Each exploded view includes reference numbers, and circled numbers mean a complete assembly. If you see a small bag icon in the illustration, that’s a seal kit (seals, O-rings, snap rings).

Why a Genuine GEHL Catalog Over Aftermarket?

Aftermarket parts catalogs copy the pictures but miss the serial-number breaks. This manual marks them clearly: (SN > XXXXX) means up to and including that number, (SN YYYYY >) means from that number onward. I’ve seen a guy install an injection pump from the wrong break and pop a line on startup. That’s a $400 mistake you avoid when you have the factory print. The inside back cover lists standard attaching hardware torque values—Grade 8.8 cap screws, zinc plated, proper ft-lbs. None of that “tighten until it squeaks” garbage.

Audience Fit: Who Actually Needs This?

Home garage guys restoring a 480 loader and shop owners with a fleet of GEHL machines. If you’re a DIYer who’s afraid of breaking expensive components, this catalog removes the guesswork. You get the exact part number for the engine block, cylinder head, injection system, fasteners, even the decals. No more calling the dealer and hoping the parts guy has your serial number in his head. You hand him the part number from page 37 and you’re done. Pros use this to quote jobs faster and avoid ordering the wrong seal kit. Liability drops when you can prove the replacement part matches the OEM spec.

Deciphering the Abbreviations Table

Open to page 2 and you’ll see a full abbreviation list: CS for cap screw, FHCS for flat head cap screw, HLN for hex lock nut, SHCS for socket head cap screw. Don’t laugh—I’ve had junior techs grab a carriage bolt when they needed a hex bolt because they didn’t read the callout. This catalog tells you exactly what fastener grade (Grade 8.8 unless specified) and whether it’s cadmium or zinc plated. That matters for corrosion resistance in wet loader work. The torque values are printed on the inside back cover—metric in Newton-meters and the conversion factor right there.

Source Validity: OEM Factory Print

This is not a reprint of some third-party scan. It’s the original GEHL factory document, Form No. 918116, Revision E, dated 10/06. The serial number tag location is specified (panel on the front of the cabin), and the manual defines “right” and “left” from the operator’s seat facing forward. That little detail saves you when you’re ordering a mirror or a control lever. For deeper engine theory, I’d send you over to this Wikipedia article on diesel engines – but for part identification, this catalog IS the authority. Want to see how the fuel injection system ties into the rest? this Wikipedia article on diesel engines gives background, but that’s not why you’re here. You need the part number, and this book has it.

Related Manuals for the 480 Loader

If you need operating instructions or service procedures, pair this catalog with the GEHL 480 2007 Operators Manual – OEM Factory Specs and the GEHL 480 2005 Service Manual – OEM Factory Specs for Loader. For other models in the same family, check the GEHL SL4640, SL4840, SL5640, SL6640 2005 Parts Catalog.

Frequently Asked Questions

Does this catalog replace the service manual?

No. It’s a parts catalog, not a repair manual.

How do I find the right part number using this catalog?

Start by locating your loader’s serial number (stamped on the front cabin panel). Cross-reference that with the serial number breaks listed at the start of each section. Then look up the component in the alphabetical index (A–Q or R–W) or the numerical index. Each exploded view gives a reference number that links to a part number, description, and quantity. Remember that circled reference numbers indicate a complete assembly. If the illustration shows a small bag, that’s a seal kit containing multiple O-rings and seals. Always double-check the fastener grade (Grade 8.8 cap screws unless noted) and torque values from the inside back cover before assembly.

Stop wasting time and money on parts that don’t fit. Access the Factory Manual now – you’ll have the GEHL 480 2006 Parts Catalog in your toolbox before your next job.
