Ford Focus RS, Focus ST 2011 Workshop Manual – OEM Factory Specs

I’ve been twisting wrenches since before most of you were born. When a Focus RS rolls into my bay with a boost leak or a Focus ST with a timing chain rattle, I don’t reach for a Chilton. I reach for the Ford Focus RS, Focus ST 2011 Workshop Manual – 1171 pages of factory-verified data. No aftermarket reprints, no third-party “summaries.” This is the exact binder Ford issued to dealer techs. If you’re paying shop labor rates because you’re afraid to pull a door panel, or if you’ve stripped one too many bolts guessing at torque, this PDF is your insurance.

1171 Pages of Factory Specs

That number isn’t padding. Every page comes from Ford’s own Group 5 – Body and Paint. You get the full breakdown: from the Body System – General Information (section 501-00) all the way through Frame and Mounting (section 502-00). The foreword on page 1 spells it out: Ford reserves the right to change specs without notice, but this document captures the exact tolerances and fastener grades at the time of print. If you’re swapping a bumper cover on a 2011 Focus ST, the clip locations and fastener torque come straight from the assembly line. Don’t trust a generic chart.

Body System General Information – What’s Covered

This manual breaks down every body sub-system. Section 501-00 opens with an overview of the body structure. Then it drills into Front End Body Panels (501-02), Body Closures (501-03), Interior Trim (501-05), Exterior Trim (501-08), Rear View Mirrors (501-09), Seating (501-10), Glass, Frames and Mechanisms (501-11), Instrument Panel and Console (501-12), Handles, Locks, Latches and Entry Systems (501-14), Wipers and Washers (501-16), Roof Opening Panel (501-17), Bumpers (501-19), Safety Belt System (501-20A), Supplemental Restraint System (501-20B), and three dedicated repair sections (501-25 through 501-30) for front end, roof, side, and rear sheet metal. Paint – General Information is section 501-36. If you’re doing a full restore on a Focus RS, this is your map.

Torque Values You Can Trust

Page 1 of the manual warns that Ford may change specs – but the values printed here are the ones that left the factory. I’ve seen Chilton manuals list a generic 30 lb-ft for a seat belt anchor bolt. Ford says 41 lb-ft. Guess which one keeps the belt from pulling out in a crash? The supplemental restraint system section (501-20B) includes specific fastener torque for airbag modules and pretensioners. Don’t eyeball it. The manual gives you NM and lb-ft.

Does This Manual Cover the Drivetrain?

This volume is dedicated to body and paint. If you need engine, transmission, or drivetrain procedures, look for the companion powertrain manual. However, for any work that involves removing body panels to access the engine bay – like pulling the bumper to replace an intercooler on a Focus ST – this manual gives you the correct clip removal steps and fastener locations. Saves you from breaking plastic retainers that cost $12 each from the dealer.

Get the Right Diagnosis Steps

Section 501-25 (Body Repairs – General Information) lists diagnostic checks before you cut or weld. Section 501-26 adds vehicle-specific tolerance checks. You get the factory step sequence: inspection, measurement, repair, validation. That’s the difference between a body job that lines up and one that leaves a 3mm gap at the fender seam. The manual also includes wiring diagrams for body electrical systems (doors, windows, mirrors).

Trust that. Aftermarket manuals skip the tolerance tables. Ford prints them.

If you’re working on other Ford platforms, the Ford 6.4L Workshop Manual – OEM Torque Charts & Wiring gives you the diesel side, and the Ford Fiesta 2011 Workshop Manual – 730 Pages of Factory Body & Paint Specs is a solid companion for smaller platforms. For older chassis, check the Ford Mondeo 2003 Workshop Manual – OEM Factory Specs | 2255 Pages.

To understand how Ford’s documentation fits into the wider repair world, you can read the Automotive Industry Overview from Toyota’s official site, and also the Automotive Industry Overview on Wikipedia for industry-wide standards.

What years does this manual cover?

Exact 2011 model year for Ford Focus RS and Focus ST only.

Can I use this for body panel removal on a Focus ST?

Yes. Section 501-02 (Front End Body Panels) and 501-03 (Body Closures) detail removal, installation, and alignment of all exterior panels. Includes fastener types, clip positions, and torque values for every bolt. The supplement restraint system (501-20B) has critical safety steps for airbag-disabling before you pull the bumper. The manual even specifies the tool you need for the door hinge release – it’s not a standard socket. Read that section before you start, or you will damage the hinge mechanism. I’ve seen it happen. Follow the procedure exactly as written, and the panel gaps will match factory.

You need factory data to work on these cars. Stop guessing with forums and generic guides. Access the Factory Manual – it’s the only document that tells you what Ford actually built.
