GEHL 4610 Parts Catalog – The Only Way to Order Parts Without Guessing

I’ve been turning wrenches in San Antonio for 28 years, and I’ve seen more botched parts orders than I care to count. A guy walks in with a part that looks close, bolts it on, and then wonders why the hydrostat leaks or the lift arms bind. That’s what happens when you use a third-party parts list or try to match by eye. The GEHL 4610 Parts Catalog kills that guesswork. This is the actual 92-page factory document GEHL issued for their 4610 skid loader. Every part number, every exploded view, every hardware callout—it’s all in here. No aftermarket reprints, no generic cross-references. If you’re working on a 4610, this is the only parts manual you need on the bench.

Engine & Related Components (Before and After SN8500)

The manual splits content by serial number range—critical for a machine that had running changes. Pages 36-37 cover the engine and related components for units after SN8500, pages 38-39 for units before SN8501. You get the exact breakdown for the engine block, mounting hardware, and accessory drives. If you’re ordering a replacement alternator or a water pump, you’ll see the correct part number tied to your machine’s serial. The same goes for the air cleaner, alternator, muffler, and radiator sections on pages 40-43. Each line item includes the bolt grade and quantity. No hunting through generic diagrams.

Fuel System and Chassis Layout

Pages 6-7 show the chassis, fuel tank, grill, and access covers. The fuel tank mount brackets, the filler neck, the pick-up tube—all called out with part numbers. For the chassis, the decal locations are on pages 2-5, including the serial number decal inside the right chassis riser. You need that serial number before you order anything. This catalog makes it clear where to look. If your fuel system has a leak or you need a new tank cap, you’ll find the factory spec right here.

Wiring and Instrument Panel – Don’t Wing It

Electrical problems are a pain on any skid loader. Pages 16-17 cover the instrument panel, wiring, and battery for machines after SN8500; pages 18-19 for before SN8501. The wiring diagrams aren’t full schematic style, but the parts catalog shows every connector, harness, and switch as an exploded view with part numbers. You can order a replacement ignition switch or a gauge cluster without pulling a used part from a scrap machine. That saves hours of chasing wires. I’ve seen too many guys burn up a harness because they used a generic connector. Don’t be that guy.

Hydraulic and Hydrostatics – The Heart of the Machine

Pages 28-31 cover the hydraulic system with separate sections for before and after SN8501. The hydrostatics system (pages 32-35) includes the drive pumps and motors. Pages 49-61 dive into pumps, motors, valves, and cylinders with individual exploded views for left and right side drive pumps, main control valve, auxiliary control valve, and relief valves (1000 PSI and 1200 PSI). If you’re rebuilding a Columbus tilt cylinder or replacing a gear pump, you get the correct part breakdown. Torque specs for hydraulic fittings are referenced on the inside back cover. Never trust a torque value from a generic chart—use the factory spec.

3 Reasons Factory Parts Catalogs Beat Aftermarket Lists

Aftermarket parts catalogs often combine multiple models into one chart and skip hardware callouts. This 92-page OEM catalog does the opposite. First, it separates by serial number ranges. Second, it lists each attaching bolt, washer, and nut with grade and torque spec. Third, it includes options and accessories—pages 62-78 cover everything from work light kits to backhoe adapting packages to heater defroster kits. When you order a part from a dealer, they’ll ask for the part number from this catalog. You hand them the factory number, they hand you the right box. That’s time saved.

Hardware Torque Specs – Inside Back Cover

The inside back cover has the attaching hardware table and torque specifications. Standard grade 5 cap screws, inch-pound and foot-pound values, and a note that all cap screws are grade 5 unless otherwise specified. I’ve had guys ask me, “Do I really need to torque that bolt?” On a skid loader, yes. Loose bolts kill bearings and cause leaks. This table gives you the numbers for every fastener in the machine. Keep the manual open to that page while you reassemble.

FAQ

Does this catalog include part numbers for the engine fuel system?

Yes. The fuel system breakdown is on pages 6-7 with the tank and fittings.

How do I find the correct part if my serial number falls in a break range?

The manual separates sections by serial number ranges, e.g., “After SN8500” and “Before SN8501”. Locate your machine’s serial number from the decal inside the right chassis riser (page 2 tells you exactly where). Then use the corresponding pages for your range. If your serial is exactly on the break line, GEHL’s note says to use the earlier or later section based on which one matches your build date—check the decal or call a dealer if unsure. This catalog covers both ranges, so you won’t miss a part.

Every time I open a GEHL 4610, I grab this parts catalog. It eliminates the back-and-forth of ordering wrong parts, and it keeps the machine down for the shortest possible time. If you own or work on a 4610, get the factory document on your bench. Access the Factory Manual now from AutoRepairManuals and stop guessing what part goes where.
